Chapter 4
Operating Information
This section describes the operational features of the ProLiant Storage System.
Status Indicators
The ProLiant Storage System has LED status indicators located in several
areas. They are used to indicate the operational status of the various sub-
systems within the storage system, such as the power supply and hard drives.
Front Bezel
The front bezel indicators are shown in Figure 4-1. Table 4-1 defines each
indicator state. Some of the indicator states described in Table 4-1 require
support from the operating system or an intelligent SCSI controller.
4-1.EPS
Figure 4-1. Front Bezel Indicators
Power
Service Required
Compaq ProLiant Storage System User Guide
4-1
