B.5.2.3.3 Foot Pedal
Click the button Foot Pedal
The scanner has two connectors (FS1 and FS2) on its back to connect foot pedals. For
each foot pedal a specific action can be defined.
Click below the designated foot pedal and select from the drop-down list which action
should be executed when the pedal is operated.
Drop-down list item
Start scan
Start scan left page
Start scan right page
Page 90
to define a function for the foot pedals.

Picture 80: Foot pedal settings

Function
Starts the scan with the selected scan area size
Starts the scan and displays the left half of the
selected scan area size.
Starts the scan and displays the right half of the
selected scan area size.
