Sony HDCU-950 Installation And Maintenance Manual

Hd camera control unit.
Hide thumbs

Advertisement

HD CAMERA CONTROL UNIT
HDCU-950
SD ENCODER UNIT
HKCU-951
HD FRAME RATE CONVERTER UNIT
HKCU-953
INSTALLATION AND MAINTENANCE MANUAL
1st Edition (Revised 3)
Serial No. 10001 and Higher : HDCU-950
Serial No. 10001 and Higher : HKCU-951
Serial No. 10001 and Higher : HKCU-953

Advertisement

   Related Manuals for Sony HDCU-950

   Summary of Contents for Sony HDCU-950

  • Page 1

    HDCU-950 SD ENCODER UNIT HKCU-951 HD FRAME RATE CONVERTER UNIT HKCU-953 INSTALLATION AND MAINTENANCE MANUAL 1st Edition (Revised 3) Serial No. 10001 and Higher : HDCU-950 Serial No. 10001 and Higher : HKCU-951 Serial No. 10001 and Higher : HKCU-953...

  • Page 2

    électrique, d’incendie ou de blessure n’effectuer que les réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres. Pour toute réparation faire appel à une personne compétente uniquement. HDCU-950 IMM...

  • Page 3

    For HDCU-950 For HDCU-950 Laser Diode Properties Attention-when the product is installed in Rack: Material : In GaAsP : 1310 ± 40 nm Wave length 1. Prevention against overloading of branch circuit Emission duration : Continuous When this product is installed in a rack and is...

  • Page 5: Table Of Contents

    Installing the HKCU-953 ........... 1-29 (E) 1-9. Installing the RM-B750 ............... 1-31 (E) 1-9-1. Connecting/Disconnecting the Flexible Card Wire ... 1-31 (E) 1-9-2. Installing the RM-B750 ............1-32 (E) 1-10. Installing in 19-inch Rack ..............1-34 (E) 1 (E) HDCU-950 IMM...

  • Page 6

    Note on Using the Large Lens Adapter CA-905L ......2-26 (E) 3. Service Overview 3-1. Cleaning of Connector/Cable ..............3-1 (E) 3-2. Recommended Replacement Parts ............3-2 (E) 3-2-1. Power Fan ................3-2 (E) 3-3. Character Display Function ..............3-3 (E) 2 (E) HDCU-950 IMM...

  • Page 7: Manual Structure

    Beside this Installation and Maintenance Manual, the following manuals are avail- able for the unit. . Operation Manual (Supplied with HDCU-950) This manual describes how to operate the HDCU-950. . Maintenance Manual (Available on request) This manual intended for use by trained system and service engineers describes (the circuit overview, the main part replacements, electrical alignment, etc.)

  • Page 8: Contents

    Section 3 Service Overview Describes recommended replacement parts, how to cleaning connector/cables and charactor display function. Trademark Trademark or registered trademark used in this manual is follows. . Clear-Com is a registered trademark of Clear-Com Intercom Systems. 4 (E) HDCU-950 IMM...

  • Page 9: Installation Overview

    RM-B750 MPU-124 Ver. 1.00 or higher HDC-950/900 AT-130 Ver. 1.20 or higher 1-2. Standard Accessories The HDCU-950 and optional boards consist of the following components. . HDCU-950 HDCU-950 unit Operation manual Maintenance manual 4-pin plug connector (M) Remote indicator assembly .

  • Page 10: Power Cord

    No. 3 of the above illustration, is used. SYNC OUT : BNC ± 0.3 V, ternary SYNC, 75 Z Or, 0.3 V p-p, SD SYNC, 75 Z selectable AC inlet Other PROMPTER IN : BNC 1.0 V p-p, 75 Z 1-2 (E) HDCU-950 IMM...

  • Page 11

    Analog signal FRAME REFERENCE IN : BNC ± 0.3 V, ternary SYNC, 75 Z Or, black burst signal 0.286 V p-p, 75 Z FRAME REFERENCE OUT : BNC THROUGH OUT/0.3 V p-p, FRAME SYNC pulse, 75 Z 1-3 (E) HDCU-950 IMM...

  • Page 12

    ASPECT REMOTE L : REMOTE RECALL5 (ENC) LOW ACTIVE ON/OFF RECALL6 (R+B) ASPECT CONT1 *3 Refer to the right column. RECALL7 (R+G) CONT2 RECALL8 (G+B) MIC2 GAIN CONT *2 Refer to the right column. ON/OFF IN 1-4 (E) HDCU-950 IMM...

  • Page 13

    POWER (+) OUT RCP POWER, +30 V G TALLY (X) IN ON : 24 Vdc, TTL (H), SHORT POWER (_) OUT GND for POWER G TALLY (Y) IN OFF : 0 Vdc, TTL (L), OPEN SPARE 1-5 (E) HDCU-950 IMM...

  • Page 14: Connection Connectors

    PROMPTER IN . CAMERA connector of the unit . CCU connector of the camera adaptor side HKCU-951 . Optical/electric signal composite cable Y/G OUT B-Y/B OUT R-Y/R OUT VBS OUT HKCU-953 FRAME REFERENCE IN FRAME REFERENCE OUT 1-6 (E) HDCU-950 IMM...

  • Page 15: Circuit Boards Layouts

    RC-91 board DRX-1 board RC-91 board or FC-88 board (HKCU-953) To install the optional board is required depending on the system to be used. For details, refer to Sections 1-8. “Installing the HKCU-951/953” and 2. “System Setup”. 1-7 (E) HDCU-950 IMM...

  • Page 16: Setting Of Switches On Boards

    . S407 (CONVERSION DELAY PHASE) Performs the fine adjustment of the delay amount of the signal between HD and SD that is set by S417 on the AT-149, in unit of 1H or 2.2 usec. 1-8 (E) Factory setting : 0 HDCU-950 IMM...

  • Page 17

    MONI connector on the rear panel. However, this function cannot be used by default at present. If you ON : Inserted want to use this function, consult your local Sony Sales Office/ Service Center. OFF : Not inserted Factory setting : OFF .

  • Page 18

    . S421 (1-8 CCU No.) composite cable This switch is mainly used to set the CCU numbers when RCP is connected to the HDCU-950. . S424-1 to 8 Use switches 1 to 8 to set the CCU numbers from 1 to 96 Factory use only in BCD notation.

  • Page 19

    MIC-OFF : Turns OFF the headset microphone. PGM : The program audio is output to the INCOM connector on the front panel. Factory setting : MIC-OFF Selecting the receiving audio is valid when S11 on the AVP-4 board is OFF. 1-11 (E) HDCU-950 IMM...

  • Page 20: Avp-4 Board

    Selects the type of the PGM (program audio). ANA : Analog system PGM (Input signals to the INCOM/TALLY/PGM connectors) SDI : Embedded digital audio of the SDI signal selected by S605 on the DTX-1 board. Factory setting : ANA 1-12 (E) HDCU-950 IMM...

  • Page 21

    POWER supply 5 V voltage POWER POWER supply . S500 (PGM 1 SEL) Set the input signal level of the PGM (program audio) CH-1 to either 0 dBu or _20 dBu. Factory setting : 0 dBu 1-13 (E) HDCU-950 IMM...

  • Page 22

    Do not change the settings of the switches described Selects the color bar signal that is output from the HD “Factory use only”. SDI OUT 1 and 2 connectors (of the HDCU-950/HKCU- 953) on the rear panel. . S201 (GRAY ON/OFF)

  • Page 23

    -5 (GRAY SIGNAL BAR-CHAR ON/OFF) This switch enables mixing of the color bar character with the gray signal that is output when camera is turned off. ON : GRAY BAR-CHAR ON OFF : GRAY BAR-CHAR OFF 1-15 (E) HDCU-950 IMM...

  • Page 24: Dtx-1 Board

    S604-5, -6 : RET3 S604-7, -8 : RET4 (PROMPTER) S604-1, -3, -5, -7 S604-2, -4, -6, -8 Aspect ratio 13 : 9 14 : 9 15 : 9 16 : 9 Factory setting : All OFF 1-16 (E) HDCU-950 IMM...

  • Page 25

    B (48i conversion) : When the camera side is 24PsF, the forced-reverse conversion is performed. (Conversion to 48i format by simple skipping) AUTO : Depends on the setting of S1-1 on the FC-88 board. Factory setting : All OFF 1-17 (E) HDCU-950 IMM...

  • Page 26

    100% & 75%-CB (non-split) output to the SD OUT. (Set the 75%-CB (non-split) cutting position using S8 on the RC- Pseudo SMPTE-CB 91 board.) Mode to down-convert HD-CB Factory setting : SQ Not used Factory setting : 0 1-18 (E) HDCU-950 IMM...

  • Page 27

    Regardless of the setting of S417 on the AT-149 board, down-conversion to the SD signal is performed with the minimum delay. ON : Minimum delay OFF : Normal mode (Depends on the setting of S417 on the AT-149 board.) 1-19 (E) HDCU-950 IMM...

  • Page 28

    VBS (ENC) of the WF output Factory setting : SDI signal. ON : VBS (SC-locked by SC-PLL) of the EN-145 board. OFF : VBS (not SC-locked by SC-PLL) of the RC-91 board. 1-20 (E) HDCU-950 IMM...

  • Page 29

    . S402 (SETUP SEL) Selects whether SETUP is added or not to the VBS signal of SD when S427-1 on the AT-149 board is set to OFF (NTSC). ON : Added OFF : Not added Factory setting: OFF 1-21 (E) HDCU-950 IMM...

  • Page 30: Board (hkcu-953)

    2 : FRAME REF SD ON : DRX-SDI-OUT phase adjustment 3 : FRAME REF S. SYNC OFF : FC-SDI-OUT phase adjustment Factory setting : 0 . S6-1 to 8 Factory use only Factory setting : All OFF 1-22 (E) HDCU-950 IMM...

  • Page 31: Functions Of Indicators On Boards

    Lights up when the REFERENCE signal is input to the REFERENCE connector on the rear panel. D108 (red) : UNLOCK display Lights up when the unit cannot be synchronized with the external REFERENCE signal in the external sync mode. 1-23 (E) HDCU-950 IMM...

  • Page 32

    Section 1-6-1. “Setting of Switches on POWER Boards _ AT-149 Board”. D201 D202 D203 D204 D205 540P CHARACTER DRX-1 board (A side/panel side) D2 (green) : POWER display Lights up when the voltage used on this board is normally supplied. 1-24 (E) HDCU-950 IMM...

  • Page 33

    Attenuates about 0.5 dB by every 1 km of cable. D605, D606, D607 : OPTICAL CONDIITON (CCU) display Attenuates about 0.5 dB by each relay connector. Displays the optical level received on the HDCU-950 side. (0 dBm = 1 mW) D611 (green) : CHU LOCK display...

  • Page 34

    When the SD system is set to 525/59.94i (NTSC). D5 (green) lights up : When the SD system is set to 625/50i (PAL). For details of the SD system setting, refer to Section 2-2, “Setting the System Format _ SD system”. 1-26 (E) HDCU-950 IMM...

  • Page 35: Installing The Hkcu-951

    Check that the EN-145 board is securely connected to 953. the motherboard (MB-951 board). D107 (red) : UNLOCK display Lights up when the frame reference signal is not synchro- nized with the main reference signal. EN-145 board 1-27 (E) HDCU-950 IMM...

  • Page 36

    (MB-951 board). 3. Secure the VDA-61 board with the two screws removed in step 1. Upper groove B3 x 5 Handle Blank panel B3 x 5 Lower groove VDA-61 board There is a difference of the depth. 1-28 (E) HDCU-950 IMM...

  • Page 37: Installing The Hkcu-953

    2. Open the front panel. (Refer to Section 1-8-1, step 2.) 3. Pull up the lever in the direction of arrow A to unlock and pull out the RC-91 board. RC-91 board Levers FC-88 board RC-91 board 1-29 (E) HDCU-950 IMM...

  • Page 38

    1 and 2. Upper grooves B3 x 5 Handle DIF-124 board SDI-73 board B3 x 5 Blank panel B3 x 5 Lower grooves DIF-124 board There is a difference of the depth. B3 x 5 1-30 (E) HDCU-950 IMM...

  • Page 39: Installing The Rm-b750

    (Blue) of the flexible card wire into the connector in the direction that is shown against the recessed portion of the connector. 2. Return the portion “A” to its original position and lock the connector. 1-31 (E) HDCU-950 IMM...

  • Page 40: Installing The Rm-b750

    Flexible card wire 2. Loosen the four screws (with drop-safe) and open the front panel and the rear panel in the direction of the respective arrows. Rear panel Front panel Screws (with drop-safe) Screws (with drop-safe) 1-32 (E) HDCU-950 IMM...

  • Page 41

    RM-B750 is ON. Front panel of the RM-B750 The switch S206 (CCU-PW) on the MPU-124 board is the power ON/OFF switch for the RM-B750. If it is set to OFF, the panel functions are stopped. 1-33 (E) HDCU-950 IMM...

  • Page 42: Installing In 19-inch Rack

    1-10. Installing in 19-inch Rack 1-10. Installing in 19-inch Rack Installation The two HDCU-950 can be mounted in parallel in a 19- 1. Secure the RMM-301 in the 19-inch EIA standard rack inch EIA standard rack by using the rack mount adapter with the four B5 screws (6 mm or longer).

  • Page 43: System Setup

    HKCU-953: Install the HKCU-953 when you want to shoot picture in 24PsF mode of the camera, and you need the HD (SD) signal created by the 2 to 3 Pulled Down method. HDCU-950 (without optional board installed) HDCU-950 with HKCU-953...

  • Page 44: Standard System

    +B M3 +B M3 +B M3 HDCU-950 CNU-700 HDC-950 + CA-905L HKCU-951 HKCU-953 MSU-700A/750 +B M3 +B M3 +B M3 PIX/WF (HDCU-950) HDCU-950 HDC-950 + CA-905L HKCU-951 HKCU-953 +B M3 +B M3 +B M3 HDC-950 HDCU-950 HKCU-951 HKCU-953 +B M3...

  • Page 45: Standard Hd/sd System

    WF MODE +B M3 +B M3 +B M3 +B M3 MIC REMOTE INCOM/TALLY/PGM +B M3 +B M3 +B M3 HDCU-950 HD-SDI Monitor SD ANALOG VIDEO SIGNAL Next HDCU-950 SD REFERENCE SIGNAL CNU-700 Terminated at 75 Z 2-3 (E) HDCU-950 IMM...

  • Page 46: Hd/sd Film Like System

    WF MODE +B M3 +B M3 +B M3 +B M3 MIC REMOTE INCOM/TALLY/PGM +B M3 Waveform Monitor +B M3 +B M3 HDCU-950 SD ANALOG VIDEO SIGNAL SD REFERENCE SIGNAL Next HDCU-950 CNU-700 Terminated at 75 Z 2-4 (E) HDCU-950 IMM...

  • Page 47: Analog Ntsc/pal System

    +B M3 +B M3 +B M3 +B M3 INCOM/TALLY/PGM MIC REMOTE +B M3 +B M3 +B M3 HDCU-950 Next HDCU-950 WF 2 PIX 2 SD ANALOG VIDEO SIGNAL SD REFERENCE SIGNAL VCS-700 PIX 1 WF 1 REMOTE PIX A WF A...

  • Page 48: Setting The System Format

    540P : When shooting with 540-60P system. (At present, this function is not supported.) If you select a format of 48i (48 field interlace) or other format that is not supported by the HDCU-950, the setting causes an error and the indicators (D201 to D205) on the AT-149 board flash.

  • Page 49: Setting The Reference Input

    When the sub reference is not input, the pulse gate signal of the frame sync is output from the loop-through output terminal. You can lock the frame sequence between multiple CCUs if you connect this signal to the sub reference input of other CCUs. 2-7 (E) HDCU-950 IMM...

  • Page 50: Audio System

    RTS system. Otherwise, they oscillate and system used. Then, select the number of intercom line have adverse effects on the peripheral circuits. systems (1ch or 2ch). 2-8 (E) HDCU-950 IMM...

  • Page 51

    3. Set the mix amout of 1. Select the input 4W/RTS/ PGM audio signal Clear-Com INCOM SELECT switch on board panel 4. Setting for the INCOM connector on the front panel To the INCOM connector on the front panel 2-9 (E) HDCU-950 IMM...

  • Page 52: Setting The Microphone

    8 : 1 FRAME DELAY (25 FRAME/SEC) right. Factory setting : 0 Setting the microphone input control of the video camera Pin No. Microphone connector MIC IN CH-1 MIC IN CH-2 Internal setup (MIC LEVEL switch on the AVP-4 board panel) 2-10 (E) HDCU-950 IMM...

  • Page 53: Systems

    Setting the output level of MIC 2 : Supplying POWER POWER POWER POWER 1RV501 (MIC 2 OUT LEVEL) 24 V power Supplying POWER POWER 5 V power Switches S100 and S101 are set to CONTACT when the unit is shipped from the factory. 2-11 (E) HDCU-950 IMM...

  • Page 54: Setting The Camera Number

    System that uses CNU-700/500 The CCU connector number on the rear of the CNU-700/ 500 is the camera number. For example, the camera number of the CCU video camera that is connected to the CCU 1 connector is 1. 2-12 (E) HDCU-950 IMM...

  • Page 55

    2-4. Systems HDCU-950 [1] CAMERA +B M3 REFERENCE PROMPTER +B M3 +B M3 +B M3 MIC1 +B M3 +B M3 +B M3 SD SDI OUT 1 +B M3 +B M3 +B M3 SD SDI SERIAL +B M3 RET1 OUT 2...

  • Page 56: Video Signal System

    When using 10F-BB (NTSC 10-field sequence BB) of SMPTE318M as BB, the frame sequences of the 30 Hz frame frequency and the 24 Hz frame frequency can be locked by setting switch S416 (REF-10F-BB) on the AT-149 board to ON. 2-14 (E) HDCU-950 IMM...

  • Page 57

    In the HDC-950/930 series camera system, the aspect ratio the AT-149 board to MIC REMOTE (OFF). can be switched by using the HDCU-950 and MSU-700A/ 2. Set pin-12 (ASPECT REMOTE ON/OFF) of the MIC 750 according to the system during HD-SD down-convert.

  • Page 58

    S7/RC-91 → LB S10-3, -4/RC-91 → ON The picture that is cut out with the aspect 2-16 (E) HDCU-950 IMM ratio of 13 : 9, is inserted into the 4 : 3 ratio picture and is output in the SD SDI format.

  • Page 59: Level Adjustment Of The Vbs Signal

    1. Check the switch S107-3 on the EN-145 board to OFF. Factory setting : OFF 2. Press the BARS button of the MSU-700A/750, RCP- 700 series, etc. to display the color bars on the wave- form or vector monitor. 2-17 (E) HDCU-950 IMM...

  • Page 60: Adjusting The Level Of Signals For Waveform Monitor

    “4” range. HDCU rear panel (WFM 1 CHROMA control) A = 100 ± 1 IRE [for NTSC] Specification : A = 700 ± 7 mVp-p [for PAL] [for NTSC] [for PAL] [for NTSC] [for PAL] 2-18 (E) HDCU-950 IMM...

  • Page 61

    RV303 (STAIR STEP POSITION) on the RC- 91 board. 3. Use control RV304 (STAIR STEP LEVEL) on the RC-91 board so that the intervals of signals A and B to be displayed are almost equal. 2-19 (E) HDCU-950 IMM...

  • Page 62

    If required, change the polarity of the control from the setting of switch S301 (SEQ) on the RC-91 board. If adjustment is not possible even after the polarity is changed, perform the adjustment on the waveform monitor side. 2-20 (E) HDCU-950 IMM...

  • Page 63: Adjusting The Level Of Signals For Picture Monitor

    Measurement point : PIX OUT connector on the [for NTSC] [for PAL] HDCU rear panel A = 100 ± 1 IRE [for NTSC] Specification : A = 700 ± 7 mV p-p [for PAL] [for NTSC] [for PAL] 2-21 (E) HDCU-950 IMM...

  • Page 64: Setting The Ret Input

    S604-7, -8 : PROMPTER (RET 4) S601 S604-1, -3, -5, -7 S604-2, -4, -6, -8 Aspect ratio S603 S604 S605 13 : 9 14 : 9 15 : 9 16 : 9 RETURN SET switch DTX-1 board (A side/panel side) 2-22 (E) HDCU-950 IMM...

  • Page 65

    S603-2, -4, -6, -8/DTX-1 → ON Letter box Letter box (16 : 9) The same picture as the camera output S603-1 to -8/DTX-1 → ON picture is shown. S604-1 to -8/DTX-1 → OFF 2-23 (E) HDCU-950 IMM...

  • Page 66

    S604-1, -3, -5, -7/DTX-1 → ON S604-2, -4, -6, -8/DTX-1 → OFF Edge-crop Semi-letter box (13 : 9) When the signal was up-converted in the edge-crop S603-1 to -8/DTX-1 → ON mode S604-1 to -8/DTX-1 → ON 2-24 (E) HDCU-950 IMM...

  • Page 67

    Setup switch : S610 on the DTX-1 board (Factory setting : 0) You can set phase of the frame frequency conversion manually. For details, refer to Section 1-6-5. “Setting of Switches on Boards _ DTX-1 Board”. 2-25 (E) HDCU-950 IMM...

  • Page 68: Note On Using The Large Lens Adapter Ca-905l

    2-6. Note on Using the Large Lens Adapter CA-905L 2-6. Note on Using the Large Lens Adapter CA-905L When attaching the large lens adapter CA-905L to the camera to be connected to the HDCU-950, note the following. Viewfinder Use of the 6-type color LCD viewfinder HDVF-C700W is recommended.

  • Page 69: Service Overview

    Follow the procedures below for cleaning. Tools Required . Alignment sleeve remover HC-001 (for female connector) Sony P/N : J-6480-010-A Female connector Insert the shorter nose end when removing/installing the The optical contacts for female connector are in an unex- alignment sleeve.

  • Page 70: Recommended Replacement Parts

    The lifespan of the fan is about 30,000 hours, which means (Alignment sleeve: Sony P/N 9-980-074-01) that the fan can be used for about three and a half years if the power is on all the time, so the fan should be replaced according to service conditons.

  • Page 71: Character Display Function

    ACTER switch on the panel surface of the DRX-1 board) . HD monitor is kept pressed, the pages are changed continuously. After Sony BVM-D20F1J or equivalent all the pages are displayed, the cycling display stops on the . SD monitor...

  • Page 72

    Displays the type of signal that is input to the RET 4 Detail (PROMPTER) connector on the rear panel of the unit. 1 ON *1 : For details, refer to Section 2, “System Setup”. F:CLS Contents Displays information of White/Black/Black γ/Flare/Detail, etc. 3-4 (E) HDCU-950 IMM...

  • Page 73

    *3 : The optical sending/receiving level state of the main unit also can be 14 of the character display. checked using the indicator on the panel surface of the DTX-1 board. For details, refer to Section 1-7-5. “Functions of the Indicators on the Boards _ DTX-1 Board”. 3-5 (E) HDCU-950 IMM...

  • Page 74

    Sense : The communication with the equipment connected to the PANEL connector is being established. Power is supplied or not to the front RM panel. ON : 30 V power is supplied for the front panel. OFF : Power is turned off. 3-6 (E) HDCU-950 IMM...

  • Page 75

    AT-141 board (Normal/Test) *4 : For details, refer to Section 1-6-1. “Setting of Switches on Boards _ AT- 149 Board”. *5 : Set S424 to all OFF so that it is set to normal mode. 3-7 (E) HDCU-950 IMM...

  • Page 76

    Config NG : PLD (IC401 on the DTX-1 board) did not start correctly. State of the operation mode on the DTX-1 board (Normal/ Test) *6 : For details, refer to Section 1-6-5. “Setting of Switches on Boards _ DTX-1 Board”. 3-8 (E) HDCU-950 IMM...

  • Page 77

    *9 : When S10-1 on the RC-91 board and the HKCU-951 are installed, set the switch with S104 on the EN-145 board. For details, refer to Sections 1-6-6 and 1-6-7. “Setting of Switches on Boards _ RC-91 Board and EN-145 Board”. 3-9 (E) HDCU-950 IMM...

  • Page 78

    *11 : When S10-1 on the RC-91 board and the HKCU-951 are installed, set the switch with S104 on the EN-145 board. For details, refer to Sections 1-6-6 and 1-6-7. “Setting of Switches on Boards _ RC-91 Board and EN-145 Board”. 3-10 (E) HDCU-950 IMM...

  • Page 79

    Contents Displays the ROM version of the camera. Displays the ROM (IC510 and IC553 on the AT-149 board) version of the HDCU-950. Displays the ROM version of the equipment that is connected to the RCP/CNU connector on the rear panel of he HDCU-950.

  • Page 81

    : The material contained in this manual consists of information that is the property of Sony Corporation. Check the metal trim, “metallized” knobs, Sony Corporation expressly prohibits the duplication of...

  • Page 82

    Printed in Japan Sony Corporation HDCU-950 (SY) J, E 2003. 6 16 B&P Company 3-619-324-04 ©2002...
