1.2 Applications
• Industrial ON/OFF control
• Switch status sensing
• BCD interfacing
• Digital I/O control
• Industrial and lab automation
• Laboratories & Education
1.3 Installation Guide
Before you install your PCI-1736UP card, please make sure you have the
following necessary components:
• PCI-1736UP card
• PCI-1736UP User Manual
• Driver software Advantech DLL drivers
(included in the companion CD-ROM)
• Wiring cable PCL-10144 (optional)
• Wiring board ADAM-3944 (optional)
• Computer Personal computer or workstation with a PCI-bus slot (run-
ning Windows 98/2000/XP)
Some other optional components are also available for enhanced
operation:
• Application software ActiveDAQ, ADAQ-View or other third-party
software packages
After you get the necessary components and maybe some of the accesso-
ries for enhanced operation of your Multifunction card, you can begin the
installation procedures.
PCI-1736UP User Manual
4
