Advantech PCI-1733 Startup Manual

PCI-1733
32-channel Isolated Digital Input Card
Packing List
Before installation, please make sure that you have
received the following:
ƒ PCI-1733 card
ƒ Driver CD
ƒ Quick Start User Manual
If anything is missing or damaged, contact your
distributor or sales representative immediately.
User Manual
For more detailed information on this product, please
refer to the PCI-1730_1733_1734 User Manual on the
CD-ROM (PDF format).
CD:\Documents\Hardware Manuals\PCI\PCI-1730
Declaration of Conformity
FCC Class A
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications. Operation
of this equipment in a residential area is likely to cause
interference in which case the user is required to correct
interference at his own expense.
CE
This product has passed the CE test for environmental
specifications when shielded cables are used for external
wiring. We recommend the use of shielded cables. This
kind of cable is available from Advantech. Please contact
your local supplier for ordering information.
Notes
For more information on this and other Advantech
products, please visit our websites at:
http://www.advantech.com
For technical support and service:
http://www.advantech.com/support/
This startup manual is for PCI-1733.
Part No: 2003173301
1 Startup Manual
Overview
The Advantech PCI-1733 is a 32-channel isolated digital
input card for the PCI bus. For easy monitoring, each
isolated digital input channel is equipped with one red
LED, and each isolated digital output channel is equipped
with one green LED to show its ON/OFF status. The PCI-
1733's isolated digital input channels are ideal for digital
input in noisy environments or with floating potentials.
The PCI- 1733 provides specific functions for different
user requirements.
Specifications
Isolated Digital Input
Number of Channels
Optical Isolation
Opto-isolator response time 100 μs
Over-voltage Protection
Input Voltage
Input Current
General
I/O Connector Type 37-pin D-Sub female
Dimensions
Power Consump-
tion
Temperature
Relative Humidity
Certification
2nd Edition
June 2015
32 (bi-directional)
2,500 VDC
70 VDC
VIH (max.) 30 VDC
VIH (min.) 5 VDC
VIL (max.) 2 VDC
5 VDC 1.4 mA (typical)
12 VDC 3.9 mA (typical)
24 VDC 8.2 mA (typical)
30 VDC 10.3 mA
(typical)
175 mm x 100 mm ( 6.9" x 3.9" )
Typical +5 V @ 200 mA
+12 V @ 50 mA
Max. +5 V @ 350 mA
Operation 0 ~ +60°C (32~ 140°F )
(refer to IEC 68 -2 - 1 ,2)
Storage -20 ~ +70°C (-4 ~158°F)
5 ~ 95% RH non-condensing
(refer to IEC 60068-2-3)
CE/FCC
