JAI CV-A11 Operation Manual

Jai progressive scan monochrome ccd camera cv-a11 operation manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Progressive Scan Monochrome CCD Camera
CV-A11
Operation Manual
Camera: Revision B
Manual: Version 2.1
A11Manualjul15
JPT 15-07-03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CV-A11 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JAI CV-A11

Summary of Contents for JAI CV-A11

  • Page 1 Progressive Scan Monochrome CCD Camera CV-A11 Operation Manual Camera: Revision B Manual: Version 2.1 A11Manualjul15 JPT 15-07-03...

  • Page 2: Table Of Contents

    7. Configuring the Camera ... 17 7.1. RS-232C control..17 7.2. CV-A11 RS-232C command list..18 7.3. Camera Control Tool for CV-A11 ... 19 7.4.1. HD/VD input-output selection ... 20 7.4.2. Selecting termination of HD/VD input signals ... 20 8.

  • Page 3: General

    1. General The CV-A11 is a monochrome progressive scan 1/3” CCD cameras, designed for automated inspection application, featuring an extremely small housing and a wide range of unique functions. The asynchronous trigger can be set to work in several modes, to allow functions such as pulse width controlled shutter, programmable shutter speed and long time integration.

  • Page 4: Camera Housing And Dimensions

    4. Camera Housing and Dimensions 12 pin Hirose connector for frame grabber interfacing and power (12V DC). BNC connector for video output. VS 1.0 Vpp 75 Ohm. 6 pin Hirose connector for trigger input and RS-232C control interface. Gain potentiometer for manual gain setting. Mounting holes, 8 x M3.

  • Page 5: Pin Assignment

    EEN will be low all the time in normal continous mode (TR=0), if the selected exposure time is longer than the frame readout time. For schematic diagram of the input and output circuit alternative settings refer to 5.3. CV-A11 Pin configuration is compatible with EIAJ standard Pin no.

  • Page 6: Input And Output Circuits

    5.3. Input and Output Circuits In the following schematic diagrams the input and output circuits for video and timing signals are shown. For alternative connections refer to “10.1. CV-A11 emulating CV-M10 interfacing.” Jumper settings are shown as for factory default.

  • Page 7: Functions And Operations

    6. Functions and Operations Apart from the standard continuous operation, the CV-A11 features three external asynchronous trigger modes (edge pre-select, pulse width controlled and start/stop) and a special frame-delay readout mode. Long integration time mode is also supported. In addition, the CV-A11 also provides a partial scan readout function.

  • Page 8: Input-Output Of Hd/Vd Signals

    6.2. Input-output of HD/VD Signals In the default setting the camera will accept external HD/VD signals on pin 6 and 7 of the 12 pin Hirose connector. If external HD/VD is applied, the camera will synchronize to it. If no external sync signals are applied, the camera will operate with its internal x-tal controlled sync.

  • Page 9: External Trigger Modes

    6.4. External Trigger Modes This camera has 6 external asynchronous trigger modes, which can be set by RS-232C commands. Edge Pre-select Mode.TR=1 Pulse Width Control Mode. TR=2 Frame Delay read out mode. TR=3 Long Time Exposure Mode. TR=4 Start/stop Mode. TR=5 Smearless Read out mode.

  • Page 10: Edge Pre-Select Mode

    6.5. Edge Pre-select Mode An external trigger pulse initiates the capture (input on pin 11 of the 12-pin Hirose connector or pin 5 of the 6-pin Hirose). The leading edge of the trigger pulse initiates the exposure (this is a falling edge if factory default).

  • Page 11: Pulse Width Control Mode

    6.6. Pulse Width Control Mode The leading edge of the trigger pulse initiates the capture. The exposure time (accumulation time) is governed by the duration of the trigger pulse. If the polarity of this pulse is reversed, the camera can be configured to correct for it. The exposure time range is 1.5H to 1000H (shortest and longest pulse duration).

  • Page 12: Frame-Delay Read Out Mode

    6.7. Frame-delay read out Mode This mode allows simultaneous capture of multiple camera using a common external trigger pulse subsequent multiplexed (sequential) readout using a single input frame grabber, as the user has control over when the image is read out from the CCD sensor. The exposure starts at the falling edge of the ext.

  • Page 13: Long Time Exposure Mode

    6.8. Long Time Exposure Mode The exposure time is the interval between 2 ext. VD pulses sent to the VD input of the camera (Pin No. 7 of the 12-pin Hirose connector). The exposure starts after input of the first ext. VD pulse, and ends after the next input of the next ext.

  • Page 14: Start/Stop Mode

    6.9. Start/Stop Mode The exposure time is controlled by the interval between the ext. trigger and the ext. VD signal. The exposure starts at the first HD pulse after the falling edge of the ext. trigger, and stops at the rising edge of the VD pulse. The range can be between 1/30 to 1/10,000 second. The Start/Stop mode is a continuous mode where the VD signal must be given continuously.

  • Page 15: Smearless Mode

    6.10. Smearless Mode This mode will reduce the unwanted smear signal from a highlighted scene when a short exposure time is used. The trigger mode is like edge pre-select, but a fast dump readout is performed before the active accumulation is started. It will remove the smear over the highlighted parts in the image, but there is still smear left below highlighted areas.

  • Page 16: Partial Scan Readout Mode

    6.11. Partial scan readout mode This mode allows increased frame rate, as only a selected number of lines are read out. The vertical resolution is reduced as outlined below. Partial scan will operate in normal continuous mode and all trigger modes. The partial scanning settings are as follows: Readout format Frame rate Effective lines...

  • Page 17: Other Functions

    CV-A11 6.12. Other Functions Gain and analogue settings. !! Do not adjust these settings unless you have knowledge to video adjustments !! AS, AGC Switch The video gain can be set to AGC or manual. In AGC mode the video level is kept constant by the automatic gain control circuit within a 12 dB range.

  • Page 18: Configuring The Camera

    7. Configuring the Camera 7.1. RS-232C control. All configuration of the CV-A11 camera is done via the RS-232C port. The camera can be set up from a PC running terminal emulator software, or using JAI´s camera control software. Below is the description of the ASCII based short command protocol.

  • Page 19: Cv-A11 Rs-232C Command List

    7.2. CV-A11 RS-232C command list. Command Name A – General settings and useful commands Echo Back Camera Status request Online Help request Firmware version B – Timing and shutter related commands Scanning format Trigger mode Shutter mode Shutter speed Programmable expos.

  • Page 20: Camera Control Tool For Cv-A11

    7.3. Camera Control Tool for CV-A11 From www.jai.com CV-A11 Camera Control Tool for Windows 98/NT/2000 can be downloaded. The control tool contents a camera control program and tools for making your own program. Below the different windows are shown. Control bar Windows for all functions Fig.

  • Page 21: Hd/Vd Input-Output Selection

    7.4. Internal Switch and Jumper Settings. 7.4.1. HD/VD input-output selection In the default setting the camera will accept external HD/VD signals on pins 6 and 7 of the 12 pin Hirose connector. The composite video signal from the camera will be synchronized to an external HD/VD source connected to the camera.

  • Page 22: Specifications

    20 – 80% non-condensing -25 to 60 /20% - 80% 12V DC ± 10%, 1.8W Max. 29 x 44 x 66mm (HxWxD) Wave Length (nm) Fig. 27. Spectral sensitivity. - 21 - CV-A11 29.96 Hz > 56dB C-mount 150g 1000...

  • Page 23: Appendix

    M-series. This new configuration is compliant to the EIA-J standard. This means, however, that the CV-A11 is not completely backward compatible with the CV-M10, CV-M40, etc in all cases (depending on the cable configuration). The table below shows how to change the pin configuration, by changing internal solder jumpers.

  • Page 24: Precautions

    CV-A11 10.2. Precautions Personnel not trained in dealing with similar electronic devices should not service this camera. The camera contains components sensitive to electrostatic discharge. The handling of these devices should follow the requirements of electrostatic sensitive components. Do not attempt to disassemble this camera.

  • Page 25: Users Record

    Company and product names mentioned in this manual are trademarks or registered trademarks of their respective owners. JAI A-S cannot be held responsible for any technical or typographical errors and reserves the right to make changes to products and documentation without prior notification.
