Antenna Specifications

GSM/EGSM Antenna Requirements/Specifications

Frequency Range:
Impedance:
VSWR:
Typical Radiated Gain:
Radiation:
Polarization:
Wave:

Antennas Available from Multi-Tech Systems, Inc.

Quad Band Description
Hinged Right Angle 800/900/1800/1900 MHz Cellular Modem Antenna
Hinged Right Angle 800/900/1800/1900 MHz Cellular Modem Antenna
Hinged Right Angle 800/900/1800/1900 MHz Cellular Modem Antenna
Dual Band Description
Hinged Right Angle 900/1800 MHz Cellular Modem Antenna
Hinged Right Angle 900/1800 MHz Cellular Modem Antenna
Hinged Right Angle 900/1800 MHz Cellular Modem Antenna
Hinged Right Angle 800/1900 MHz Cellular Modem Antenna
Hinged Right Angle 800/1900 MHz Cellular Modem Antenna
Hinged Right Angle 800/1900 MHz Cellular Modem Antenna
Mag Mount Dual Band Description
Mag Mount 900/1800 MHz 1/2 Wave Cellular Antenna, 12.5"
Mag Mount 900/1800 MHz 1/2 Wave Cellular Antenna, 12.5"
Mag Mount 900/1800 MHz 1/2 Wave Cellular Antenna, 12.5"
Mag Mount 900/1800 MHz 1/4 Wave Cellular Antenna, 4"
Mag Mount 900/1800 MHz 1/4 Wave Cellular Antenna, 4"
Mag Mount 900/1800 MHz 1/4 Wave Cellular Antenna, 4"
Mag Mount 850/1900 MHz 1/2 Wave Cellular Antenna, 12.5"
Mag Mount 850/1900 MHz 1/2 Wave Cellular Antenna, 12.5"
Mag Mount 850/1900 MHz 1/2 Wave Cellular Antenna, 12.5"
Mag Mount 850/1900 MHz 1/4 Wave Cellular Antenna, 4"
Mag Mount 850/1900 MHz 1/4 Wave Cellular Antenna, 4"
Mag Mount 850/1900 MHz 1/4 Wave Cellular Antenna, 4"
GPS Description
Mag Mount GPS Antenna, 5 Meter Cable
Mag Mount GPS Antenna, 5 Meter Cable

PTCRB Requirements Note

There cannot be any alteration to the authorized antenna system. The antenna system must be the same type with similar in-
band and out-of-band radiation patterns and maintain the same specifications.

FCC Requirements Note

The antenna gain, including cable loss, for the radio you are incorporating into your product design must not exceed the
requirements at 850 MHz and 1900 MHz as specified by the FCC grant for mobile operations and fixed mounted operations as
defined in 2.1091 and 1.1307 of the FCC rules for satisfying RF exposure compliance. The antenna used for transmitting must
be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any
other antenna transmitters. User and installers must be provided with antenna installation instructions and transmitter operating
conditions to satisfying RF exposure compliance.
Multi-Tech Systems, Inc. MultiModem iCell User Guide
824 – 960 MHz / 1710 – 1990 MHz
50 Ohms
<2.0:1
3 dBi on azimuth plane
Omni
Vertical
Half Wave Dipole
Qty Part Number
1 ANQB-1HRA
10 ANQB-10HRA
50 ANQB-50HRA
Qty Part Number
1 ANF1-1HRA
10 ANF1-10HRA
50 ANF1-50HRA
1 ANCF2-1HRA
10 ANCF2-10HRA
50 ANCF2-501HRA
Qty Part Number
1 ANF1-1MMHW
10 ANF1-10MMHW
50 ANF1-50MMHW
1 ANF1-1MMQW
10 ANF1-10MMQW
50 ANF1-50MMQW
1 ANCF2-1MMHW
10 ANCF2-10MMHW
50 ANCF2-50MMHW
1 ANCF2-1MMQW
10 ANCF2-10MMQW
50 ANCF2-50MMQW
Qty Part Number
1 ANGPS-1MM
10 ANGPS-10MM
