Chapter 4 – Antennas

Cellular Antenna

Cellular devices were approved with the following antenna:
Manufacturer:
Model Number:
MultiTech ordering information:
Model
ANLTE4V2-1HRA
ANLTE4V2-2HRA
ANLTE4V2-10HRA
ANLTE4V2-50HRA

Cellular Antenna Specifications

Category
Frequency Range
Impedance
VSWR
Peak Gain
Radiation
Polarization
Connector

Antenna System Cellular Devices

The cellular/wireless performance depends on the implementation and antenna design. The integration of the
antenna system into the product is a critical part of the design process; therefore, it is essential to consider it early
so the performance is not compromised. Devices were approved with the following antenna(s) and for alternate
antennas meeting the given specifications.
®
MultiConnect microCell MTCM-L4N1D User Guide
S000822 Rev. 1.1
Wieson
ARY118-0167-001-00
Quantity
1
2
10
50
Description
617-960 MHz
1447-2690 MHz
3300-3800 MHz
50 Ohms
619-960 MHz: 2.5:1
1447-2690 MHz: 2:1
3300-3800 MHz: 2:1
619-960 MHz: 1.89 dBi
1447-2690 MHz: 3.95 dBi
3300-3800 MHz: 1.56 dBi
Omni-directional
Linear
SMA(M)
ANTENNAS
11
