ANTENNAS
Chapter 4 – Antennas

Antenna System Cellular Devices

The cellular/wireless performance depends on the implementation and antenna design. The integration of the
antenna system into the product is a critical part of the design process; therefore, it is essential to consider it early
so the performance is not compromised. Devices were approved with the following antenna(s) and for alternate
antennas meeting the given specifications.
The antenna system is defined as the UFL connection point from the device to the specified cable specifications
and specified antenna specifications.

Requirements for Cellular Antennas with regard to FCC/IC Compliance

This device has been designed to operate with the antennas listed below and having a maximum antenna gain of
6.18 dBi for the 700 MHz band, 6.00 dBi for 1700 MHz band, and 9.01 dBi for the 1900 MHz frequency band.
Antennas not included in this list or that have a gain greater than specified are strictly prohibited for use with this
device. The required antenna impedance is 50 ohms.

Antenna

Devices were approved with the following antenna:
Manufacturer:
Description:
Model Number
MultiTech ordering information:
Model
ANLTE4-1HRA
ANLTE4-2HRA
ANLTE4-10HRA
ANLTE4-50HRA

Antenna Specifications

Category
Frequency Range
VSWR
Gain
Impedance
18
Wieson
LTE Antenna with SMA-Male Connector
GY115IE002-001
Quantity
1
2
10
50
Description
0.698 - 0.96 GHz
1.710 - 2.170 GHz
2.30 - 2.69 GHz
3:1 maximum
2.06 dBi
50Ω nominal
®
