Specifications

Features MTCMR-E1
Performance EDGE: E-GPRS Class 12,
GPRS: Class 10
Band, Frequency
Quad-band GSM/GPRS/EDGE
850/900/1800/1900 MHz
Packet Data EDGE: E-GPRS Up to 240K bps,
coding scheme MCS 1-9, mobile
station Class B, LLC layer, 4 time
slots. GPRS: Full PBCCH support,
coding scheme 1-4, mobile station
Class B
Circuit-Switched Up to 14.4K bps, non-transparent
Data
Short Message
Text & PDU, Point-to-Point
Services-SMS (MO/MT), cell broadcast
Antenna RF Antenna: 50 ohm SMA (female
Connector connector)
SIM Connector Standard 1.8 and 3V SIM slot
External
Connectors
Voltage 9V to 32 VDC
Physical
Description
Operating -35° to +75° C
Temperature *
UL listed @ 40°
Storage Temp -40° to +85° C
Humidity
Certifications
EMC Compliance
FCC Part 15 Class B
EN55022 Class B
Radio Compliance
FCC Part 22, 24
RSS132,133
EN301 489-1
EN301 489-3 (-GP only)
EN301 489-7
EN301 511
EN301 908
AS/ACIF S042.1, S042.3
Safety: UL60950-1
cUL60950-1
IEC60950-1
Network: PTCRB
*
UL Listed @ 40° C, limited by power supply. UL Certification does not apply or extend to an ambient above 40° C and has not been evaluated by UL for ambient greater than 40° C.
"UL has evaluated this device for use in ordinary locations only. Installation in a vehicle or other outdoor locations has not been evaluated by UL. UL Certification does not apply or extend to use
in vehicles or outdoor applications or in ambient above 40° C."
Multi-Tech Systems, Inc. MultiModem iCell User Guide
MTCMR-C1
CDMA2000 1xRTT GPRS Class 10
Dual-band 800/1900 MHz CDMA; Quad-band GSM
800 MHz and 800/1900 MHz with
850/900/1800/1900 MHz
R-UIM support
Up to 153.6K bps forward and Up to 85.6K bps, coding schemes
reverse CS1 to CS4
IS-95A, IS-95B up to 14.4K bps Up to 14.4K bps transparent and
forward and reverse non-transparent
Text & PDU, Point-to-Point Text & PDU, Point-to-Point, cell
(MO/MT), cell broadcast broadcast
RF Antenna: 50 ohm SMA (female RF Antenna: 50 ohm SMA
connector) (female connector)
- Standard 1.8 and 3V SIM slot
RS2323: DE9; GPIO: 6 pin 2x3 style; Power: 2.5mm miniature (screw-on); USB: Type B
9V to 32 VDC 9V to 32 VDC
4.9" Width x 1.1" Height x 3.1" Depth
12.4 cm Width x 2.8 cm Height x 7.9 cm Depth 227 grams
-40° to +85° C -40° to +85° C
UL listed @ 40° UL listed @ 40°
-40° to +85° C -40° to +85° C
Relative humidity 20% to 90% noncondensing
EMC Compliance EMC Compliance
FCC Part 15 Class B
EN55022 Class B
Radio Compliance Radio Compliance
FCC Part 22, 24
RSS132,133
Safety: UL60950-1
cUL60950-1
IEC60950-1
Network: CDG 1&2
Safety:
Network:
MTCMR-G2
HSPA
HSUPA / HSDPA / UMTS Triple-
band: 2100/1900/850 MHz with Rx
diversity
HSDPA data service of up to
7.2 Mbps
HSUPA data service of up to
5.76 Mbps
Up to 14.4K bps transparent and
non-transparent
Text & PDU, Point-to-Point
(MO/MT), cell broadcast
RF Antenna: 50 ohm SMA (female
connector)
Standard 1.8 and 3V SIM slot
9V to 32 VDC
8 ounces
-30° to +60° C
UL listed @ 40°
-40° to +85° C
EMC Compliance
FCC Part 15 Class B FCC Part 15 Class B
EN55022 Class B EN55022 Class B
Radio Compliance
FCC Part 22, 24 FCC Part 22, 24
RSS132,133 RSS132,133
EN301 489-1 EN301 489-1
EN301 489-3 (-GP only) EN301 489-3 (-GP only)
EN301 489-7 EN301 489-7
EN301 511 EN301 489-24
EN301 908 EN301 511
AS/ACIF S042.1, S042.3 EN301 908
UL60950-1 AS/ACIF S042.1, S042.3
cUL60950-1 Safety: UL60950-1
IEC60950-1 cUL60950-1
IEC60950-1
PTCRB
Network:
MTCMR-H4 MTCMR-EV2
CDMA2000 1xRTT
EV-DO Rev. A
Dual-band 800/1900 MHz CDMA;
800 MHz and 800/1900 MHz with
R-UIM support
Up to 153.6K bps forward and
reverse
IS-95A, IS-95B up to 14.4K bps
forward and reverse
Text & PDU, Point-to-Point
(MO/MT), cell broadcast
RF Antenna: 50 ohm SMA (female
connector)
9V to 32 VDC
-30° to +85° C
UL listed @ 40°
-40° to +85° C
EMC Compliance
FCC Part 15 Class B
EN55022 Class B
Radio Compliance
FCC Part 22, 24
Safety: UL60950-1
cUL60950-1
IEC60950-1
Network: CDG 1&2
PTCRB
