  • Page 1 ® MultiModem GPRS USB Wireless Modem MTCBA-G-U User Guide...
  • Page 2 Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc., to notify any person or organization of such revisions or changes.

  • Page 3: Table Of Contents

    Chapter 5 – Reference Information...32 Wireless Modem Reference Information ...32 Appendix A – Warranty and Repairs ...33 Appendix B - Waste Electrical and Electronic Equipment (WEEE) Statement ...35 Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Contents Table of Contents...

  • Page 4: Chapter 1 - Product Description And Specifications

    A Note About Documentation: Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc., to notify any person or organization of such revisions or changes.

  • Page 5: Application Overview

    Using the embedded Internet protocols and the wireless connection to an IP network, it sends and receives data over the Internet. It can also serve a single web page in response to a web browser request. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 2 – Installation...

  • Page 6: Safety

    Therefore, keep it in a safe place at all times and out of the reach of children. Try to remember your Unlock and PIN codes. Become familiar with and use the security features to block unauthorized use and theft. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 2 – Installation...

  • Page 7: Package Contents

    Part to be Supplied by Your Wireless Service Provider Subscriber Identity Module (SIM) configuration chip. The SIM contains information specific to your wireless account and its features. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Bundled Package (multiple units) Each individual package in the bundle includes...

  • Page 8: Specifications

    Impedance VSWR Typical Radiated Gain Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide 4.3" L x 2.4" W x 0.94" H; 4.2 oz. (11 cm x 6.1 cm x 2.4 cm; 119 g) Antenna Connection type: SMA jack...

  • Page 9: Interfaces

    AT commands for the GPRS USB wireless modem are published in a separate GPRS AT Commands Reference Guide included on the MultiModem CD and posted on the Multi-Tech web site. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 2 – Installation...

  • Page 10: Chapter 2 - Activation And Installation

    Multi-Tech – A Certified National Activation Agent Multi-Tech Systems, Inc. is a certified national activation agent for Cingular and Sprint wireless. For more information about available data plans and to purchase and activate a wireless data account, contact Multi-Tech at 888-288-5470.

  • Page 11: Step 3 - Connect The Antenna And Usb Cable

    Connect one end of the USB cable to the modem and the other end to the PC. Step 4 – Handset Connection (Optional) If you intend to use a phone handset, connect it to the MultiModem now. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem...

  • Page 12: Step 5 - Attach The Modem To A Flat Surface (Optional)

    Slide the mounting brackets into the corresponding slots on the backside of the MultiModem chassis. Attach the MultiModem with two screws to the mounting surface at the desired location on the equipment. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem...

  • Page 13: Step 6 - Install The Modem Driver

    The Found New Hardware Wizard screen now displays the TUSB3410 Serial Port device. This is the first of three New Hardware Wizards that will appear. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem...
  • Page 14 USB driver is now complete. The second Found New Hardware wizard will start automatically to associate the PC port with the USB driver. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem...
  • Page 15 The association between the serial port and the USB driver has been made. Click Finish. The third Found New Hardware wizard will start automatically to install the modem inf file. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem...
  • Page 16 The Completing the Found New Hardware Wizard screen appears. Click Finish. With the modem .inf file successfully installed, the entire software installation procedure for the Wireless USB MultiModem is complete. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem...

  • Page 17: Installing The Modem Driver In Windows 2000

    Click on Search for a suitable driver for my device (recommended) Click Next. The Locate Driver Files screen appears. Click in the Optional search locations: on CD-ROM drive option. Click Next. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem...
  • Page 18 Installation of the USB driver is now complete. The second Found New Hardware wizard will start automatically to associate the PC port with the USB driver. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem...
  • Page 19 USB driver has been made. Click Finish. The third Found New Hardware Wizard will start automatically to install the modem INF file. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem...
  • Page 20 The Completing the Found New Hardware Wizard screen appears. Click Finish. With the modem .inf file successfully installed, the entire software installation procedure for the Wireless USB MultiModem is complete. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem...

  • Page 21: Chapter 3 - Using Your Wireless Modem

    The software version displays. For example: 651_09gg... • Type ATI6 Displays modem data features. For example: data rates, data modes, fax classes. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Modem Network Registration Verification Chapter 2 – Activation and Installation...

  • Page 22: Establishing A Voice Call

    Disconnect: Type: +++ Wait about one second to see an OK response. Then type: ATH Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem (Operation not allowed) • The phone number you are calling is entered between the displayed brackets.

  • Page 23: Using Short Message Services (Sms)

    Note: The x represents an index location. The n stands for the type of messages to delete. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem "REC UNREAD" Shows received unread messages.

  • Page 24: Sms Examples

    (set to Phase 2) +CSMS: 1,1,1 at+cnmi=2,2,0,0,0 (set to receive SMS and route directly to TE) +CMT: "+17632273726",,"06/03/17,13:59:18+00" (message received and directly routed to TE) TEST2 Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem...
  • Page 25 (set to Phase 2+) +CSMS: 1,1,1 at+cnmi=2,2,0,0,0 (set to receive SMS and route directly to TE) +CMT: "+17632273726",,"06/03/17,14:01:17+00" (message received and directly routed to TE) TEST3 at+cnma (acknowledge that message has been received) Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide...

  • Page 26: Internet Access

    Multi-Tech Systems, Inc. will not be responsible for any charges on your cellular bill. If you have any questions about billing, service plans, service charges, etc., please contact your provider for more information.
  • Page 27 Scroll up and click on Disconnect. Your should now be disconnect from the Internet. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 3 – Using Your Wireless Modem Important: Make sure that Use...

  • Page 28: Mobile Phonetools

    PC and use it for making Internet connections, voice calls, SMS messaging, and email. This program allows you to use your wireless modem hooked up to your PC as if it were a cell phone. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide...

  • Page 29: Chapter 4 - Troubleshooting And Frequently Asked Questions

    (esp. for voice communication) Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 4 – Troubleshooting and Frequently Asked Questions Action In communications program, verify that modem parameters have been set to the values shown here:...

  • Page 30: Frequently Asked Questions

    • In PDU mode using 7-bit, the modem still supports 160 characters, but in 8-bit the modem will support only 70 characters. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 4 – Troubleshooting and Frequently Asked Questions...
  • Page 31 Here is an example of how to send an SMS message to an email account: AT+CMGS=”0000” > email@multitech.com My message goes here. <ctrl +Z> Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 4 – Troubleshooting and Frequently Asked Questions...

  • Page 32: Chapter 5 - Reference Information

    GSM 07.01,GSM 07.02, GSM 07.05, GSM 07.07. ETSI contact: ETSI Secretariat F-06921 Sophia Antipolis Cedex, France e-mail: secretariat@etsi.fr Service: The AT commands manual is available on the Multi-Tech web site: http://www.multitech.com Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Chapter 5 – Reference Information...

  • Page 33: Appendix A - Warranty And Repairs

    Multi-Tech Warranty Statement Multi-Tech Systems, Inc., (hereafter “MTS”) warrants that its products will be free from defects in material or workmanship for a period of two, five, or ten years (depending on model) from date of purchase, or if proof of purchase is not provided, two, five, or ten years (depending on model) from date of shipment.
  • Page 34 You can place an order with SupplyNet via mail, phone, fax or the Internet at the following addresses: Mail: SupplyNet, Inc. 614 Corporate Way Valley Cottage, NY 10989 Phone: 800 826-0279 Fax: 914 267-2420 Email: info@thesupplynet.com Internet: http://www.thesupplynet.com Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide Appendix A – Warranty and Repairs...

  • Page 35: Appendix B - Waste Electrical And Electronic Equipment (Weee) Statement

    For more information about where you can drop off your waste equipment for recycling, please contact your local city office, your household waste disposal service or where you purchased the product. Multi-Tech Systems, Inc. MultiModem GPRS USB Wireless Modem User Guide...
