Qty Designator
1 U10
2 U18, U22
1 U4
2 SW2, SW3
2 S2, S3
1 S6
1 U5
1 U7
60 TP1 to TP6, TP8 to TP10, TP12 to
TP15, TP17, TP19 to TP23, TP25 to
TP52, TP54 to TP60, TP62, TP64 to
TP68
Description
110 Ω AES/EBU transformer
Buffer, three-state, single gate
Octal, three-state buffer/driver
SPDT slide switch PC mount
8-position SPST SMD switch, flush, actuated
Tact switch, 6 mm gull wing
15 Mb/sec fiber optic receiving module
with shutter
Fiber optic transmit module, 15 Mb/sec
Mini test point, white, 0.1 inch, OD
Rev. 0 | Page 29 of 32
Manufacturer Part Number
Scientific SC937-02
Conversion
Texas Instruments SN74LVC1G125DRLR
Texas Instruments SN74LVC541ADBR
E-Switch EG1218
CTS Corp 219-8LPST
Tyco/Alcoswitch FSM6JSMA
Toshiba TORX147L(F,T)
Toshiba TOTX147L(F,T)
Keystone 5002
