Evaluation Board User Guide
Qty Designator
16 R56, R57, R65, R66, R88, R89, R140,
R154, R179, R183, R213, R216,
R228 to R231
8 C25, C31, C45, C53, C169, C181,
C190, C198
3 R3, R11, R58
1 C125
4 R5, R52, R53, R75
1 C120
33 R38
1 R129
8 C24, C34, C44, C56, C167, C185,
C189, C201
30 C11, C14, C22, C26, C27, C30, C32,
C35, C41, C46, C47, C52, C54, C57,
C63, C66, C72, C75, C80, C105,
C119, C133, C139, C148, C152,
C164, C172, C179, C191, C196
3 C12, C18, C19
4 R83, R96, R148, R163
20 R103, R104, R110 to R112, R116,
R119, R124, R126 to R128, R130 to
R132, R142 to R147
35 R8 to R10, R15 to R17, R19, R92,
R95, R100, R105, R113, R120, R125,
R133, R135, R139, R153, R155,
R156, R160, R174, R175, R178,
R187, R188, R190, R194, R196,
R200, R201, R203, R206, R210,
R215
16 R25, R26, R32, R34, R45, R46, R61,
R68, R181, R182, R192, R195, R208,
R209, R218, R220
16 R21 to R23, R27, R33, R35 to R37,
R39, R41, R42, R50, R62, R69 to
R71
1 C131
1 R138
16 R72, R73, R79, R85 to R87, R97,
R107, R121, R122, R137, R150 to
R152, R165, R171
4 C78, C137, C171, C195
1 U11
2 U19, U26
1 R29
1 R67
Description
Chip resistor, 24.9 Ω, 1%, 100 mW, thick film
(0603)
Multilayer ceramic capacitor, 50 V, NP0
(0603)
Chip resistor, 374 Ω, 1%, 100 mW, thick film
(0603)
Multilayer ceramic capacitor, 50 V, NP0
(0603)
Chip resistor, 392 Ω, 1%, 100 mW, thick film
(0603)
Multilayer ceramic capacitor, 16 V, ECH-U
(1206)
Chip resistor, 3.01 kΩ, 1%, 100 mW, thick
film (0603)
Chip resistor, 3.32 kΩ, 1%, 100 mW, thick
film (0603)
Multilayer ceramic capacitor, 50 V, NP0
(0603)
Aluminum electrolytic capacitor, 16 V,
FC, 105 deg, SMD_D
Aluminum electrolytic capacitor, FC, 105
deg, SMD_E
Chip resistor, 49.9 kΩ, 1%, 100 mW, thick
film (0603)
Chip resistor, 49.9 kΩ, 1%, 63 mW, thick film
(0402)
Chip resistor, 49.9 kΩ, 1%, 100 mW, thick
film (0603)
Chip resistor, 49.9 kΩ, 1%, 100 mW, thick
film (0603)
Chip resistor, 49.9 kΩ, 1%, 100 mW, thick
film (0603)
Multilayer ceramic capacitor, 25 V, NP0
(0603)
Chip resistor, 562 Ω, 1%, 125 mW, thick film
(0603)
Chip resistor, 5.76 kΩ, 1%, 125 mW, thick
film (0603)
Multilayer ceramic capacitor, 100 V, NP0
(0603)
IC inverter, hex, TTL/LSTTL, 14 SOIC
IC buffer, quad, three state, 14 SOIC
Chip resistor, 75 Ω, 1%, 100 mW, thick film
(0603)
Chip resistor, 90.9 Ω, 1% 100 mW, thick film
(0603)
Rev. 0 | Page 27 of 32
Manufacturer Part Number
Rohm MCR03EZPFX24R9
Rohm MCH185A271JK
Rohm MCR03EZPFX3740
Panasonic EC ECJ-1VC1H391J
Rohm MCR03EZPFX3920
Panasonic EC ECH-U1C393JB5
Rohm MCR03EZPFX3011
Rohm MCR03EZPFX3321
Murata ENA GRM1885C1H431JA01D
Panasonic EC EEE-FC1C470P
Panasonic EC EEE-FC1E470P
Panasonic EC ERJ-3EKF4992V
Rohm MCR01MZPF49R9
Panasonic EC ERJ-3EKF49R9V
Panasonic EC ERJ-3EKF4641V
Panasonic EC ERJ-3EKF4751V
TDK Corp C1608C0G1E562J
Panasonic EC ERJ-3EKF5620V
Panasonic EC ERJ-3EKF5761V
Panasonic EC ECJ-1VC2A680J
NXP Semi 74HC04D-T
Texas Instruments SN74LV125AD
Panasonic EC ERJ-3EKF75R0V
Rohm MCR03EZPFX90R9
UG-046
