Analog Devices EVAL-AD1974AZ User Manual page 28

UG-046
Qty Designator
1 Y1
1 U15
1 U23
1 U1
1 J2
1 J3
1 J4
2 J22, J23
1 U8
1 U13
2 D2, D5
1 S1
1 SW1
6 L2 to L7
1 L1
2 J1, J14
4 J15 to J18
1 J19
2 J20, J26
4 J5 to J8
2 S4, S5
19 JP4 to JP7, JP11 to JP14, JP17,
JP18, JP20 to JP22, JP24, JP26,
JP28 to JP31
11 JP1 to JP3, JP8 to JP10, JP15, JP19,
JP23, JP25, JP27
1 U16
1 D11
2 D6, D9
2 D7, D10
2 U2, U3
6 J10, J11, J13, J21, J27, J28
2 R161, R162
8 U6, U9, U12, U14, U17, U20, U24,
U25
1 U21
2 J9, J12
Description
Crystal, 12.288 MHz, SMT, 10 pF
Four ADC/eight DAC with PLL, 192 kHz, 24-
bit CODEC
Microprocessor voltage supervisor
Voltage regulator, low dropout
5-way binding post, black, uninsulated
base TH
5-way binding post, mini, green, uninsulated
base TH
5-way binding post, mini, red, uninsulated
base TH
SMA receptacle, straight PCB mount
192 kHz digital audio receiver (DGTL RCVR
28-TSSOP)
192 kHz digital audio interface (S/PDIF
transmitter)
Passivated rectifier, 1 A, 50 V, MELF
Switch slide, DP3T, PC MNT, L = 4 mm
DPDT slide switch, vertical
Chip ferrite bead, 600 Ω at 100 MHz
Chip ferrite bead, 600 Ω at 100 MHz
10-way shrouded polarized header
16-way unshrouded, not populated
Connector header, 0.100 dual STR, 72 POS
Connector header, 0.100 dual STR, 72 POS
Connector header, 0.100 dual STR, 72 POS
16-position rotary switch, hex
2-pin header, unshrouded jumper, 0.10";
use shunt Tyco 881545-2
3-position SIP header
Complex programmable logic devices
(CPLD), HI PERF, E2CMOS, PLD
Green, diffused, 10 millicandela, 565 nm
(1206)
Red, diffused, 6.0 millicandela, 635 nm
(1206)
Yellow, diffused, 4.0 millicandela, 585 nm
(1206)
3-terminal, adjustable voltage regulator,
DPak
Sterero mini jack, SMT
Resistor network, bussed 9 res
Dual bipolar/JFET audio op amp.
12.288 MHz fixed SMD oscillator, 1.8 V dc to
3.3 V dc
RCA jack, PCB, TH mount, R/A, yellow
Rev. 0 | Page 28 of 32
Evaluation Board User Guide
Manufacturer Part Number
Abracon Corp ABM3B-12.288MHZ-10-
1-U-T
Analog Devices AD1974YSTZ
Analog Devices ADM811RARTZ-REEL7
Analog Devices ADP3303ARZ-3.3
Deltron 552-0100 BLK
Components
Deltron 552-0400 GRN
Components
Deltron 552-0500 RED
Components
Amp-RF Division 901-144-8RFX
Cirrus Logic CS8416-CZZ
Cirrus Logic CS8406-CZZ
Micro Commercial DL4001-TP
E-Switch EG2305
E-Switch EG2207
TDK MPZ1608S601A
Steward HZ0805E601R-10
3M N2510-6002RB
3M N/A
Sullins PBC10DAAN; or cut
PBC36DAAN
Sullins PBC13DAAN; or cut
PBC36DAAN
Sullins PBC06DAAN; or cut
PBC36DAAN
APEM PT65503
Sullins PBC02SAAN; or cut
PBC36SAAN
Sullins PBC03SAAN; or cut
PBC36SAAN
Lattice LC4128V-75TN100C
Semiconductor
Lumex Opto SML-LX1206GW-TR
Lumex Opto SML-LX1206IW-TR
CML Innovative CMD15-21VYD/TR8
Tech
STMicroelectronics LM317MDT-TR
CUI SJ-3523-SMT
CTS 773091103
Analog Devices OP275GSZ
Abracon Corp AP3S-12.288MHz-F-J-B
Connect-Tech CTP-021A-S-YEL
Products
