2 .3 Rear Panel
1 3 B
The 3-pronged power plug is located at the Rear Panel of the MSL-3S79 as shown in
figure. The Switches will work with AC in the range 100-240V AC, 50-60Hz. The DC
redundant power jack is optional.
S tatus
1 1 2 B
Green
Link connected
Blink
The port is receiving or transmitting data.
Off
No device attached or Link is disconnected
Rear Panel of the MSL-3S79
10
Meaning
