2 B 6 .4.6.3 Logging Ram Table - LevelOne MSL-3S79 User Manual

Remote Logging, and SMTP Logging, the system will issue a log record to location
where user has designated. After configuring, click
Logging Event Level: 4 events – Cold Start Event, Warm Start Event, Auth
Failure Event, and Port Link Change Event. Pull down the right side item menu to
select the event level. When selected events occur, the system will issue the logs.
Cold Start Event: when the device executes cold start action, the system will
issue a log event.
Warm Start Event: when the device executes warm start, the system will
issue a log event.
Auth Failure Event: You get this trap if a network management system
(NMS) polls the device with the wrong community string.
Port Link Change Event: when the port link has changed, the system will
issue a log event.
6.4.6.3 Logging RAM Table
8 2 B
Logging RAM Table displays the logs which have been sent to RAM.
Logging Events Level interface
26
.
Apply
