Image Acquisition Control
Camera Model
acA640-90um/uc
acA640-120um/uc
acA1300-30um/uc
acA1600-20um/uc
acA1920-25um/uc
acA2000-165um/uc
acA2000-165umNIR
acA2040-90um/uc
acA2040-90umNIR
acA2500-14um/uc
acA3800-14um/uc
acA4600-10uc
Table 27: Exposure Start Delays
FTWait
Signal
ExFSTrig
Signal
Exposure
Frame N
Exposure
Frame
Readout
Frame
Transmission
Fig. 68: Exposure Start Controlled with an ExFSTrig Signal
142
Exposure Start Delay
22 µs
18 µs
35 µs
46 µs
35 µs
TBD µs (with frame acquisitions overlapped)
TBD µs(with frame acquisitions not overlapped)
848 to 883 µs (with frame acquisitions overlapped)
848 µs (with frame acquisitions not overlapped, or in
global reset release mode)
TBD µs (with frame acquisitions not overlapped, or in
global reset release mode)
TBD µs (with frame acquisitions not overlapped, or in
global reset release mode)
Exposure Start Delay
Exposure
Frame N+1
Frame N Sensor Readout
Transmission Start Delay
Frame N Transmission to Host PC
AW00123402000
Exposure Start Delay
Exposure
Frame N+2
Frame N+1 Sensor Readout
Transmission Start Delay
Frame N+1 Transmission to Host PC
Timing charts are not drawn to scale
