UG-358

ORDERING INFORMATION

BILL OF MATERIALS

Table 1.
Quantity Reference Designator
1 C1
2 C2, C4
1 C3
1 C5
4 CANH, TXD, VDD2SENSE, VREF
2 CANL, RXD
2 GND1, GND2
4 J1, J3, J4, J7
1 J2
2 J5, J6
2 LK1, LK2
1 R1
2 RT1, RT2
1
U1
2 VDD1, VDD2

RELATED LINKS

Resource
ADM3054
Description
Capacitor, tantalum, 22 µF, TAJ_C
Capacitor, 100 nF, 0805
Capacitor, 47 nF, 0805
Not placed/optional
Test point, yellow
Test point, green
Test point, black
Terminal block, 2-way
Terminal block, 4-way
Connector, SMB jack
4-pin (2 × 2) 0.1" header and shorting block
Resistor, 0 Ω, 0805
Resistor, 30 Ω, 0805
16-lead SOIC, wide body
Test point, red
Description
Product Page, 5 kV rms Signal Isolated High Speed CAN Transceiver with Bus Protection
Rev. 0 | Page 6 of 8
Evaluation Board User Guide
Supplier/Part Number
AVX Corporation/TAJC226K016RNJ
Yageo (Phycomp)/CC0805KRX7R7BB104
Multicomp/MCCA000270
N/A
Vero Technologies/20-313140
Vero Technologies/20-313138
Vero Technologies/20-2137
Lumberg/KRM 02
Lumberg/KRM 04
Multicomp/24-14-2-TGG
Harwin/M20-9953646 & M7566-05
Vishay Draloric/MC 0.063W 0603 0R
Multicomp/MCPWR05FTFW0300
Analog Devices/ADM3054BRWZ
Vero Technologies/20-313137
