Wiring Information

2 Wire Digital Communication Wiring Information

V-C6124P
24 volt outputs
+
- + -
+
-
*V-C6124P and the V-CCU are ordered as
a V-VCU
V-WMCA Master Clock
18 19
18 19
19 18
DATA IN
V-CCU
24 VDC IN
2 W ire Digital
Output to Clocks
+
- + -
+
-
110V
(EU 240V)
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019
V-C6124P and the V-CCU
are ordered as a V-VCU
White
Black
V-A2412 or V-A2416
V-D2425 or V-D2440
White
Black
V-A2412 or V-A2416
540-563-2000 P.
540-362-9800 F.
www.valcom.com
