Owner's Operator And Maintenance Manual
T-3
DEALER/PROVIDER: THIS MANUAL MUST BE GIVEN TO
THE USER OF THE WHEELCHAIR.
USER: BEFORE USING THIS WHEELCHAIR, READ THIS
MANUAL AND SAVE FOR FUTURE REFERENCE.
For more information regarding
Invacare products, parts, and services,
please visit www.invacare.com
™
Tennis Adjustable
T-3
Tennis Elite
™
T-3
Titanium
™
T-4
Tennis Elite
™
T-4
Titanium
™
®
