Invacare® Top End
Terminator™
Terminator™ Titanium
This manual MUST be given to the user of the product.
BEFORE using this product, read this manual and save for future reference.
Everyday Series
®
User Manual
Manuel d'utilisation
Gebruikershandleiding
Gebruiksaanwijzing
EN
FR
DE
NL

Advertisement

Table of Contents
loading

Related Manuals for Invacare Top End Everyday Series

Summary of Contents for Invacare Top End Everyday Series

  • Page 1 Invacare® Top End Everyday Series ® Terminator™ Terminator™ Titanium User Manual Manuel d’utilisation Gebruikershandleiding Gebruiksaanwijzing This manual MUST be given to the user of the product. BEFORE using this product, read this manual and save for future reference.
  • Page 2 © 2011 Invacare Corporation. All rights reserved. Republication, duplication or modification in whole or in part is prohibited without prior written permission from Invacare. Trademarks are identified by ™ and ®. All trademarks are owned by or licensed to Invacare Corporation or its subsidiaries unless otherwise noted.

  • Page 3: Table Of Contents

    Reaching, Leaning and Bending Forward ......................................23 Reaching, Leaning and Bending Backwards ....................................23 Tipping ..................................................23 Tipping - Curbs..............................................24 Stairways ................................................25 Transferring To and From Other Seats......................................26 SAFETY INSPECTION/TROUBLESHOOTING Part No 1171801 Invacare® Top End® Everyday Series...
  • Page 4 Adjusting Wheelbase Length (Adjusting Center of Gravity)..............................56 Adjusting Wheelbase Width ..........................................58 Replacing Axle Tube ............................................59 Adjusting the Axle Tube .............................................62 Replacing/Adjusting Casters..........................................65 Wheel Lock Adjustment/Replacement......................................66 SEAT Replacing Adjustable Tension Seat Upholstery .....................................67 FOOTREST/ANTI-TIPPER Invacare® Top End® Everyday Series Part No 1171801...
  • Page 5 Adjusting/Replacing Footrest..........................................69 Installing/Adjusting Optional Clamp on Raised Footrest................................70 Replacing/Adjusting Optional Adjustable Angle One Piece Footplate ............................ 70 Adjusting/Replacing Anti-Tipper........................................71 Installing/Removing/Adjusting Swivel Anti-Tip ....................................73 SUSPENSION Elastomers and Suspension..........................................75 Part No 1171801 Invacare® Top End® Everyday Series...

  • Page 6: General

    Indicates a hazardous situation that could result in damage to property if it is not avoided.  Gives useful tips, recommendations and information for efficient, trouble-free use. Dealer/Technician Information The term “qualified technician” in this manual refers to an Invacare qualified technician. Invacare® Top End® Everyday Series Part No 1171801...

  • Page 7: Warranty Information

    (seat and back) and remaining components of this product when purchased new and unused to be free from defects in materials and workmanship for a period of thirteen (13) months from date of purchase from Invacare or a dealer, with a copy of the seller’s invoice required for coverage under this warranty.
  • Page 8 La seule obligation d’Invacare et le seul recours du bénéficiaire de la garantie se limitera à ces réparations et/ou remplacements. Pour un service au titre de la garantie, l’acheteur doit contacter le distributeur auprès duquel il a acheté le produit Invacare. Si l’acheteur ne juge pas le service de garantie satisfaisant, il doit écrire directement à...

  • Page 9: European Limited Warranty Information And Customer Service

    Tel: (351) (0)225 1059 46/47, Fax: (351) (0)225 1057 39 portugal@invacare.com, www.invacare.pt España: Invacare SA, c/Areny s/n, Polígon Industrial de Celrà, E-17460 Celrà (Girona) Sverige & Suomi: Tel: (34) (0)972 49 32 00, Fax: (34) (0)972 49 32 20 Invacare AB, Fagerstagatan 9, S-163 91 Spånga contactsp@invacare.com, www.invacare.es...

  • Page 10: Overview

    2 OVERVIEW 2 Overview Label Locations  Serial number label located underneath seat. The weight capacity label is on the camber tube. Refer to Weight Capacity on page 21. Terminator Terminator Titanium Invacare® Top End® Everyday Series Part No 1171801...

  • Page 11: Typical Product Parameters

    Primo 25-540 (Standard), 24x1-3/8-inch (60.69x3.5 cm), KIK®, Knobby Primo 25-540 (Standard) 25-INCH: Primo 25-559 (Standard), KIK, Knobby Primo 25-559 (Standard) 26-INCH: Primo 25-590 (Standard), 26x1-3/8-inch (60.96x3.5 cm) Primo 25-590 (Standard) 700C: Special Turbo (Standard) Part No 1171801 Invacare® Top End® Everyday Series...
  • Page 12 350 lbs (158.76 kg) with Heavy Duty Package  15 x 15-inch seat, rear wheels and minimal options are included in the weight. * Refer to Tire Pressure Conversion on page 15. All specifications are approximate Invacare® Top End® Everyday Series Part No 1171801...
  • Page 13 Primo 25-559 (Standard) 26-INCH: Primo 25-590 (Standard), 26x1-3/8-inch (60.69x3.5 cm) Primo 25-590 (Standard) 700C: Special Turbo (Standard) HANDRIMS: Aluminum Welded Tab (Standard) Plastic Coated, Natural Fit®, Titanium Aluminum Welded Tab (Standard), Titanium Part No 1171801 Invacare® Top End® Everyday Series...
  • Page 14 400 lbs (181.44 kg) with Heavy Duty Package  15 x 15-inch seat, rear wheels and minimal options are included in the weight. * Refer to Tire Pressure Conversion on page 15. All specifications are approximate Invacare® Top End® Everyday Series Part No 1171801...

  • Page 15: Component Identification

    Footrest Rear Wheel Rear Wheel Footrest Tire Pressure Conversion  PSI rating is printed on the side of the tire. Conversion formula: 1 psi = 6.895 kPa (approx. 7 kPa). KILOPASCALS KILOPASCALS Part No 1171801 Invacare® Top End® Everyday Series...
  • Page 16 2 OVERVIEW Invacare® Top End® Everyday Series Part No 1171801...

  • Page 17: Safety

    NOTICE THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. Check all parts for shipping damage and test before using. In case of damage, DO NOT use. Contact Invacare/Carrier for further instruction. Invacare® Top End® Everyday Series...

  • Page 18: Stability Warning

    FOOTREST POSITION    CAMBER TUBE    BACK ANGLE     BACK UPHOLSTERY    USER CONDITION      Part No 1171801 Invacare® Top End® Everyday Series...

  • Page 19: Operating Information

    DO NOT stand on the frame of the wheelchair. Check all allen screws that secure the footrest/raised footrest system to the chair frame before using the wheelchair, especially if engaging in any contact sport. Invacare® Top End® Everyday Series Part No 1171801...
  • Page 20 Invacare DOES NOT recommend the use of its wheelchairs as a weight training apparatus. Invacare wheelchairs have not been designed or tested as a seat for any kind of weight training. If occupant uses said wheelchair as a weight training apparatus, Invacare shall not be liable for bodily injury and the warranty is void.

  • Page 21: Weight Capacity

    WARNING Camber Tube Weight Capacity Invacare's Top End Everyday and Terminator Titanium wheelchairs have a weight capacity of 250 lbs (113.4 kg). Invacare’s Terminator Everyday wheelchairs with the heavy duty option have a weight capacity of 350 lbs (158.7 kg).

  • Page 22: Percentage Of Weight Distribution

    Shortening the wheelbase will decrease the stability, increase the maneuverability and distribute additional weight onto the rear wheels. Center of Gravity Rear of Wheelchair Lengthening the Wheelbase Shortening the Unoccupied Occupied Wheelbase Part No 1171801 Invacare® Top End® Everyday Series...

  • Page 23: Reaching, Leaning And Bending Forward

    At this point, the assistant will feel a difference in the weight distribution. Turn the wheelchair in the desired direction if necessary. Slowly lower the wheelchair in one continuous movement. Part No 1171801 Invacare® Top End® Everyday Series...

  • Page 24: Tipping - Curbs

    3.11 Tipping - Curbs WARNING Invacare does not recommend that sport wheelchairs be used where traversing curbs present an obstacle. Possible injury to occupant and/or assistant(s) can occur. Transfer to an everyday use wheelchair is recommended if any such obstacles may be encountered.

  • Page 25: Stairways

    Extreme caution is advised when it is necessary to move an occupied wheelchair up or down a stairway. Invacare recommends that, if possible, the user be removed from the wheelchair prior to moving. Invacare recommends using two assistants and making thorough preparations.

  • Page 26: Transferring To And From Other Seats

    Engage wheel locks. Shift body weight into seat with transfer. During independent transfer, little or no seat platform will be beneath you. Use a transfer board if at all possible. Invacare® Top End® Everyday Series Part No 1171801...
  • Page 27 3 SAFETY Part No 1171801 Invacare® Top End® Everyday Series...

  • Page 28: Safety Inspection/Troubleshooting

    Ensure adjustable axle position camber bar is securely tightened. ❑ Ensure quick/quad release axles lock properly. ❑ Ensure no excessive side movement or binding when lifted and spun. ❑ Inspect handrims for signs of rough edges or peeling. Invacare® Top End® Everyday Series Part No 1171801...
  • Page 29 Inspect wheel/fork assembly for proper tension by spinning caster; caster should come to a gradual stop. ❑ Inspect tires for flat spots and wear. ❑ If pneumatic tires check for proper inflation. ❑ Ensure casters are free of debris. Part No 1171801 Invacare® Top End® Everyday Series...
  • Page 30 ❑ Ensure wheel bearings are clean and free of moisture. ❑ Ensure casters are free of debris. ❑ Check that all labels are present and legible. Replace if necessary. Invacare® Top End® Everyday Series Part No 1171801...

  • Page 31: Troubleshooting

    DO NOT use WD-40®, 3-in-1 oil, or other penetrating lubricants on quick-release axles or camber inserts. Otherwise, binding and/or damage to the handcycle can occur. Clean/oil quick-release axles and camber inserts once a week with a Teflon® lubricant. Part No 1171801 Invacare® Top End® Everyday Series...
  • Page 32 Invacare customer support at the telephone numbers on the back of this manual. Regularly check for loose spokes in the front and rear wheels. If loose, have them adjusted. Contact a qualified technician or Invacare customer support at the telephone numbers on the back of this manual.
  • Page 33 4 SAFETY INSPECTION/TROUBLESHOOTING Part No 1171801 Invacare® Top End® Everyday Series...

  • Page 34: Back

    To fold the back, pull up on the back release cord and push the back posts forward toward the front of the wheelchair.  Back upholstery removed for clarity. Part No 1171801 Invacare® Top End® Everyday Series...

  • Page 35: Back Angle Adjustment

    -4°. Flip the adjustment square over to obtain back angles of -8°, 4° and 0°. When adjusted properly, the back should have a small amount of movement when locked in the open position. Plunger pins should snap in and release easily without resistance. Part No 1171801 Invacare® Top End® Everyday Series...
  • Page 36 (Details “A” and “C”). Adjustment Mounting screw secures the adjustment square Square from the other side of the plate DETAIL Jam Nut Back Cane Placement Screw “B” Back Angle Plate Invacare® Top End® Everyday Series Part No 1171801...
  • Page 37 11. Completely tighten jam nut up against bottom of back cane Back Angle Plate (Detail “D”).  Back angle plate, mounting screw and adjustment square are removed for clarity. DETAIL Back Cane “D” Jam Nut Mounting Screw Seat Rail Part No 1171801 Invacare® Top End® Everyday Series...
  • Page 38 Seat Rail OPTION 1 OPTION 2 Back Angle Back Cane Back Angle Plate Plate Adjustment 83° 0° Adjustment square to be square to be positioned at 0° Seat positioned at 0° Rail Invacare® Top End® Everyday Series Part No 1171801...
  • Page 39 Back Angle Back Cane Plate Adjustment square to be positioned at +4° +4° 87° Seat Rail Back Cane Back Angle Plate 91° +8° Adjustment square to Seat Rail be positioned at +8° Part No 1171801 Invacare® Top End® Everyday Series...

  • Page 40: Removing/Installing Foldover Back Upholstery

    Wrap the fastening flap around the back post again and press firmly to secure. Fold the top of the back upholstery down over the back posts towards the front of the wheelchair. Press firmly to secure the fastening strips. Invacare® Top End® Everyday Series Part No 1171801...

  • Page 41: Adjustable Tension Back Upholstery

    The second is to keep the cushion from sliding out of the back of the wheelchair. • The third is a sacral support depending upon how far or tight the flap is pulled under the seat cushion. Part No 1171801 Invacare® Top End® Everyday Series...
  • Page 42 Slip adjuster straps through corresponding anchor loops and adjust the back upholstery. Secure with the fastening straps. Loop Back Post Upper Grommet Back Upholstery Anchor Hole Loop Section Mounting Screw Back Upholstery Adjuster Strap Section Invacare® Top End® Everyday Series Part No 1171801...

  • Page 43: Back Height Adjustment (Adjustable Backs Only)

    Ensure that both back post inserts are at the same height BEFORE reassembling the wheelchair. Press the push pin on the back post insert tube in and adjust the back height to one of four heights depending on original back height: Part No 1171801 Invacare® Top End® Everyday Series...
  • Page 44 The fastening flap with logo is for the left back post. Right and left is determined by sitting in the wheelchair. Back Post Reinstall the fastening flaps onto the back posts. Adjust the new back upholstery to the desired tautness. Invacare® Top End® Everyday Series Part No 1171801...
  • Page 45 5 BACK Part No 1171801 Invacare® Top End® Everyday Series...

  • Page 46: Wheels

    Quad-Release Axle are the same as Quick-Release Axle. Keep locking pins clean. If there is too much movement of the rear wheel assembly in a back and forth motion, refer to Part No 1171801 Invacare® Top End® Everyday Series...

  • Page 47: Adjusting Quick-Release Axles

    Repeat STEPS 1-7 for the opposite wheel. Rear Wheel Hub Locking Collar  End of Quick Release axle is shown for reference only. It is not visible when inserted into camber bar. Invacare® Top End® Everyday Series Part No 1171801...

  • Page 48: Adjusting Quad-Release Handles

    With the rear wheel and quad-release axle still mounted on the (On Quick-Release Axle) Rear Wheels wheelchair, tighten the length adjusting screw until there is no in and out movement of the quad-release axle and rear wheel. Part No 1171801 Invacare® Top End® Everyday Series...

  • Page 49: Handrim Replacement

    DO NOT ride on a flat or underinflated tires. Riding on flat or underinflated tires can cause injury, as well as, damage to the tire, tube and wheels. Inflate the tire to the recommended psi. Part No 1171801 Invacare® Top End® Everyday Series...

  • Page 50: Repairing/Replacing Rear Wheel Tire/Tube

    If replacing rear wheels with a different size than what was originally on the wheelchair, the front caster height must also be changed to keep the wheelchair frame parallel to the floor. Refer to Replacing/Adjusting Casters on page 65 ONLY after contacting Invacare.
  • Page 51 Side View of Standard Side View of Quick Camber Clamp Camber Clamp Release Lever Camber Clamp Camber Insert Camber Clamp Quick Closed Position Release Socket Screw Lever Camber Clamp Open Position Hex Screw Axle Tube Part No 1171801 Invacare® Top End® Everyday Series...

  • Page 52: Adjusting Rear Wheel Camber

    Close the camber clamp. Refer to Repeat STEPS 1-8 for opposite side of wheelchair. 10. Install rear wheel to the wheelchair. Refer to 11. Adjust toe in/toe out of wheelchair. Refer to Invacare® Top End® Everyday Series Part No 1171801...

  • Page 53: Determining Toe In/Toe Out

    Top View of Top View of Front of Wheelchair Front of Wheelchair Toe-out Wheelchair Wheelchair 12-inches (30.48 cm) Toe-in Rear of Wheelchair Smaller than Front Larger than Front Centerlines of Rear Wheels Part No 1171801 Invacare® Top End® Everyday Series...

  • Page 54: Adjusting Toe In/Toe Out

    Rotate either the right or left adjustment ring until the stop on the ring is at the top of the slot in the camber clamp as shown and securely tighten the Phillips screw on the positioned adjustment ring. Invacare® Top End® Everyday Series Part No 1171801...
  • Page 55 Adjustment Ring Adjustment Ring Camber Clamp Camber Clamp Stop - In position for one camber, touching Adjustment Ring camber clamp Stop - Not touching Adjustment Ring camber clamp Part No 1171801 Invacare® Top End® Everyday Series...

  • Page 56: Adjusting Wheelbase Length (Adjusting Center Of Gravity)

    Shortening the Wheelbase - Will decrease the stability, increase the maneuverability and distribute additional weight onto the rear wheels.  Wheelchair performance will be affected if the camber clamps DO NOT sit flush on the wheelchair frame. Invacare® Top End® Everyday Series Part No 1171801...
  • Page 57 If drag to either side occurs, Refer to Determining Toe In/Toe Out. Hex Screw - Loosen But DO NOT Back Post Remove Hex Screws Top Clamp Lengthening Wheelchair Frame Axle Tube Axle Tube Shortening Clamp Hex Screw - Loosen But DO NOT Remove Part No 1171801 Invacare® Top End® Everyday Series...

  • Page 58: Adjusting Wheelbase Width

    Repeat STEPS 2-3 for the opposite axle nut and axle bolt.  Axle bolt removed from axle tube for clarity. It is not necessary to remove the axle both for this procedure. Axle Bolt Camber Clamp Invacare® Top End® Everyday Series Part No 1171801...

  • Page 59: Replacing Axle Tube

    Adjustable Camber System Only - Note the position of the camber inserts so they can be installed at the same position in the new axle tube. Open the camber clamps. Remove the two rear wheels. Adjustable Camber System Only - Remove the camber inserts positioned in the axle tube. Part No 1171801 Invacare® Top End® Everyday Series...
  • Page 60 To maximize rollability: Before using the wheelchair, make sure both camber inserts are set to the same indexing notch. This will make sure the distance between the rear wheel and the wheelchair is the same on both sides. 14. Install the rear wheels onto the wheelchair. 15. Adjust the axle tube. Invacare® Top End® Everyday Series Part No 1171801...
  • Page 61 The performance of the wheelchair will be affected if the toe in/toe out of the wheelchair is not correct. Suspension option not shown for clarity. Axle tube installs in the same manner as pictured above. Part No 1171801 Invacare® Top End® Everyday Series...

  • Page 62: Adjusting The Axle Tube

    90° angle with the ground/floor as shown. Place “L” Square Here Close both camber clamps. 90° Angle Determine the toe in/toe out of the wheelchair. Ground/ Floor Flat Edge of Camber Tube Invacare® Top End® Everyday Series Part No 1171801...
  • Page 63 Loosen the set screw on the right toe adjustment ring. iii. Repeat STEP 3. Repeat STEPS 12-16 until toe in/toe out measurement is within ±1/8 (.32 cm) inch. 17. If desired, reposition camber inserts to the desired degree of camber. Part No 1171801 Invacare® Top End® Everyday Series...
  • Page 64 Stopped Ring Against Lower Edge of Camber Right Toe Adjustment Ring Clamp Camber Clamp Camber Right Tab Clamp Stopped Against Upper Edge of Camber Clamp Axle Tube - Will Rotate Up only Invacare® Top End® Everyday Series Part No 1171801...

  • Page 65: Replacing/Adjusting Casters

    Changing the size/type of and/or repositioning the front size of the rear wheels may also need adjustment. casters can affect the performance of the wheelchair. Non-Suspension Caster Contact Invacare at the telephone numbers on the back of this manual before performing this procedure. Fork Locknut Bolt ...

  • Page 66: Wheel Lock Adjustment/Replacement

    6 WHEELS 6.17 Wheel Lock Adjustment/Replacement Rear Front Wheelchair Frame Invacare recommends low mount wheel locks when  engaging in any contact sport. Low Mount Before adjusting or replacing the High/Low mount wheel Wheel Lock locks, ensure that the tires are inflated to the recommended psi on the sidewall of the tire.

  • Page 67: Seat

    Slip front adjuster strap through corresponding anchor loop and adjust the seat upholstery to desired tension. Secure the adjustment straps. Crossbar Securely latch the four remaining adjuster straps together. Reinstall the seat cushion and back upholstery. Part No 1171801 Invacare® Top End® Everyday Series...
  • Page 68 7 SEAT Invacare® Top End® Everyday Series Part No 1171801...

  • Page 69: Footrest/Anti-Tipper

    If replacing the footrest, remove existing footrest. Frame Position the new or existing footrest to the desired height on the wheelchair frame. Tighten the allen screws that secure the new footrest to the wheelchair frame. Footrest Part No 1171801 Invacare® Top End® Everyday Series...

  • Page 70: Installing/Adjusting Optional Clamp On Raised Footrest

    Loosen, but DO NOT remove the four flat screws and locknuts that secure the footplate to the footrest tubes. Position the footplate to the necessary angle to accommodate the user. Tighten the four flat screws and locknuts. Invacare® Top End® Everyday Series Part No 1171801...

  • Page 71: Adjusting/Replacing Anti-Tipper

    Anti-tippers MUST be attached at all times. Inasmuch as the anti-tippers are an option on this wheelchair (you may order it with or without the anti-tippers), Invacare strongly recommends ordering the anti-tippers as an additional safeguard for the wheelchair user.
  • Page 72 If necessary, adjust the height of the anti-tippers. DETAIL“A” - Top Adjustment Hole ANTI-TIPPER ADJUSTMENT HOLES Anti-Tipper Bar Release Buttons Hole Anti-Tipper Camber Clamp Ground/ 1-1/2 to 2 inch Anti-Tipper Floor (53.66 cm) Socket Clearance Invacare® Top End® Everyday Series Part No 1171801...

  • Page 73: Installing/Removing/Adjusting Swivel Anti-Tip

    To adjust the height of the swivel anti-tip, remove dust cover and loosen set screw on swivel anti-tip caster assembly. Set anti-tip caster wheel to desired height. Tighten set screw and reinstall dust cover. Part No 1171801 Invacare® Top End® Everyday Series...
  • Page 74 8 FOOTREST/ANTI-TIPPER Anti-Tippers Anti-Tipper Receiver Set Screw Anti-Tipper  Detail view from rear of wheelchair. Invacare® Top End® Everyday Series Part No 1171801...

  • Page 75: Suspension

    Use an allen wrench to hold the outer allen screw in position. Mounting Holes Recess 10. While holding the outer allen screw, install the inner allen screw into the pivot pin. Tighten securely. 11. Release when desired speed is achieved. Part No 1171801 Invacare® Top End® Everyday Series...
  • Page 76 Threaded Sleeve become disassembled. Possible injury or damage could occur. Apply Loctite 242 to the mounting screw. Reinstall the mounting screw into the threaded sleeve and tighten securely. Invacare® Top End® Everyday Series Part No 1171801...
  • Page 77 9 SUSPENSION Part No 1171801 Invacare® Top End® Everyday Series...
