Owner's Operator and Maintenance Manual
®
Everyday Series Wheelchairs
Top End® Terminator™ Everyday
Top End® Terminator™Everyday w/ Heavy Duty Package
Top End®Terminator™Titanium
Top End® Terminator Titanium w/ Heavy Duty Package
Sport Series Wheelchairs
Top End®Transformer™All Sport
Top End®Rugby QR.2G
Top End® Paul Schulte Signature BB
Top End® T-5™Tennis Elite
Top End® Pro™Tennis
Top End® Pro™BB
DEALER: This manual MUST be given to
the user of the wheelchair.
USER: BEFORE using this wheelchair, read
this manual and save for future reference.
For more information regarding
Invacare products, parts, and services,
please visit www.invacare.com
Advertisement
Table of Contents
Related Manuals for Invacare Top End
Summary of Contents for Invacare Top End
- Page 1 ® Everyday Series Wheelchairs Top End® Terminator™ Everyday Top End® Terminator™Everyday w/ Heavy Duty Package Top End®Terminator™Titanium Top End® Terminator Titanium w/ Heavy Duty Package Sport Series Wheelchairs Top End®Transformer™All Sport Top End®Rugby QR.2G Top End® Paul Schulte Signature BB Top End®...
- Page 2 OTHERWISE INJURY AND/OR EQUIPMENT DAMAGE MAY OCCUR. ACCESSORIES WARNING Invacare products are specifically designed and manufactured for use in conjunction with Invacare accessories. Accessories designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products.
-
Page 3: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS SPECIAL NOTES ....................5 TYPICAL PRODUCT PARAMETERS ..............6 Tyre Pressure Conversion..............................13 SECTION 1—GENERAL GUIDELINES ..............14 Stability Warning ................................. 14 Operating Information ............................... 14 Tyre Pressure and Information ............................15 Weight Training................................... 16 Weight Limitation ................................ - Page 4 Adjusting Toe In/Toe Out..............................37 Adjusting Wheelbase Length (Adjusting Center of Gravity) ..................39 Adjusting Center of Gravity - Top End Pro Tennis/ Top End Pro BB..............40 Adjusting Center of Gravity (T-5/Paul Schulte Signature BB) .................. 42 Adjusting Wheelbase Width............................. 42 Replacing Axle Tube ................................
-
Page 5: Special Notes
If signs of wear appear, belt MUST be replaced immediately. Because TOP END wheelchairs are made to the specifications of the original owners it is unlikely that refurbished product would be suitable to other user’s needs. -
Page 6: Typical Product Parameters
Typical Product Parameters TYPICAL PRODUCT PARAMETERS NOTE: All specifications are approximate. TERMINATOR EVERYDAY (ED) TERMINATOR TITANIUM FRAME: Rigid - 6061-T6 Aluminum Rigid - 3-2.5 Titanium SEAT WIDTH: 12-18 inches (30.48 - 45.7 cm) Outside to Outside of seat frame in 1inch (2.54 cm) increments SEAT DEPTH: 14 to 18 (35.56 - 45.7 cm) inches SEAT-TO-FLOOR:... - Page 7 Typical Product Parameters TERMINATOR EVERYDAY (ED) TERMINATOR TITANIUM 24-INCH (STANDARD): Primo (25-540): 1inch High Pressure Grey Clincher (Standard) Kenda: 1 inch High Pressure Clincher (Optional) Schwable 1 inch Black Flat Resistant (Optional) 24 x 1 inch (60.69x3.5 cm) Grey Treaded (Optional) 24 x 1 inch (60.69x3.5 cm) w/ Flat Free (Optional) Solid 1 inch no-Flat (Optional)
- Page 8 Typical Product Parameters TRANSFORMER ALL-SPORT FRAME: Rigid - 606IT6 Aluminium SEAT WIDTH: 12-20 inches (30.48 - 50.8 cm) - Outside to Outside of SEAT FRAME in 1-inch increments SEAT DEPTH: 12 to 20-inches (30.48 - 50.8 cm) SEAT-TO-FLOOR: TALL FRAME: Front - 18 to 21-inch (45.72 - 53.34 cm), Rear -15 to 21-inch (38.1 - 53.34 cm) SHORT FRAME Front - 16 to 18-inch (40.64 - 45.72 cm), Rear -15 to 18-inch (38.1 - 45.72 cm)
- Page 9 Typical Product Parameters TRANSFORMER ALL-SPORT FRONT FORKS: Non-Suspension (Standard) CASTOR SIZE: 3-inch (7.62 cm) BACK UPHOLSTERY: U240 Black - Foldover, Adjustable Tension (Optional) WEIGHT: 24 lbs. (10.89 kg) SHIPPING WEIGHT: 30 lbs. (13.6 kg) WEIGHT LIMITATION: 250 lbs. (113.40 kg) NOTE: 15 x 15‐inch seat, rear wheels and minimal options are included in the weight.
- Page 10 Typical Product Parameters RUGBY QR.2G FRAME: Rigid - 6061-T6 Aluminum SEAT WIDTH: 14 - 21 inches (35.56 - 53.34 cm) - Outside to outside of seat frame in 1-inch (2.54 cm) increments SEAT DEPTH: 14 to 18 (35.56 - 45.72 cm) inches SEAT-TO-FLOOR: Front - 14.5 to 21 inch (36.83 - 53.34 cm) Rear -13 to 19.5 inch (33.02 - 49.53 cm)
- Page 11 Typical Product Parameters PAUL SCHULTE SIGNATURE BB/T-5 TENNIS ELITE FRAME: Rigid - 6061T6 Aluminum or 3-2.5 Titanium SEAT WIDTH: 14 - 21 inches (35.56 - 53.34 cm) - Outside to outside of seat frame in 1-inch (2.53 cm) increments SEAT DEPTH: 14 to 18-inches (35.56 - 45.72 cm) SEAT-TO-FLOOR: Front - 14...
- Page 12 Typical Product Parameters TOP END PRO TENNIS AND TOP END PRO BB FRAME: Rigid - 6061T6 Aluminum SEAT WIDTH: 12-20 inches (30.48 - 50.8 cm) - Outside to Outside of SEAT FRAME in 1-inch (2.53 cm) increments SEAT DEPTH: 14 to 18-inches (35.56 - 45.72 cm) SEAT-TO-FLOOR: Front - 19 to 21-inch (48.26 - 53.34 cm), Rear -15 to 21-inch (38.10 - 53.34 cm)
-
Page 13: Tyre Pressure Conversion
Typical Product Parameters Tyre Pressure Conversion NOTE: PSI rating is printed on the side of the tyre. NOTE: Conversion formula: 1 psi = 6.895 kPa (appox. 7 kPa). KILOPASCALS KILOPASCALS Part No 1122172 Everyday Series Wheelchairs/Sport Series Wheelchairs... -
Page 14: Section 1-General Guidelines
SECTION 1—GENERAL GUIDELINES SECTION 1—GENERAL GUIDELINES WARNING SECTION 1 - GENERAL GUIDELINES contains important information for the safe operation and use of this product. Stability Warning The position of the footrest, camber tube, back angle, the tautness of the back upholstery as well as the userʹs condition are directly related to the wheelchairs stability. Any change to one or any combination of the five may cause the wheelchair to decrease in stability. Use extreme caution when using a new seating position. The addition of anti‐tippers may be required. ✓ ✓ ● FOOTREST POSITION ✓ ✓ CAMBER TUBE ● ✓... -
Page 15: Tyre Pressure And Information
SECTION 1—GENERAL GUIDELINES DO NOT use an escalator to move a wheelchair between floors. Serious bodily injury may occur. Before attempting to transfer in or out of the wheelchair, every precaution should be taken to reduce the gap distance. Turn both castors parallel to the object you are transferring onto. Also be certain the wheel locks are engaged to prevent the wheels from moving. DO NOT operate on roads, streets or highways. DO NOT climb, go up or down ramps or traverse slopes greater than 9°. DO NOT attempt to move up or down an incline with a water, ice or oil film. DO NOT attempt to ride over curbs or obstacles. Doing so may cause your wheelchair to turn over and cause bodily harm or damage to the wheelchair. DO NOT attempt to lift the wheelchair by any removable (detachable) parts. Lifting by means of any removable (detachable) parts of a wheelchair may result in injury to the user or damage to the wheelchair. DO NOT stand on the frame of the wheelchair. Check all allen screws that secure the footrest/raised footrest system to the chair frame before using the wheelchair, especially if engaging in any contact sport. Anti‐tippers MUST BE attached at all times. Inasmuch as the anti‐tippers are an option on this wheelchair (you may order with or without the anti‐tippers), Invacare strongly recommends ordering the anti‐tippers as an additional safeguard for the wheelchair user. Anti‐tippers MUST be used at all times. When outdoors on wet, soft ground or on gravel surfaces, anti‐tippers may not provide the same level of protection against tip over. Extra caution MUST be observed when traversing such surfaces. Unless otherwise noted, all service and adjustments should be performed while the wheelchair is unoccupied. ALWAYS wear your seat positioning strap. Inasmuch as the SEAT POSITIONING STRAP is an option on this wheelchair (You may order with or without the seat positioning strap), Invacare Top End strongly recommends ordering the seat positioning strap as an additional safeguard for the wheelchair user. The seat positioning strap is a positioning belt only. It is not designed for use as a safety device withstanding high stress loads such as auto or aircraft safety belts. If signs of wear appear, belt MUST be replaced immediately. ALWAYS use the handrims for self‐propulsion. Inasmuch as the handrims are an option on this wheelchair (you may order with or without the handrims), Invacare strongly recommends ordering the handrims as an additional safeguard for the wheelchair user. DO NOT use the footplate as a platform when getting in or out of the wheelchair. The bumper design creates a potential foot entrapment area. Ensure the occupant’s legs and feet are properly secured during use. When transferring the occupant, ensure the feet do not slip between the bumper and the footrests. -
Page 16: Weight Training
SECTION 1—GENERAL GUIDELINES Weight Training Invacare DOES NOT recommend the use of its wheelchairs as a weight training apparatus. Invacare wheelchairs have not been designed or tested as a seat for any kind of weight training. If occupant uses said wheelchair as a weight training apparatus, Invacare shall not be liable for bodily injury and the warranty is void. Weight Limitation Invacareʹs Top End Everyday and Sport Series wheelchairs (Terminator Titanium, Terminator Everyday, Paul Schulte Signature BB, T‐5 Tennis Elite, Top End Pro Tennis, Top End Pro BB, Rugby QR.2G and Transformer All Sport) have a weight limitation of 250 lbs (113.4 kg). Terminator Everyday wheelchairs with the heavy duty option have a weight limitation of 350 lbs (158.76 kg). Terminator Titanium wheelchairs with the heavy duty option have a weight limitation of 400 lbs (181.44 kg). A weight limitation label is on the camber tube of the chair. Weight Capacity Label Camber Tube FIGURE 1.1 Weight Capacity Label Everyday Series Wheelchairs/Sport Series Wheelchairs Part No 1122172... -
Page 17: Section 2-Safe Handling
ALWAYS wear your seat positioning strap. Inasmuch as the SEAT POSITIONING STRAP is an option on this wheelchair (you may order with or without the seat positioning strap), Invacare strongly recommends ordering the seat positioning strap as an additional safeguard for the wheelchair user. -
Page 18: Percentage Of Weight Distribution
SECTION 2—SAFE HANDLING Percentage of Weight Distribution WARNING DO NOT attempt to reach objects if you have to move forward in the seat or pick them up from the floor by reaching down between your knees. The position of the footrest, camber tube, back angle, the tautness of the back upholstery Center of Gravity as well as the user's condition are directly... -
Page 19: Tipping
Tipping - Curbs WARNING Invacare does not recommend that sport wheelchairs be used where traversing curbs present an obstacle. Possible injury to occupant and/or assistant(s) can occur. Transfer to an everyday use wheelchair is recommended if any such obstacles may be encountered. -
Page 20: Stairways
Extreme caution is advised when it is necessary to move an occupied wheelchair up or down a stairway. Invacare recommends that, if possible, the user be removed from the wheelchair prior to moving. Invacare recommends using two assistants and making thorough preparations. Make sure to use ONLY secure, non-detachable parts for hand-held supports. -
Page 21: Section 3-Safety Inspection
SECTION 3—SAFETY INSPECTION SECTION 3—SAFETY INSPECTION NOTE: Every six months, take your wheelchair to a qualified technician for a thorough inspection and servicing. Regular cleaning will reveal loose or worn parts and enhance the smooth operation of your wheelchair. To operate properly and safely, your wheelchair must be cared for just like any other vehicle. Routine maintenance will extend the life and efficiency of your wheelchair. Clean upholstery with mild soap and water or spray disinfectant using a sponge. DO NOT use bleach or wash in a washing machine. Safety Inspection Checklist WARNING In cases of inactivity longer then six months, a comprehensive initial inspection MUST be per- formed. Initial adjustments should be made to suit your personal body structure and preference. Thereafter follow these maintenance procedures: Inspect Initially ❑ Ensure wheelchair rolls straight (no excessive drag/pull to one side). ❑ Ensure wheel locks DO NOT interfere with tyres when rolling. ❑ Ensure pivot points are free of wear and looseness. ❑... - Page 22 SECTION 3—SAFETY INSPECTION Inspect/Adjust Weekly ❑ Ensure hand grips (if equipped) are not loose. ❑ Ensure quick release axles and camber inserts are clean. ❑ Ensure quick/quad release axles lock properly. ❑ Inspect handrims for signs of rough edges or peeling. ❑ Inspect spokes for bent or broken spokes. ❑ Ensure All spokes uniformly tight. CAUTION As with any vehicle, the wheels and tyres should be checked periodically for cracks and wear, and should be replaced if damaged. ❑...
-
Page 23: Troubleshooting
SECTION 3—SAFETY INSPECTION ❑ Ensure wheel bearings are clean and free of moisture. ❑ Ensure castors are free of debris. ❑ Check that all labels are present and legible. Replace if necessary. Troubleshooting CHAIR VEERS CHAIR SLUGGISH CASTOR SQUEAKS LOOSENESS SOLUTIONS RIGHT VEERS LEFT TURN OR FLUTTERS IN CHAIR PERFORMANCE RATTLES Check tyres for correct and equal pressure. Check for loose stem nuts. Check spokes and nipples. - Page 24 The recommended tyre pressure is on the sidewall of the tyre. Recommended tyre pressure is listed on the sidewall of the tyre. NOTE: Refer to Tyre Pressure Conversion on page 13 for correct metric measurement. CAUTION As with any vehicle, the wheels and tyres should be checked periodically for cracks and wear, and should be replaced if damaged. The wheels, castors and tyres should be checked periodically for cracks and wear, and should be replaced when necessary. Contact a qualified technician or Invacare customer support at the telephone numbers on the back of this manual. Regularly check for loose spokes in the rear wheels. If loose, have them adjusted. Contact a qualified technician or Invacare customer support at the telephone numbers on the back of this manual. Periodically check handrims to ensure they are secured to the rear wheels. Refer to Handrim Replacement on page 34. Periodically adjust wheel locks as tyres wear. Refer to Wheel Lock Adjustment/Replacement on page 48. ®...
-
Page 25: Section 4-Back
SECTION 4—BACK SECTION 4—BACK WARNING ALWAYS perform these procedures in the presence of an assistant. The position of the footrest, camber tube, back angle, the tautness of the back upholstery as well as the user's condition are directly related to the wheelchairs stability. Any change to one or any combination of the five may cause the wheelchair to decrease in stability. - Page 26 SECTION 4—BACK 95° Back Angle to Seat Rail 90° Back Angle to Seat Rail Back Post Back Post Indexing Indexing Notch Notch TOP Hex 75° Back Angle to Seat Rail Screw and TOP Hex Locknut Screw and Back Post Indexing Locknut Notch Back Angle Bracket...
- Page 27 SECTION 4—BACK Secure the adjustment square to the back angle plate with the mounting screw. Tighten securely. Repeat STEPS 2‐6 for remaining back cane. WARNING After unfolding the back, ensure that the plunger pins are fully engaged in the mounting holes of the adjustment square in the back angle plates (Detail “A”). Otherwise, serious injury could result. Unfold the back until the plunger pins lock into the mounting holes in the adjustment square. 10. Unthread the mounting screw until head of screw rests on seat rail (Detail “F”). 11.
- Page 28 SECTION 4—BACK DESIRED SEAT ANGLE ADJUSTMENT SQUARE POSITION NUMERICAL GRAPHICAL Back Cane Back Angle Plate 75° Adjustment -8° square to be positioned at -8° Seat Rail Back Angle Back Cane Plate Adjustment square to be 79° -4° positioned at -4° Seat Rail OPTION 2 Back Cane...
-
Page 29: Removing/Installing Foldover Back Upholstery
SECTION 4—BACK Removing/Installing Foldover Back Upholstery WARNING The position of the footrest, seat angle, back angle, seating system/upholstery, castor size and position, rear wheel size and position, use of anti-tippers, as well as the user condition directly relate to the stability of the wheelchair. Any change to one or any combination of the ten may cause the wheelchair to decrease in stability. -
Page 30: The Adjustable Tension Straps
SECTION 4—BACK The Adjustable Tension Straps The straps can be adjusted at various levels of tension to accommodate individual end‐users. The bottom two straps can be adjusted tightly to support and/or assist the extensor Back Posts muscles. The Back Upholstery Cover NOTE: The back upholstery cover is designed for three reasons: Back Upright • The first is as a modesty cover. • The second is to keep the cushion from sliding out of the back of the wheelchair. Back Height Adjustment Screw • The third is a sacral support depending upon how far or tight the flap is pulled under the seat cushion Replacing Adjustable Tension Back Upholstery Fastening Strap Remove the back height adjustment screws that secure Back Upholstery Cover the back posts to the back uprights. ... -
Page 31: Back Height Adjustment (Adjustable Backs Only)
SECTION 4—BACK 12. Adjust the slack in the back upholstery cover and then secure to the seat pan fastening straps. Back Height Adjustment (Adjustable Backs Only) NOTE: For this procedure, refer to FIGURE 4.7 on page 31 NOTE: Observe the tautness of the back upholstery for reinstallation. Unlatch the two fastening flaps that secure the top of the back upholstery to the back posts and remove from the back posts. WARNING Push pin MUST be protruding through hole in back post. Ensure that both back post inserts are at the same height BEFORE reassembling the wheelchair. Press the push pin on the back post insert tube in and adjust the back height to one of four heights depending on original ... -
Page 32: Section 5-Wheels
SECTION 5—WHEELS SECTION 5—WHEELS WARNING After any adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may result. Removing/Installing Rear Wheels CAUTION Changing the size of the rear wheels can affect the performance of the wheelchair. Contact Inva- care at the telephone numbers on the back of this manual before changing rear wheel size. -
Page 33: Replacing Quad-Release Axles
SECTION 5—WHEELS Replacing Quad-Release Axles NOTE: For this procedure, refer to FIGURE 5.3. Remove rear wheel and the existing quick‐release axle from the wheelchair. Refer to Removing/Installing Rear Wheels on page 32. Remove existing quick‐release axle from rear wheel. Allen Screw Quick-Release Insert new quad‐release axle through rear wheel hub. Axle Slide locking collar onto quad‐release axle until it is snug against rear wheel and tighten securely with allen screw. Reinstall rear wheel and the quad‐release axle onto the wheelchair. Refer to Removing/Installing Rear Wheels on page 32. Flip the handle of the quad‐release axle down to release Rear Wheel Locking the detent pin ensuring that the locking pins are fully Collar released. NOTE: End of Quick Release axle is shown for reference only. It If detent pin does not fully release, proceed to Adjusting Quad‐Release Handles on page 33. is not visible when inserted into camber bar. FIGURE 5.3 Replacing Quad-Release Axles Repeat STEPS 1‐7 for the opposite rear wheel. -
Page 34: Handrim Replacement
Changing the size of the rear wheels can affect the performance of the wheelchair. Contact Inva- care at the numbers on the back cover before performing this procedure. NOTE: If replacing rear wheels with a different size than what was originally on the wheelchair, the front castor height must also be changed to keep the wheelchair frame parallel to the floor. Refer to Adjusting Front Castor Height ‐ Transformer Only on page 48 ONLY after contacting Invacare. Anti‐tipper height (if applicable) must also be adjusted to maintain 1‐1/2 to 2‐inch (3.81 to 5.08 cm) clearance between bottom of the anti‐tipper wheels and the floor. Refer to Adjusting/Replacing Anti‐Tipper on page 56. Opening/Closing Camber Clamps WARNING STANDARD AND SUSPENSION CAMBER CLAMPS - Make sure the hex screws are securely tightened before using wheelchair, otherwise personal injury or damage to the wheelchair may occur. -
Page 35: Adjusting Rear Wheel Camber
SECTION 5—WHEELS CAUTION ADJUSTABLE CAMBER SYSTEM only - DO NOT close the quick-release levers or tighten the socket screws or hex screws without camber inserts in the axle tube. Damage to the axle tube will occur. NOTE: For this procedure, refer to FIGURE 5.6 on page 35. Perform one of the following to open a camber clamp: • Quick Release Levers ‐ Pull the quick release lever to the open position. -
Page 36: Determining Toe In/Toe Out
SECTION 5—WHEELS WARNING NEVER position the camber inserts in the axle tube with more than 3-inches (7.62 cm) (12 index- ing marks showing) of the camber insert outside of the axle tube. The camber inserts will not be securely tightened in the axle tube. Possible injury to the user and/or damage to the wheelchair may occur. -
Page 37: Adjusting Toe In/Toe Out
SECTION 5—WHEELS Adjusting Toe In/Toe Out Camber Tube With Single Camber NOTE: For this procedure, refer to FIGURE 5.9. Open the camber clamps. Refer to Opening/Closing Camber Tube - Rotates Up and Down Camber Clamps on page 34. Slowly rotate the camber tube in either direction until the rear wheels are approximately in a straight line. Close the camber clamps. Refer to Opening/Closing Camber Clamps on page 34. Measure the distance between the center lines at the rear and front of the rear wheels at approximately 12 inches (30.48 cm) from the ground/floor. Refer to Camber Clamps Determining Toe In/Toe Out on page 36. Repeat STEPS 1‐4 until the toe in/toe out measurement FIGURE 5.9 Adjusting Toe In/Toe Out - Camber Tube is less than 1/2‐inch (1.27 cm) (0 + 1/4‐inch (.63 cm) for ... -
Page 38: Fine Adjustment
SECTION 5—WHEELS Stop - In position for one camber, Stop - Not touching touching camber clamp camber clamp Adjustment Ring Adjustment Ring Camber Clamp Camber Clamp Stop - In position for one camber, touching camber clamp Adjustment Ring Stop - Not touching Adjustment Ring camber clamp FIGURE 5.11 Adjusting Toe In/Toe Out - Adjustable Camber System - Course Adjustment... -
Page 39: Adjusting Wheelbase Length (Adjusting Center Of Gravity)
FIGURE 5.13 Adjusting Toe In/Toe Out - Adjustable Camber System - Fine Adjustment Adjusting Wheelbase Length (Adjusting Center of Gravity) All Models Except Top End Pro Tennis/Top End Pro BB WARNING ALWAYS perform this procedure in the presence of an assistant. The position of the footrest, camber tube, back angle, the tautness of the back upholstery as well as the user's condition are directly related to the wheelchairs stability. -
Page 40: Adjusting Center Of Gravity - Top End Pro Tennis/ Top End Pro Bb
Shortening Clamp Hex Screw - Loosen But DO NOT Remove FIGURE 5.14 Adjusting Wheelbase Length (Adjusting Center of Gravity) Adjusting Center of Gravity - Top End Pro Tennis/ Top End Pro BB NOTE: For this procedure, refer to FIGURE 5.15. If necessary, remove the seat upholstery. Refer to Replacing Adjustable Tension Seat Upholstery on page 50 or Replacing Screw‐On Seat Upholstery. on page 50. Review the following chart and determine the correct COG mounting position and then proceed to STEP 3. COG Mounting Position... - Page 41 Coved Washers Spacer Base Mounting Screw, Two Frame Base Washers, Coved Spacer Mounting Screw Frame and Locknut FIGURE 5.15 Adjusting Center of Gravity - Top End Pro Tennis/ Top End Pro BB Part No 1122172 Everyday Series Wheelchairs/Sport Series Wheelchairs...
-
Page 42: Adjusting Center Of Gravity (T-5/Paul Schulte Signature Bb)
SECTION 5—WHEELS Adjusting Center of Gravity (T-5/Paul Schulte Signature BB) NOTE: For this procedure, refer to FIGURE 5.16. If necessary, remove the seat upholstery. Refer to Replacing Adjustable Tension Seat Upholstery on page 50 or Replacing Screw‐On Seat Upholstery. on page 50. Remove the four mounting screws, coved spacers, washers and locknuts that secure the two backrest mounting brackets to the base frame. Secure backrest mounting brackets to the base frame in the desired mounting holes in the backrest mounting bracket and the mounting holes in the base frame with four mounting screws, coved spacers, washers and locknuts. Tighten securely. If necessary, install the seat upholstery. Refer to Replacing Adjustable Tension Seat Upholstery on page 50 or Replacing Screw‐On Seat Upholstery. on page 50. Mounting Holes in Base Frame Base Frame Coved Locknuts Spacers Backrest Mounting Bracket Mounting Holes in Washers Backrest Mounting Bracket... -
Page 43: Replacing Axle Tube
SECTION 5—WHEELS Axle Tube Camber Insert Axle Nut Threads Axle Bolt Camber Clamp FIGURE 5.17 Adjusting Wheelbase Width - Camber Tube With Single Camber Adjustable Camber System NOTE: For this procedure, refer to FIGURE 5.18 on page 43. Open the camber clamp. Refer to Opening/Closing Camber Clamps on page 34. WARNING NEVER position the camber inserts in the axle tube with more than 3 inches (7.62 cm) (12 indexing marks showing) of the camber insert outside of the axle tube. - Page 44 SECTION 5—WHEELS Pull the existing axle tube through one of the camber clamps. Adjustable Camber System Only ‐ Remove toe adjustment rings from the existing axle tube. Pull the existing axle tube through the other camber clamp and remove from the wheelchair. Slide the new axle tube through one of the camber clamps. NOTE: Adjustable Camber System Only ‐ Make sure the notches in the axle tube are towards the rear of the wheelchair and the slots in the axle tube are facing up. 10. Adjustable Camber System Only ‐ Install the adjustment rings onto the new axle tube. Make sure the stops on the adjustment rings are facing towards the outside of the wheelchair. NOTE: DO NOT tighten the phillips screws that secure the adjustment rings to the axle tube at this time. 11. Slide the new axle tube through the other camber clamp until the axle tube is evenly spaced between the camber clamps. NOTE: DO NOT close the camber clamps at this time. WARNING NEVER position the camber inserts in the axle tube with more than 3 inches (7.62 cm) (12 index- ing marks showing) of the camber insert outside of the axle tube. The camber inserts will not be securely tightened in the axle tube.
-
Page 45: Adjusting The Axle Tube
SECTION 5—WHEELS Adjusting the Axle Tube WARNING QUICK RELEASE LEVERS - Make sure the quick release levers are in the closed position before using the wheelchair, otherwise injury or damage to the wheelchair may occur. STANDARD and suspension camber clamps - Make sure the hex screws are securely tightened before using the wheelchair, otherwise injury or damage to the wheelchair may occur. -
Page 46: Replacing/Adjusting Castors
FIGURE 5.21 Adjusting the Axle Tube - Adjustable Camber System Replacing/Adjusting Castors CAUTION Changing the size/type of and/or repositioning the front castors can affect the performance of the wheelchair. Contact Invacare at the telephone numbers on the back of this manual before performing this procedure. NOTE: For this procedure, refer to FIGURE 5.22 on page 47. NOTE: Non‐suspension castors cannot be adjusted as they mount in one position only. ... - Page 47 SECTION 5—WHEELS Perform one of the following: • Non‐Suspension Fork ‐ Remove the bolt and locknut that secure the front castor to the fork. • Suspension Fork ‐ Perform the following steps: Using two allen wrenches, turn in opposite directions and remove one mounting screw from the fork. ii. Remove the mounting screw/threaded sleeve assembly that secures the front castor and two spacers to the fork. Remove front castor and axle spacers from fork. Perform one of the following: • Non‐Suspension Fork ‐ Install the new castor, bolt, locknut and axle spacers onto the fork and securely tighten. • Suspension Fork ‐ Perform the following steps: Determine the desired mounting hole for the castor installation. ii. Line up the front castor and two spacers with the mounting hole in the fork determined in STEP B‐i. iii. Reinstall the mounting screw/threaded sleeve assembly through the fork, front castor and two spacers. Refer to FIGURE 5.22 for hardware orientation. iv. Reinstall the mounting screw into the threaded sleeve and tighten securely. WARNING Both front castors MUST be positioned to the same corresponding mounting hole, otherwise injury or damage may occur. Repeat STEPS 1‐3 for the opposite castor if necessary.
-
Page 48: Adjusting Front Castor Height - Transformer Only
Locknut CAUTION Castor Housing Changing the height of the front/castors can affect the performance of the wheelchair. Con- tact Invacare at the telephone numbers on the Dust Cover back of this manual before performing this pro- cedure. Spacers “L” NOTE: For this procedure, refer to FIGURE 5.23. - Page 49 SECTION 5—WHEELS Rear Wheel Lock Adjustment Front Wheelchair Frame Wheelchair Frame Low Mount Wheel Lock Wheel Lock Wheel Lock Shoe Shoe Hex Screws High Mount Wheelchair Wheel Lock Rear Wheel Frame 5/32 to 5/16-inch Gap (.4 to .8 cm) Wheel Lock Shoe NOTE: High mount wheel lock shown for clarity NOTE: Rear wheel not shown for clarity.
-
Page 50: Section 6-Seat
SECTION 6—SEAT SECTION 6—SEAT WARNING After ANY adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may occur. Replacing Adjustable Tension Seat Upholstery WARNING The seat upholstery and/or cushion MUST be cleaned regularly and/or replaced if incontinence is fre- quent. -
Page 51: Adjusting Transformer Seat Height
SECTION 6—SEAT Adjusting Transformer Seat Height NOTE: For this procedure, refer to FIGURE 6.2 on page 51 Adjusting Front Seat Height Note the order of the mounting screw, coved washers, spacer, half clamps and mounting screw/threaded sleeve and their position on the wheelchair frame and footrest tubing (Detail ʺAʺ, FIGURE 6.2). Remove the mounting screw, coved washers, spacer, half clamps and mounting screw/threaded sleeve on both sides of the wheelchair. NOTE: The footrest tubing will slide once the hardware is removed. Raise/lower the front of the seat to the desired position. Adjust the footrest height if desired. Refer to Adjusting the Transformer Footrests on page 55. Align the footrest tubing adjustment holes with the desired wheelchair frame adjustment holes. Install the hardware removed in STEP 2 through the adjustment holes aligned in STEP 5. Securely tighten all hardware. Adjusting Rear Seat Height Loosen the two mounting screws on both sides of the front of the wheelchair (Detail ʺAʺ). Loosen the four adjustment screws on both sides of the rear of the wheelchair (Detail ʺBʺ). Adjust seat higher or lower to desired position. Use a tape measure or ruler to ensure that both sides are the same height. Securely tighten the four adjustment screws at the rear of the wheelchair and the two mounting screws at the front of the wheelchair. DETAIL “A” - FRONT VIEW Wheelchair Frame Coved Washer See Detail “A”... -
Page 52: Adjusting Seat Height For Top End Pro Tennis And Top End Pro Bb
Adjustment Screw Bracket Bracket Locknuts Washer Locknuts Mounting Mounting Screw Screw Washer FIGURE 6.3 Adjusting Seat Height for Top End Pro Tennis and Top End Pro BB - Adjusting Front/Rear Seat Height Everyday Series Wheelchairs/Sport Series Wheelchairs Part No 1122172... -
Page 53: Section 7-Footrest/Anti-Tipper
SECTION 7—FOOTREST/ANTI-TIPPER SECTION 7—FOOTREST/ANTI-TIPPER WARNING After ANY adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may occur. ALWAYS perform this procedure in the presence of an assistant. The position of the footrest, camber tube, back angle, the tautness of the back upholstery as well as the user's condition are directly related to the wheelchairs stability. -
Page 54: Replacing/Adjusting Optional Adjustable Angle One Piece Footplate
SECTION 7—FOOTREST/ANTI-TIPPER Installing Allen Wheelchair Frame Screws Install the two half clamps onto either side of the wheelchair frame approximately 2‐inches (5.08 cm) Half Clamp above existing footrest with two provided allen screws. Repeat for the opposite side of the wheelchair. Outside Raised Slide the clamp on raised footrest into the half clamps to Footrest the desired height. Footrest Hoop Securely tighten the four allen screws. FIGURE 7.2 Installing/Adjusting Optional Clamp on Raised Footrest Adjusting Loosen the four allen screws. Adjust clamp on raised footrest to the desired height. Securely tighten the four allen screws. Replacing/Adjusting Optional Adjustable Angle One Piece Footplate NOTE: For this procedure, refer to FIGURE 7.3 on page 54. -
Page 55: Adjusting The Transformer Footrests
SECTION 7—FOOTREST/ANTI-TIPPER Adjusting the Transformer Footrests NOTE: For this procedure, refer to FIGURE 7.4. Depth Remove the two mounting screws and locknuts that secure the footrest to the footrest clamp. Move footrest to desired depth. Align the holes in the footrest with the holes in the footrest clamp. Secure footrest to footrest clamp with two mounting screws. Securely tighten. Angle Loosen the two mounting screws in the footrest. Adjust the angle of the footrest. Retighten the two mounting screws. Tighten securely. Depth Angle Mounting Screws Mounting Screws Footrest Footrest Footrest Clamp Depth Footrest Adjustment Locknuts Holes FIGURE 7.4 Adjusting the Transformer Footrests Height Mounting Screw/ Threaded Sleeve Note the order of the mounting screw, coved washers, ... -
Page 56: Adjusting/Replacing Anti-Tipper
Anti-tippers MUST be attached at all times. Inasmuch as the anti-tippers are an option on this wheelchair (you may order it with or without the anti-tippers), Invacare strongly recommends ordering the anti-tippers as an additional safeguard for the wheelchair user. -
Page 57: Installing/Removing/Adjusting Swivel Anti-Tip
SECTION 7—FOOTREST/ANTI-TIPPER PART NUMBER MEASUREMENT 1112178 21 - 1/8-inches (53.66 cm) DETAIL“A” - ANTI-TIPPER ADJUSTMENT HOLES Top Adjustment Hole Anti-Tipper Bar Release Buttons Anti-Tipper Hole Camber Clamp Anti-Tipper Socket Ground/ 1-1/2 to 2 inch Floor (53.66 cm) Clearance FIGURE 7.6 Adjusting/Replacing Anti-Tipper Installing/Removing/Adjusting Swivel Anti-Tip NOTE: For this procedure, refer to FIGURE 7.7 on page 58. -
Page 58: Adjusting Height
Adjust the height of the anti‐tip caster fork assembly to the desired height by moving the bullet up or down. Securely tighten mounting screw and locknut. Bullet Mounting Screw Locknut Caster Fork Assembly FIGURE 7.8 Adjusting Height - Paul Schulte Signature BB, T-5 Tennis Elite Models, Top End Pro Tennis, and Top End Pro BB ONLY Everyday Series Wheelchairs/Sport Series Wheelchairs Part No 1122172... -
Page 59: Section 8-Suspension
SECTION 8—SUSPENSION SECTION 8—SUSPENSION WARNING After ANY adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may occur. NOTE: The following procedures are for wheelchairs with the suspension option ONLY. Elastomers and Suspension NOTE: The performance of the wheelchair will be affected if elastomers are not the same on both sides of the wheelchair. Replacing Rear Elastomers NOTE: For this procedure, refer to FIGURE 8.1 on page 59. Use an allen wrench to hold the outer allen screw. While holding the outer allen screw in position, remove the inner allen screw from the pivot pin. -
Page 60: Replacing Front Elastomers
SECTION 8—SUSPENSION Replacing Front Elastomers CAUTION DO NOT use excessive force when removing/installing the threaded sleeve from/onto the fork. Damage to the threaded sleeve may occur. NOTE: For this procedure, refer to FIGURE 8.2 on page 60. Using two allen wrenches, turn in opposite directions and remove one mounting screw from fork. NOTE: One mounting screw will not turn. Remove the threaded sleeve and mounting screw assembly from the fork. DO NOT use excessive force. Remove the existing elastomer from the fork. Install new elastomer determined in STEP 1 into fork. NOTE: Make sure the elastomer sits in the two recessed areas on the fork. Align the mounting holes in the upper and lower portion of the fork. Reinstall threaded sleeve and mounting screw assembly. DO NOT use excessive force. WARNING Use Loctite 242™when reinstalling the mounting screw into the threaded sleeve, otherwise the fork can become disassembled. -
Page 61: Section 9-Wing/Bumper
SECTION 9—WING/BUMPER SECTION 9—WING/BUMPER WARNING After any adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may occur. The bumper design creates a potential foot entrapment area. Ensure the occupant’s legs and feet are properly secured during use. - Page 62 NOTES NOTES Everyday Series Wheelchairs/Sport Series Wheelchairs Part No 1122172...
-
Page 63: Limited Warranty
For warranty service, please contact the dealer from whom you purchased your Invacare product. In the event you do not receive satisfactory warranty service, please write directly to Invacare Top End at the address on the back page. Provide dealer’s name, address, date of purchase, indicate nature of the defect and, if the product is serialized, indicate the serial number. - Page 64 CH-1196 Gland, Switzerland prohibited without prior written permission from Invacare. +44 22 354 6024 Trademarks are identified by ™ and ®. All trademarks are owned by or licensed to Invacare Corporation or its Invacare, USA subsidiaries unless otherwise noted. One Invacare Way Natural Fit is a registered trademark of Three Rivers.
