Owner's Operator and Maintenance Manual
®
Crossfire
Series
™
Wheelchairs
Crossfire T6
Crossfire Titanium
DEALER: This manual MUST be given to
the user of the wheelchair.
USER: BEFORE using this wheelchair, read
this manual and save for future reference.
For more information regarding
Invacare products, parts, and services,
please visit www.invacare.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Crossfire T6 and is the answer not in the manual?

Questions and answers

Related Manuals for Invacare Crossfire T6

Summary of Contents for Invacare Crossfire T6

  • Page 1 Crossfire T6 Crossfire Titanium DEALER: This manual MUST be given to the user of the wheelchair. USER: BEFORE using this wheelchair, read this manual and save for future reference. For more information regarding Invacare products, parts, and services, please visit www.invacare.com...
  • Page 2 AND/OR EQUIPMENT DAMAGE MAY OCCUR. ACCESSORIES WARNING Invacare products are specifically designed and manufactured for use in conjunction with Invacare accessories. Accessories designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products. NOTE: Updated versions of this manual are available on www.invacare.com. ™ Crossfire...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS SPECIAL NOTES ................6 TYPICAL PRODUCT PARAMETERS ............ 8 SECTION 1—GENERAL GUIDELINES ..........10 Stability Warning............................10 Operating Information..........................10 Tire Pressure and Information ......................12 Weight Training ............................12 Weight Limitation.............................12 SECTION 2—SAFE HANDLING ............13 Stability and Balance..........................13 Coping with Everyday Obstacles......................14 A Note to Wheelchair Assistants....................15 Reaching, Leaning and Bending - Forward..................15...
  • Page 4 TABLE OF CONTENTS TABLE OF CONTENTS Adjusting Footplate Angle........................26 Adjusting Footplate Depth.........................26 SECTION 5—ARMS ................. 27 Installing the Optional Swingaway Padded Armrest Socket Assembly ........27 Adjusting Swingaway Padded Armrest Height...................29 SECTION 6—BACK ................. 30 Unfolding/Folding the Back........................30 Back Angle Adjustment ...........................31 Adjustable Tension Back Upholstery ....................34 The Adjustable Tension Straps ......................34 The Back Upholstery Cover......................34...
  • Page 5 TABLE OF CONTENTS TABLE OF CONTENTS Adjusting Fork Tension ...........................52 Removing/Installing/Repositioning the Caster Assemblies..............53 Standard Forks............................53 Suspension Forks..........................53 Removing/Installing the Fork Assembly....................54 Removing Fork Assembly........................54 Installing Fork Assembly ........................55 Removing/Installing the Elastomers (Suspension Forks Only)..........................56 Removing the Elastomer ........................56 Installing the Elastomer........................56 SECTION 9—WHEEL LOCKS .............

  • Page 6: Special Notes

    CHANGE WITHOUT NOTICE. WARNING As a manufacturer of wheelchairs, Invacare endeavors to supply a wide variety of wheelchairs to meet many needs of the end user. However, final selection of the type of wheelchair to be used by an individual rests solely with the user and his/her healthcare professional capable of making such a selection.
  • Page 7 SPECIAL NOTES WARNING With regards to seat/chest positioning straps - it is the obligation of the DME dealer, therapists and other healthcare professionals to determine if a seat/chest positioning strap is required to ensure the safe operation of this equipment by the user.

  • Page 8: Typical Product Parameters

    TYPICAL PRODUCT PARAMETERS TYPICAL PRODUCT PARAMETERS NOTE: All specifications are approximate. CROSSFIRE T6 CROSSFIRE TITANIUM FRAME: 6061T6 Aluminum Grade 9 Titanium FRONT FRAME: Tapered front end (Standard), V-Style (Optional) FRONT FRAME ANGLE: 70°, 75°, 80°, 85° or 90° FOOTREST: Tubular footrest in same material as frame (Standard),...
  • Page 9 TYPICAL PRODUCT PARAMETERS CROSSFIRE T6 CROSSFIRE TITANIUM CASTERS CASTER SIZE: 3, 4 or 5-inch CASTER TYPE: Semi-pneumatic (Standard), Soft Roll or Lighted (Optional) ANTI-TIPPERS: Optional WEIGHT: 19.5 lbs 18.5 lbs SHIPPING WEIGHT: 30 lbs WEIGHT LIMITATION: 250 lbs NOTE: 16 x 16‐inch seat, rear wheels and minimal options are included in the weight. ™...

  • Page 10: Section 1-General Guidelines

    SECTION 1—GENERAL GUIDELINES SECTION 1—GENERAL GUIDELINES WARNING SECTION 1 - GENERAL GUIDELINES contains important information for the safe operation and use of this product. Stability Warning The position of the footrest, camber tube, back angle, the tautness of the back upholstery  as well as the userʹs condition are directly related to the wheelchairs stability. Any change  to one or any combination of the five may cause the wheelchair to decrease in stability.  Use EXTREME caution when using a new seating position. The addition of anti‐tippers  may be required. ✓ ✓ FOOTREST POSITION ● ✓ ✓ CAMBER TUBE ●...
  • Page 11 SECTION 1—GENERAL GUIDELINES DO NOT shift your weight or sitting position toward the direction you are reaching as the  wheelchair may tip over. DO NOT tip the wheelchair without assistance. DO NOT attempt to stop a moving wheelchair with wheel locks. Wheel locks are not  brakes. NEVER leave an unoccupied wheelchair on an incline. DO NOT use an escalator to move a wheelchair between floors. Serious bodily injury may  occur. Before attempting to transfer in or out of the wheelchair, every precaution should  be taken to reduce the gap distance. Turn both casters parallel to the object you are  transferring onto. Also be certain the wheel locks are engaged to prevent the wheels from  moving. DO NOT operate on roads, streets or highways. DO NOT climb, go up or down ramps or traverse slopes greater than 9°. DO NOT attempt to move up or down an incline with a water, ice or oil film. DO NOT attempt to ride over curbs or obstacles. Doing so may cause your wheelchair to  turn over and cause bodily harm or damage to the wheelchair. Invacare products are specifically designed and manufactured for use in conjunction with  Invacare accessories. Accessories designed by other manufacturers have not been tested  by Invacare and are not recommended for use with Invacare products. DO NOT attempt to lift the wheelchair by any removable (detachable) parts. Lifting by  means of any removable (detachable) parts of a wheelchair may result in injury to the user  or damage to the wheelchair. DO NOT stand on the frame of the wheelchair. Check all Allen screws that secure the footrest/raised footrest system to the wheelchair  frame before using the wheelchair, especially if engaging in any contact sport. Anti‐tippers MUST be used at all times. When outdoors on wet, soft ground or on gravel  surfaces, anti‐tippers may not provide the same level of protection against tip over. Extra  caution MUST be observed when traversing such surfaces. Inasmuch as the anti‐tippers  are an option on this wheelchair (you may order with or without the anti‐tippers),  Invacare strongly recommends ordering the anti‐tippers as an additional safeguard for  the wheelchair user. Unless otherwise noted, all service and adjustments should be performed while the  wheelchair is unoccupied. ALWAYS wear your seat positioning strap. Inasmuch as the seat positioning strap is an  option on this wheelchair (you may order with or without the seat positioning strap),  Invacare Top End strongly recommends ordering the seat positioning strap as an  additional safeguard for the wheelchair user. The seat positioning strap is a positioning ...

  • Page 12: Tire Pressure And Information

    SECTION 1—GENERAL GUIDELINES ALWAYS use the handrims for self‐propulsion. Inasmuch as the handrims are an option  on this wheelchair (you may order with or without the handrims), Invacare strongly  recommends ordering the handrims as an additional safeguard for the wheelchair user.  DO NOT use the footplate as a platform when getting in or out of the wheelchair. Tire Pressure and Information DO NOT use your wheelchair unless it has the proper tire pressure (p.s.i.). DO NOT  overinflate the tires. Failure to follow these suggestions may cause the tire to explode and  cause bodily harm. The recommended tire pressure is on the sidewall of the tire. Replacement of the tire or tube MUST be performed by a qualified technician. Weight Training Invacare DOES NOT recommend the use of its wheelchairs as a weight training  apparatus. Invacare wheelchairs have not been designed or tested as a seat for any kind  of weight training. If occupant uses said wheelchair as a weight training apparatus,  Invacare shall not be liable for bodily injury and the warranty is void. Weight Limitation Invacareʹs Top End Crossfire T6 and Crossfire Titanium wheelchairs have a weight  limitation of 250 lbs. ™ Crossfire Series Wheelchairs Part No 1134872...

  • Page 13: Section 2-Safe Handling

    MUST be replaced IMMEDIATELY. Anti-tippers MUST be attached at all times. Inasmuch as the anti-tippers are an option on this wheelchair (you may order with or without the anti-tippers), Invacare strongly recommends ordering the anti-tippers as an additional safeguard for the wheelchair user.

  • Page 14: Coping With Everyday Obstacles

    SECTION 2—SAFE HANDLING WARNING DO NOT attempt to reach objects if you have to move forward in the seat or pick them up from the floor by reaching down between your knees. The position of the footrest, camber tube, back angle, the tautness of the back upholstery as well as the user's condition are directly related to the wheelchair's stability.

  • Page 15: A Note To Wheelchair Assistants

    SECTION 2—SAFE HANDLING A Note to Wheelchair Assistants When assistance to the wheelchair user is required, remember to use good body  mechanics. Keep your back straight and bend your knees whenever tilting the wheelchair  or traversing curbs, or other impediments. WARNING DO NOT attempt to lift a wheelchair by lifting on any removable (detachable) parts. Lifting by means of any removable (detachable) parts of a wheelchair may result in injury to the user or damage to the wheelchair. Also, be aware of any removable (detachable) parts. These must NEVER be used to move ...

  • Page 16: Tipping

    Tipping - Curbs WARNING Invacare does not recommend that sport wheelchairs be used where traversing curbs present an obstacle. Possible injury to occupant and/or assistant(s) can occur. Transfer to an everyday use wheelchair is recommended if any such obstacles may be encountered.

  • Page 17: Stairways

    Extreme caution is advised when it is necessary to move an occupied wheelchair up or down a stairway. Invacare recommends that, if possible, the user be removed from the wheelchair prior to moving. Invacare recommends using two assistants and making thorough preparations.

  • Page 18: Transferring To And From Other Seats

    SECTION 2—SAFE HANDLING 5. If equipped, turn the anti‐tippers down. Refer to Footrest on page 24 in this manual. WARNING DO NOT use an escalator to move a wheelchair between floors. Serious bodily injury may occur. Transferring To and From Other Seats WARNING BEFORE attempting to transfer in or out of the wheelchair, every precaution should be taken to reduce the gap distance.

  • Page 19: Section 3-Safety Inspection

    SECTION 3—SAFETY INSPECTION SECTION 3—SAFETY INSPECTION NOTE: Every six months, take your wheelchair to a qualified technician for a thorough inspection  and servicing. Regular cleaning will reveal loose or worn parts and enhance the smooth operation  of your wheelchair. To operate properly and safely, your wheelchair must be cared for just like any  other vehicle. Routine maintenance will extend the life and efficiency of your wheelchair. Clean  upholstery with mild soap and water or spray disinfectant using a sponge. DO NOT use bleach or  wash in a washing machine. Safety Inspection Checklist CAUTION As with any vehicle, the wheels and tires should be checked periodically for cracks and wear, and should be replaced if damaged. Initial adjustments should be made to suit your personal body structure and preference.  Thereafter follow these maintenance procedures: Inspect Initially ❑...

  • Page 20: Inspect/Adjust Weekly

    SECTION 3—SAFETY INSPECTION ❑ Inspect wheel/fork assembly for proper tension by spinning caster; caster should come  to a gradual stop. ❑ Loosen/tighten locknut if wheel wobbles noticeably or binds to a stop.  ❑ Ensure wheel bearings are clean and free of moisture. ❑ Inspect tires for flat spots and wear. ❑ If pneumatic tires check for proper inflation. ❑ Check that all labels are present and legible. Replace if necessary. Inspect/Adjust Weekly ❑ Ensure wheel locks are easy to engage and prevent the wheels from moving. ❑ Ensure that the casters are free of debris. ❑ Ensure hand grips (if equipped) are not loose. ❑ Ensure quick release axles and camber inserts are clean. ❑ Ensure quick/quad release axles lock properly. ❑ Inspect handrims for signs of rough edges or peeling. ❑ Inspect spokes for bent or broken spokes. ❑ Ensure All spokes uniformly tight. ❑ Inspect wheel/fork assembly for proper tension by spinning caster; caster should come  to a gradual stop. ❑ Inspect tires for flat spots and wear. ❑ If pneumatic tires check for proper inflation. Inspect/Adjust Monthly ❑...

  • Page 21: Inspect/Adjust Periodically

    SECTION 3—SAFETY INSPECTION Inspect/Adjust Periodically ❑ Ensure wheelchair rolls straight (no excessive drag/pull to one side). ❑ Ensure wheel locks are easy to engage.  ❑ Ensure that the casters are free of debris. ❑ Inspect seat and back upholstery for rips or sagging.  ❑ Ensure camber bar mounting clamps are securely tightened. ❑ Ensure no excessive side movement or binding when lifted and spun.  ❑ Inspect handrims for signs of rough edges or peeling. ❑ Clean upholstery and armrests. ❑ Ensure wheel bearings are clean and free of moisture. ❑ Check that all labels are present and legible. Replace if necessary. Troubleshooting SOLUTIONS Check tires for correct and equal pressure. Check for loose stem nuts. Check spokes and nipples. Check that both casters contact the ground at the same time.

  • Page 22: Maintenance

    4. Recommended tire pressure is listed on the sidewall of the tire. CAUTION As with any vehicle, the wheels and tires should be checked periodically for cracks and wear, and should be replaced if damaged. 5. The wheels, casters and tires should be checked periodically for cracks and wear, and  should be replaced when necessary. Contact a qualified technician or Invacare  customer support at the telephone numbers on the back of this manual. ™ Crossfire Series Wheelchairs Part No 1134872...
  • Page 23 SECTION 3—SAFETY INSPECTION 6. Regularly check for loose spokes in the rear wheels. If loose, have them adjusted.  Contact a qualified technician or Invacare customer support at the telephone numbers  on the back of this manual. 7. Periodically check handrims to ensure they are secured to the rear wheels. Refer to  Handrim Replacement on page 43. 8. Periodically adjust wheel locks as tires wear. Refer to Replacing/Adjusting the Wheel  Locks on page 57. 9. Periodically check caster wheel bearings to make sure they are clean and free from  ® moisture. Use a Teflon  lubricant if necessary. 10. Check upholstery for sagging, rips or tears. 11. Clean upholstery with mild soap and water. 12. Replace any labels that are missing, worn or torn. ™ Part No 1134872 Crossfire Series Wheelchairs...

  • Page 24: Section 4-Footrest

    SECTION 4—FOOTREST SECTION 4—FOOTREST WARNING After ANY adjustments, repair or service and BEFORE use, make sure all attaching hardware is tightened securely - otherwise injury or damage may occur. ALWAYS perform this procedure in the presence of an assistant. The position of the footrest, camber tube, back angle, the tautness of the back upholstery as well as the user's condition are directly related to the wheelchairs stability.

  • Page 25: Installing/Adjusting Optional Clamp On Raised Footrest

    SECTION 4—FOOTREST Installing/Adjusting Optional Clamp on Raised Footrest NOTE: For this procedure, refer to FIGURE 4.2. Installing 1. Install the two half clamps onto either  Allen Wheelchair Frame side of the wheelchair frame  Screws approximately 2‐inches above existing  Half Clamp footrest with two provided allen  screws. Outside Raised Footrest 2. Repeat for the opposite side of the  Footrest Hoop wheelchair. 3. Slide the clamp on raised footrest into  FIGURE 4.2 Installing/Adjusting Optional the half clamps to the desired height. Clamp on Raised Footrest 4.

  • Page 26: Adjusting Footplate Angle

    SECTION 4—FOOTREST Adjusting Footplate Angle 1. Loosen, but DO NOT remove the two mounting screws and locknuts (not shown) that  secure the footplate to the two footrest tubes. 2. Position the footplate to the necessary angle to accommodate the user. 3. Retighten the two mounting screws and locknuts. NOTE: The locknuts should lie in the channel of the footplate clamp. Adjusting Footplate Depth 1. Remove the two mounting screws and locknuts (not shown) that secure footplate to  the footrest tubes. NOTE: Observe the angle of footplate for reinstallation. 2. Move the footplate to one of two mounting positions to accommodate the user. 3. Using the two mounting screws and locknuts, secure the footplate to the footrest  tubes. NOTE: The locknuts should lie in the channel of the footplate half clamp. Mounting Clamp Positions (Allen Wheelchair Screw) Frame Adjustments Depth Clamp (Allen Screw) Mounting Screws Angle Footrest Locknut...

  • Page 27: Section 5-Arms

    Arms SECTION 5—ARMS WARNING After ANY adjustments, repair or service and BEFORE use, make sure all attaching hardware is tightened securely - otherwise injury or damage may occur. DO NOT attempt to lift or tilt a wheelchair by using any removable (detachable) parts.
  • Page 28 Arms Short Mounting Screws Back Cane Mounting Bracket Washers Arm Socket Inch Mounting Screw Washer Wheelchair Locknuts Frame Washer Coved Arm Socket Washer Plate Washer Inch Locknut Mounting Screw FIGURE 1 Installing the Optional Swingaway Padded Armrest Socket Assembly ™ Crossfire Series Wheelchairs Part No 1134872...

  • Page 29: Adjusting Swingaway Padded Armrest Height

    Arms Adjusting Swingaway Padded Armrest Height NOTE: For this procedure, refer to FIGURE 2. 1. Remove the half arm from the arm socket. 2. Remove the mounting bolt, two washers and locknut mounted in the arm socket that  determine the swingaway padded armrest height. 3. Reposition mounting bolt and one washer to one of three positions in the arm socket  depending on the desired height. 4. Retighten the mounting bolt and washer to the arm socket with the remaining washer  and locknut. 5. Reinstall the half arm into the arm socket. 6. Repeat STEPS 1‐5 for the opposite side, if necessary. Swingaway Padded Armrest Arm Socket Washer Locknut Washer Mounting Bolt Three Mounting Positions FIGURE 2 Adjusting Swingaway Padded Armrest Height ™...

  • Page 30: Section 6-Back

    SECTION 6—BACK SECTION 6—BACK WARNING ALWAYS perform these procedures in the presence of an assistant. The position of the footrest, camber tube, back angle, the tautness of the back upholstery as well as the user's condition are directly related to the wheelchairs stability. Any change to one or any combination of the five may cause the wheelchair to decrease in stability.

  • Page 31: Back Angle Adjustment

    SECTION 6—BACK Back Angle Adjustment NOTE: For this procedure, refer to FIGURE 6.2 on page 32 and FIGURE 6.3 on page 33. NOTE: The numbers on the back angle plate are intended to define the resulting back angle of a  chair that has 2 inch seat drop (at 17 inch depth) and that is measured relative to true vertical with  the chair sitting on a level surface. The plus (+) sign increases the back angle and the minus (‐) sign  decreases the back angle. The resulting back angle will vary somewhat depending on your chair  configuration. Refer to FIGURE 6.3 on page 33 to see these settings converted into back angle  relative to the seat. NOTE: Perform this procedure on both sides of the wheelchair at the same time. 1. Fold down the back. Refer to Unfolding/Folding the Back on page 30. 2. Loosen the jam nut on the placement screw located at the bottom of the back cane  (Detail “A”). 3. Tighten the placement screw so that the screw and jam nut are snug against the  bottom of the back cane (Detail “B”). 4. Remove the mounting screw that secures the adjustment square to the back angle  plate (Details “A” and“C”). 5. Remove the adjustment square from the back angle plate (Detail “C”). NOTE: Note the indent on the adjustment square. When the adjustment square is positioned in  the back angle plate, the number that is located directly next to the indent will be back angle relative  to true vertical. One side of the adjustment square provides back angles of ‐8°, 0° and ‐4°. Flip the  adjustment square over to obtain back angles of 8°, 4° and 0° (FIGURE 6.3).  WARNING If the adjustment square is installed into the back angle plate so that a number does not appear next to the indent, DO NOT use this position, otherwise injury will occur.
  • Page 32 SECTION 6—BACK 10. Unthread the placement screw until head of screw rests on seat rail (Detail “F”). 11. Completely tighten jam nut up against bottom of back cane (Detail “F”). NOTE: When adjusted properly, the back should have a small amount of movement when locked  in the open position. Plunger pins should snap in and release easily without resistance. DETAIL “A” DETAIL “B” Placement Placement Jam Nut Back Cane Screw Back Cane Screw Adjustment Square Back Angle Plate Adjustment Mounting screw secures the adjustment Square square from the other side of the plate DETAIL “D”...
  • Page 33 SECTION 6—BACK DESIRED SEAT ADJUSTMENT SQUARE POSITION ANGLE NUMERICAL GRAPHICAL Back Back Angle Cane Plate 75° Adjustment -8° square to be positioned at -8° Seat Rail Back Angle Back Plate Cane Adjustment square to be 79° -4° positioned at -4° Seat Rail Back Cane OPTION 1...

  • Page 34: Adjustable Tension Back Upholstery

    SECTION 6—BACK Adjustable Tension Back Upholstery WARNING The position of the footrest, seat angle, back angle, seating system/upholstery, caster size and position, rear wheel size and position, use of anti-tippers, as well as the user condition directly relate to the stability of the wheelchair. Any change to one or any combination of the ten may cause the wheelchair to decrease in stability.

  • Page 35: Removing/Installing Foldover Back Upholstery

    SECTION 6—BACK 5. Stand behind the wheelchair and perform the following: A. Slide anchor loop section of adjustable tension back upholstery up onto the left  back cane with the upper grommet hole facing the rear of the wheelchair. B. Slide adjuster strap section of adjustable tension back upholstery up onto the right  back cane with the upper grommet hole facing the rear of the wheelchair. 6. Align the mounting hole in each back cane with the desired mounting hole in each  back upright.  NOTE: Both back canes should be adjusted to the same height. 7. Install the two back height adjustment screws through the back upright mounting  holes determined in STEP 6 and the back cane mounting holes. 8. Slip adjuster straps through corresponding anchor loops and adjust the back  upholstery. Secure with the fastening straps. WARNING After the adjustable tension back upholstery has been positioned to the end-users individual needs, the fastening straps MUST be securely fastened BEFORE applying the back upholstery cover.

  • Page 36: Removing Foldover Back Upholstery

    SECTION 6—BACK Removing Foldover Back Upholstery 1. Unfasten the two fastening flaps that secure the bottom of the existing back upholstery  to the back canes. 2. Unfold the top of the back upholstery. 3. Lift up on the existing back upholstery and remove from the wheelchair. Installing Foldover Back Upholstery 1. Install the new back upholstery onto the back canes. 2. Wrap the end of a fastening flap around the back cane. 3. Insert the end of the fastening flap through the loop. 4. Wrap the fastening flap around the back cane again and press firmly to secure. 5. Fold the top of the back upholstery down over the back canes towards the front of the  wheelchair. 6. Press firmly to secure the fastening strips. Back Upholstery Front of Wheelchair Fastening Strips Fold Fastening Flap Fastening Flap Loops Back Canes...

  • Page 37: Back Height Adjustment (Adjustable Backs Only)

    SECTION 6—BACK Back Height Adjustment (Adjustable Backs Only) NOTE: For this procedure, refer to FIGURE 6.6 NOTE: Observe the tautness of the back upholstery for reinstallation. 1. Unlatch the two fastening flaps that secure the top of the back upholstery to the back  canes and remove from the back canes. WARNING Adjustment pin MUST be protruding through hole in back cane. Ensure that both back cane inserts are at the same height BEFORE reassembling the wheelchair. 2.

  • Page 38: Section 7-Seat

    SECTION 7—SEAT SECTION 7—SEAT WARNING After ANY adjustments, repair or service and BEFORE use, make sure all attaching hardware is tightened securely - otherwise injury or damage may occur. Replacing Adjustable Tension Seat Upholstery WARNING The seat upholstery and/or cushion MUST be cleaned regularly and/or replaced if incontinence is frequent.
  • Page 39 SECTION 7—SEAT Fastening Flaps Seat Adjuster Anchor Loop Upholstery Straps (Rear) Wheelchair Frame (Top Bar) Top Crossbar FIGURE 7.1 Replacing Adjustable Tension Seat Upholstery ™ Part No 1134872 Crossfire Series Wheelchairs...

  • Page 40: Section 8-Wheels

    - otherwise injury or damage may result. Removing/Installing Rear Wheels CAUTION Changing the size of the rear wheels can affect the performance of the wheelchair. Contact Invacare at the telephone numbers on the back of this manual before changing rear wheel size. NOTE: For this procedure, refer to FIGURE 8.1. 1. Perform one of the following: •...

  • Page 41: Adjusting Quick-Release Axles

    SECTION 8—WHEELS Adjusting Quick-Release Axles NOTE: For this procedure, refer to FIGURE 8.2. 1. Remove rear wheel and quick‐release axle from the wheelchair. Refer to  Removing/Installing Rear Wheels on page 40. 2. Depress detent pin in the quick‐release  NOTE: End of Quick Release axle is shown  axle and slide axle through the wheel  for reference only. It is not visible when  hub. inserted into camber bar. 3. Release detent pin ensuring that the  Locknut Adjustable Axle locking pins are fully released. Position Camber Bar Detent 4. Increase or decrease end play by  Locking adjusting the locknut on the end of the  Pins quick‐release axle. Wheel Quick-Release 5. Reinstall rear wheel onto the  Axle wheelchair. Refer to  Removing/Installing Rear Wheels on ...

  • Page 42: Adjusting Quad-Release Handles

    SECTION 8—WHEELS Adjusting Quad-Release Handles NOTE: For this procedure, refer to FIGURE 8.4. In and/or Out 1. Remove rear wheel and the  Adjusting Quad-Release Locking Pins quad‐release axle from the wheelchair.  Handle In and/or Out Refer to Removing/Installing Rear  Wheels on page 40.  Quad Release Handle 2. Loosen the locking screw. Camber Bar 3. Make one or both of the following  adjustments: Locking Length Screw • If the quad‐release handle is not  Adjustment releasing the locking pins ...

  • Page 43: Handrim Replacement

    SECTION 8—WHEELS Handrim Replacement NOTE: For this procedure, refer to FIGURE 8.5. 1. Remove the rear wheel from the wheelchair. Refer to Removing/Installing Rear  Wheels on page 40. WARNING Tire MUST be fully deflated before any disassembly procedures are performed. Otherwise injury or damage may result. 2. Remove all air from the tube by pressing down on the pin in the center of the valve  stem. 3. While carefully holding the tire, tube and rim strip to one side, hold the allen screws  and remove the locknuts that secure the handrim to the rear wheel. 4. Remove the existing handrim. 5. Install new handrim by reversing STEPS 2‐4. WARNING DO NOT inflate tire until it is completely assembled. Otherwise injury or damage may result.

  • Page 44: Repairing/Replacing Rear Wheel, Tire/Tube

    Replacement of the tire or tube MUST be performed by a qualified technician. CAUTION Changing the size of the rear wheels can affect the performance of the wheelchair. Contact Invacare at the numbers on the back cover BEFORE performing this proce- dure. NOTE: If replacing rear wheels with a different size than what was originally on the wheelchair, ...
  • Page 45 SECTION 8—WHEELS Rear Wheel 4¼ inches of Wheelbase Length Adjustment Front Caster Wheelbase Length SOCKET SCREW MOUNTING POSITIONS CAMBER TUBE MOUNTING BRACKET CAMBER TUBE MOUNTING BRACKET FACING THE FRONT OF THE FACING THE REAR OF THE WHEELCHAIR WHEELCHAIR NOTE: Camber tube  NOTE: Camber tube  mounting bracket ...

  • Page 46: Repositioning The Camber Tube Mounting Brackets

    SECTION 8—WHEELS Repositioning the Camber Tube Mounting Brackets NOTE: For this procedure, refer to FIGURE 8.7. 1. Remove the rear wheels. Refer to Removing/Installing Rear Wheels on page 40. 2. Loosen but do not remove the four socket screws and washers that secure the two  camber tube mounting brackets to the camber tube supports. 3. Slide the camber bar forward or backward to adjust the wheelbase length to the  desired position. 4. Securely tighten the four socket screws and washers that secure the two camber tube  mounting brackets to the camber tube supports. 5. Install the rear wheels. Refer to Removing/Installing Rear Wheels on page 40. Camber Tube Washers Mounting Bracket Socket Screws Camber Tube Support Camber Tube Support Camber Tube Camber Mounting Bracket Tube...

  • Page 47: Reversing The Camber Tube Mounting Bracket Direction

    SECTION 8—WHEELS 4. Align the desires mounting positions of the camber tube mounting brackets with the  opening of the camber tube supports. 5. Install the four socket screws, washers, and lock washers into the desired mounting  positions of both camber tube mounting brackets. Hand tighten. 6. Slide the camber bar forward or backward to adjust the wheelbase length to the  desired position. Securely tighten the four socket screws. 7. Install the rear wheels. Refer to Removing/Installing Rear Wheels on page 40. Camber Tube Support Washers Socket Screws Camber Tube Mounting Bracket Camber Tube FIGURE 8.8 Repositioning the Camber Tube Mounting Bracket Socket Screws Reversing the Camber Tube Mounting Bracket Direction NOTE: For this procedure, refer to FIGURE 8.9 on page 48.

  • Page 48: Adjusting Wheelbase Width

    SECTION 8—WHEELS Camber Tube Direction Camber Tube Facing Rear of Wheelchair Support Camber Tube Camber Tube Washers Mounting Bracket Socket Screws Camber Tube Camber Tube Mounting Bracket Camber Facing Front of Wheelchair Tube FIGURE 8.9 Reversing the Camber Tube Mounting Bracket Direction Adjusting Wheelbase Width NOTE: For this procedure, refer to FIGURE 8.10.

  • Page 49: Removing/Installing/ The Camber Tube

    SECTION 8—WHEELS Removing/Installing/ the Camber Tube WARNING Camber tube mounting clamps - Make sure the mounting screws are securely tightened before using the wheelchair, otherwise personal injury or damage to the wheelchair may occur. NOTE: For this procedure, refer to FIGURE 8.11. NOTE: When replacing or changing the camber tube, perform with the new camber tube. Removing the Camber Tube 1.

  • Page 50: Adjusting The Camber Tube

    SECTION 8—WHEELS Adjusting the Camber Tube WARNING STANDARD and axle tube clamps - Make sure the hex screws are securely tight- ened before using the wheelchair, otherwise injury or damage to the wheelchair may occur. NOTE: For this procedure, refer to FIGURE 8.12. Stand behind the wheelchair to determine left or right. 1. Loosen, but DO NOT remove the four socket screws camber tube clamps. 2.

  • Page 51: Determining Toe In/Toe Out

    SECTION 8—WHEELS Determining Toe In/Toe Out NOTE: For this procedure, refer to FIGURE 8.13. 1. Inflate all pneumatic tires to recommended tire pressures (listed on the sidewall of the  tire). 2. Measure the distance between the centerlines at the rear and front of the rear wheels  at approximately 12 inches from the ground/floor (FIGURE 8.13). NOTE: For optimum accuracy, perform STEP 2 with the wheelchair occupied. 3. Determine difference between two measurements. If difference between the two  measurements is greater than ½‐inch (0 + ¼‐inch for maximum rollability), one of two  conditions exists: • If the back centerline measurement of the rear wheels is SMALLER than the front  centerline measurement of the rear wheels, a TOE‐OUT condition exists  (FIGURE 8.13). • If the back centerline measurement of the rear wheels is LARGER than the front  centerline measurement of the rear wheels, a TOE‐IN condition exists  (FIGURE 8.13). 4. If the difference between the measurements is greater than ½‐inch, correct the  toe‐in/toe‐out condition. Top View of Wheelchair Top View of Wheelchair Front of Wheelchair Front of Wheelchair Toe-out...

  • Page 52: Adjusting Fork Tension

    SECTION 8—WHEELS Adjusting Fork Tension NOTE: For this procedure, refer to FIGURE 8.14. 1. To properly tighten forks and guard against flutter, perform the following check on  both forks: A. Tip back the wheelchair to floor. B. Pivot both forks and casters to top of their arc simultaneously. C. Let casters drop to bottom of arc (wheels should swing once to one‐side, then  immediately rest in a straight downward position). 2. If necessary, perform one of the following to adjust the fork tension: • Standard Forks ‐ Adjust locknut according to freedom of caster swing (Detail “A”). • Suspension Fork (Detail “B”) ‐  a. Refer to Removing the Elastomer on page 56 to remove the elastomer and  suspension fork bottom to access the locknut. b. Adjust locknut according to freedom of caster swing. c. Refer to Installing the Elastomer on page 56 to secure the suspension fork top  to the elastomer and suspension fork bottom. 3. Test wheelchair for maneuverability. 4. If necessary, repeat STEPS 1‐2 to adjust locknuts until tension is correct for both forks. DETAIL “B” SUSPENSION FORK DETAIL “A”...

  • Page 53: Removing/Installing/Repositioning The Caster Assemblies

    SECTION 8—WHEELS Removing/Installing/Repositioning the Caster Assemblies NOTE:  If replacing a front caster note the mounting position of the existing front caster for  installation of the new front caster. NOTE: Both front casters MUST be the same size and adjusted to the same height. Standard Forks NOTE: For this procedure, refer to  Fork FIGURE 8.15. Removing Front Caster Mounting Bolt 1. Remove the mounting bolt, axle  Locknut spacers and locknut that secure the  front caster to the fork. Caster 2. Remove the caster from the fork. Axle Axle Installing Front Caster Spacer Spacer 1. Using the mounting bolt, axle spacers  FIGURE 8.15 Removing/Installing/Repositi and locknut, secure the caster to the  oning the Caster Assemblies - Standard Forks desired caster mounting position.

  • Page 54: Removing/Installing The Fork Assembly

    SECTION 8—WHEELS Installing the Caster 1. Align the caster with the desired mounting holes in the fork. 2. Insert the threaded bushing with mounting screw, through the two axle spacers and  caster. DO NOT use excessive force. WARNING Use Loctite™242 when reinstalling the mounting screw into the threaded bushing. Otherwise the fork can become disassembled. Possible injury or damage could result. 3. Apply Loctite 242 to the mounting screw. 4. Reinstall the mounting screw into the threaded bushing and tighten securely. Mounting Fork Screw Mounting Axle...

  • Page 55: Installing Fork Assembly

    SECTION 8—WHEELS Installing Fork Assembly 1. Perform one of the following: • Standard Forks ‐ Using a locknut and washer, secure the spacer and fork to the fork  stem (Detail “A”). • Suspension Fork (Detail “B”) ‐  a. Using a locknut and washer, secure the spacer and suspension fork top to the  fork stem. b. Refer to Installing the Elastomer on page 56 secure the suspension fork top to  the elastomer and suspension fork bottom. 2. Install the front caster. Refer to Installing Front Caster on page 53. DETAIL “A” DETAIL “B” STANDARD FORK SUSPENSION FORK Fork Stem Fork Stem Spacer Spacer Threaded Bushing Suspension Fork Top Mounting Screws Washer...

  • Page 56: Removing/Installing The Elastomers (Suspension Forks Only)

    SECTION 8—WHEELS Removing/Installing the Elastomers (Suspension Forks Only) CAUTION DO NOT use excessive force when removing/installing the threaded sleeve from/onto the fork. Damage to the threaded sleeve may occur. NOTE: For this procedure, refer to FIGURE 8.18. Removing the Elastomer NOTE: One mounting screw will not turn. 1. Using two allen wrenches, turn mounting screws in opposite directions and remove  one mounting screw from fork. 2. Remove the threaded bushing and mounting screw securing the suspension fork top  to the elastomer and the suspension fork bottom. DO NOT use excessive force.

  • Page 57: Section 9-Wheel Locks

    SECTION 9—WHEEL LOCKS SECTION 9—WHEEL LOCKS WARNING After any adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may result. Replacing/Adjusting the Wheel Locks WARNING If wheel locks do not hold the occupied wheelchair in place contact a qualified tech- nician - otherwise injury or damage may occur.

  • Page 58: Changing Wheel Lock Handle Position

    SECTION 9—WHEEL LOCKS Push-to-Lock or Pull-to-Lock Wheel Locks Under Mount Wheel Lock 3/16 inch 3/16 inch Mounting Screws Mounting Screws (1/8-inch) (1/8-inch) Wheel Wheel Wheel Wheel Lock Lock Tire Lock Shoe Tire Lock Shoe FIGURE 9.1 Replacing/Adjusting the Wheel Locks Changing Wheel Lock Handle Position NOTE: For this procedure, refer to FIGURE 9.2.

  • Page 59: Converting Wheel Lock From Push-To-Lock To Pull-To-Lock Or Pull-To-Lock To Push-To-Lock

    SECTION 9—WHEEL LOCKS Converting Wheel Lock From Push-to-Lock to Pull-to-Lock or Pull-to-Lock to Push-to-Lock NOTE: For this procedure, refer to FIGURE 9.3. Converting From Push-to-Lock to Pull-to-Lock 1. Remove set screw from the lower stop position (Detail “A”). NOTE: As the wheel lock handle is pushed downwards, the wheel lock will engage and then  disengage the wheel. 2. Push wheel lock handle down to access the upper stop position (Detail “B”).  3. Install set screw into upper stop position. 4. Pull wheel lock handle up to engage wheel lock. If wheel lock does not properly  engage the wheel, refer to Adjusting the Wheel Lock on page 57. Converting From Pull-to-Lock to Push-to-Lock 1. Remove set screw from the upper stop position (Detail “B”). NOTE: As the wheel lock handle is pulled upwards, the wheel lock will engage and then disengage  the wheel.

  • Page 60: Section 10-Anti-Tipper

    Anti-tippers MUST be attached at all times. Inasmuch as the anti-tippers are an option on this wheelchair (you may order it with or without the anti-tippers), Invacare strongly recommends ordering the anti-tippers as an additional safeguard for the wheelchair user.

  • Page 61: Replacing Anti-Tipper

    SECTION 10—ANTI-TIPPER Replacing Anti-tipper WARNING When anti-tippers are used, anti-tippers MUST be adjusted to maintain a 1-1/2 to 2-inch clearance between the bottom of the anti-tipper wheels and the ground/floor. This spacing should always be checked whenever adjustments/changes are made to the wheelchair. Failure to maintain proper spacing may result in the chair tipping over backward causing serious injury or property damage.
  • Page 62 NOTES NOTES ™ Crossfire Series Wheelchairs Part No 1134872...

  • Page 63: Limited Warranty

    In the event you do not receive satisfactory warranty service, please write directly to Invacare Top End at the address on the back page. Provide dealer’s name, address, date of purchase, indicate nature of the defect and, if the product is serialized, indicate the serial number.
  • Page 64 Elyria, Ohio USA Unit 8 symbols ™and ®. All trademarks are owned by or 44036-2125 Mississauga Ontario licensed to Invacare Corporation or its subsidiaries 800-333-6900 L4Z 4G4 Canada unless otherwise noted. 800-668-5324 KIK is a registered trademark of KIK Technology, Inc.
