Owner's Operator and Maintenance Manual
Everyday and Sport Series
Top End Everyday Series
Terminator™ Titanium and Titanium Heavy Duty
Terminator™ Everyday and Everyday Heavy Duty
DEALER: This manual MUST be given to
the user of the wheelchair.
USER: BEFORE using this wheelchair, read
this manual and save for future reference.
For more information regarding
Invacare products, parts, and services,
please visit www.invacare.com
Wheelchairs
Top End Sports Series
Terminator™ BB
X-Terminator™ BB
Paul Schulte Signature BB
X-Terminator™ Titanium
X-Terminator™ QR
Transformer™ All Sport
T-5 Tennis Elite
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Terminator Titanium and is the answer not in the manual?

Questions and answers

Related Manuals for Invacare Terminator Titanium

Summary of Contents for Invacare Terminator Titanium

  • Page 1 T-5 Tennis Elite DEALER: This manual MUST be given to the user of the wheelchair. USER: BEFORE using this wheelchair, read this manual and save for future reference. For more information regarding Invacare products, parts, and services, please visit www.invacare.com...
  • Page 2 DO NOT OPERATE THIS EQUIPMENT WITHOUT FIRST READING AND UNDERSTANDING THIS MANUAL. IF YOU ARE UNABLE TO UNDERSTAND THE WARNINGS, CAUTIONS AND INSTRUCTIONS, CONTACT YOUR INVACARE DEALER OR INVACARE CUSTOMER SUPPORT BEFORE ATTEMPTING TO USE THIS EQUIPMENT - OTHERWISE INJURY AND/OR EQUIPMENT DAMAGE MAY OCCUR. NOTE: Updated versions of this manual are available on www.invacare.com.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS SPECIAL NOTES ................6 TYPICAL PRODUCT PARAMETERS ............ 8 Tyre Pressure Conversion ........................14 SECTION 1—GENERAL GUIDELINES ..........15 Stability Warning............................15 Operating Information..........................15 Tyre Pressure and Information ......................17 Weight Training ............................17 Weight Limitation.............................17 SECTION 2—SAFE HANDLING ............18 Stability and Balance..........................18 Coping with Everyday Obstacles......................19 A Note to Wheelchair Assistants....................19...
  • Page 4 TABLE OF CONTENTS TABLE OF CONTENTS Adjustable Tension Back Upholstery ....................32 The Adjustable Tension Straps ......................32 The Back Upholstery Cover......................32 Replacing Adjustable Tension Back Upholstery................32 Back Height Adjustment (Adjustable Backs Only)................33 SECTION 5—WHEELS ............... 35 Removing/Installing Rear Wheels ......................35 Adjusting Quick-Release Axles......................36 Replacing Quad-Release Axles ......................36 Adjusting Quad-Release Handles......................37 In and/or Out ............................37...
  • Page 5 TABLE OF CONTENTS TABLE OF CONTENTS Adjusting Transformer Seat Height......................59 Adjusting Front Seat Height ......................59 Adjusting Rear Seat Height ........................59 SECTION 7—FOOTREST/ANTI-TIPPER ..........61 Adjusting/Replacing Standard Footrest....................61 Replacing the Footrest........................61 Adjusting the Footrest ........................61 Installing/Adjusting Optional Clamp on Raised Footrest ..............62 Installing..............................62 Adjusting ..............................62 Replacing/Adjusting Optional A4 Footrest..................62...

  • Page 6: Special Notes

    CHANGE WITHOUT NOTICE. Serial number information is located under the seat of the chair. As a manufacturer of wheelchairs, Invacare endeavors to supply a wide variety of wheelchairs to meet many needs of the end user. However, final selection of the type of wheelchair to be used by an individual rests solely with the user and his/her healthcare professional capable of making such a selection.
  • Page 7 Invacare products are specifically designed and manufactured for use in conjunction with Invacare accessories. Accessories designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products. Because TOP END wheelchairs are made to the specifications of the original own- ers it is unlikely that refurbished product would be suitable to other user’s needs.

  • Page 8: Typical Product Parameters

    TYPICAL PRODUCT PARAMETERS TYPICAL PRODUCT PARAMETERS NOTE: All specifications are approximate. TERMINATOR EVERYDAY (ED) BASKETBALL FRAME: Rigid - 4130 Chrome-moly SEAT WIDTH: 12-20 inches (30.48 - 50.8 cm) - Outside to Outside of SEAT FRAME in 1-inch (2.54 cm) increments SEAT DEPTH: 14 to 17 (35.56 - 43.18 cm) inches SEAT-TO-FLOOR: Front - 17 to 21-inch (43.18 - 53.34 cm), Front - 17 to 21-inch (43.18 - 53.34 cm),...
  • Page 9 350 lbs (158.76 kg) with Heavy Duty Package 250 lbs (113.4 kg) NOTE: 15 x 15‐inch seat, rear wheels and minimal options are included in the weight. *NOTE: Refer to Tyre Pressure Conversion on page 14. NOTE: All specifications are approximate. TERMINATOR TITANIUM EVERYDAY (ED) BASKETBALL FRAME: Rigid - 4130 Chrome-moly SEAT WIDTH: 12-20 inches (30.48 - 50.8 cm) - Outside to Outside of SEAT FRAME in 1-inch (2.54 cm) increments...
  • Page 10 TYPICAL PRODUCT PARAMETERS TERMINATOR TITANIUM EVERYDAY (ED) BASKETBALL HANDRIMS: Aluminum Welded Tab (Standard) Aluminum Welded Tab (Standard), Plastic Coated, Natural Fit®, Titanium Titanium WHEEL LOCKS: High Mount, Low Mount (Standard) FRONT FORKS: Non-Suspension (Standard), Suspension Non-Suspension CASTOR SIZE: 3, 4, 5 and 6-inch (7.62, 10.16, 12.7 and 15.24 cm)
  • Page 11 TYPICAL PRODUCT PARAMETERS X-TERMINATOR BASKETBALL (BB) TITANIUM AND QUAD RUGBY 25-INCH: Primo 25-559 (Standard) 26-INCH: Primo 25-590 (Standard) 700C: Special Turbo (Standard) HANDRIMS: Aluminum Welded Tab, Titanium WHEEL LOCKS: High Mount, Low Mount (Standard) FRONT FORKS: Non-Suspension CASTOR SIZE: 3-inch (7.62 cm) Solid BACK UPHOLSTERY: U240 Black - Adjustable Tension WEIGHT:...
  • Page 12 TYPICAL PRODUCT PARAMETERS PAUL SCHULTE SIGNATURE BB/ T-5 TENNIS ELITE SHIPPING WEIGHT: 30 lbs (13.6 kg) WEIGHT LIMITATION: 250 lbs (113.4 kg) NOTE: 15 x 15‐inch seat, rear wheels and minimal options are included in the weight. *NOTE: Refer to Tyre Pressure Conversion on page 14. NOTE: All specifications are approximate. Everyday and Sport Series Wheelchairs Part No 1122172...
  • Page 13 TYPICAL PRODUCT PARAMETERS TRANSFORMER ALL-SPORT FRAME: Rigid - 606IT6 Aluminium SEAT WIDTH: 12-20 inches (30.48 - 50.8 cm) - Outside to Outside of SEAT FRAME in 1-inch increments SEAT DEPTH: 12 to 20-inches (30.48 - 50.8 cm) SEAT-TO-FLOOR: TALL FRAME: Front - 18 to 21-inch (45.72 - 53.34 cm), Rear -15 to 21-inch (38.1 - 53.34 cm) SHORT FRAME Front - 16 to 18-inch (40.64 - 45.72 cm), Rear -15 to 18-inch (38.1 - 45.72 cm)

  • Page 14: Tyre Pressure Conversion

    TYPICAL PRODUCT PARAMETERS Tyre Pressure Conversion NOTE: PSI rating is printed on the side of the tyre. NOTE: Conversion formula: 1 psi = 6.895 kPa (appox. 7 kPa). KILOPASCALS Everyday and Sport Series Wheelchairs Part No 1122172...

  • Page 15: Section 1-General Guidelines

    SECTION 1—GENERAL GUIDELINES SECTION 1—GENERAL GUIDELINES WARNING SECTION 1 - GENERAL GUIDELINES contains important information for the safe operation and use of this product. DO NOT use this product or any available optional equipment without first completely reading and understanding these instructions and any additional instructional material such as Owner’s Manuals, Service Manuals or Instruction Sheets supplied with this product or optional equipment.
  • Page 16 SECTION 1—GENERAL GUIDELINES DO NOT attempt to reach objects if you have to pick them up from the floor by reaching  down between your knees. DO NOT lean over the top of the back upholstery to reach objects from behind as this may  cause the wheelchair to tip over. DO NOT shift your weight or sitting position toward the direction you are reaching as the  wheelchair may tip over. DO NOT tip the wheelchair without assistance. DO NOT use an escalator to move a wheelchair between floors. Serious bodily injury may  occur. Before attempting to transfer in or out of the wheelchair, every precaution should  be taken to reduce the gap distance. Turn both castors parallel to the object you are  transferring onto. Also be certain the wheel locks are engaged to prevent the wheels from  moving. DO NOT operate on roads, streets or highways. DO NOT climb, go up or down ramps or traverse slopes greater than 9°. DO NOT attempt to move up or down an incline with a water, ice or oil film. DO NOT attempt to ride over curbs or obstacles. Doing so may cause your wheelchair to  turn over and cause bodily harm or damage to the wheelchair. Invacare products are specifically designed and manufactured for use in conjunction with  Invacare accessories. Accessories designed by other manufacturers have not been tested  by Invacare and are not recommended for use with Invacare products. Because TOP END wheelchairs are made to the specifications of the original owners it is  unlikely that refurbished product would be suitable to other user’s needs. DO NOT attempt to lift the wheelchair by any removable (detachable) parts. Lifting by  means of any removable (detachable) parts of a wheelchair may result in injury to the user  or damage to the wheelchair. DO NOT stand on the frame of the wheelchair. Check all allen screws that secure the footrest/raised footrest system to the chair frame  before using the wheelchair, especially if engaging in any contact sport. Anti‐tippers MUST BE attached at all times. Inasmuch as the anti‐tippers are an option on  this wheelchair (you may order with or without the anti‐tippers), Invacare strongly  recommends ordering the anti‐tippers as an additional safeguard for the wheelchair user. Anti‐tippers MUST be used at all times. When outdoors on wet, soft ground or on gravel  surfaces, anti‐tippers may not provide the same level of protection against tip over. Extra  caution MUST be observed when traversing such surfaces. Unless otherwise noted, all service and adjustments should be performed while the  wheelchair is unoccupied. ALWAYS wear your seat positioning strap. Inasmuch as the SEAT POSITIONING STRAP ...

  • Page 17: Tyre Pressure And Information

    SECTION 1—GENERAL GUIDELINES The seat positioning strap is a positioning belt only. It is not designed for use as a safety  device withstanding high stress loads such as auto or aircraft safety belts. If signs of wear  appear, belt MUST be replaced immediately. ALWAYS use the handrims for self‐propulsion. Inasmuch as the handrims are an option  on this wheelchair (you may order with or without the handrims), Invacare strongly  recommends ordering the handrims as an additional safeguard for the wheelchair user.  DO NOT use the footplate as a platform when getting in or out of the wheelchair. The bumper design creates a potential foot entrapment area. Ensure the occupant’s legs  and feet are properly secured during use. When transferring the occupant, ensure the feet  do not slip between the bumper and the footrests. Tyre Pressure and Information DO NOT use your wheelchair unless it has the proper tyre pressure (p.s.i.). DO NOT  overinflate the tyres. Failure to follow these suggestions may cause the tyre to explode  and cause bodily harm. The recommended tyre pressure is on the sidewall of the tyre. Replacement of the tyre or tube MUST be performed by a qualified technician. Weight Training Invacare DOES NOT recommend the use of its wheelchairs as a weight training  apparatus. Invacare wheelchairs have not been designed or tested as a seat for any kind  of weight training. If occupant uses said wheelchair as a weight training apparatus,  Invacare shall not be liable for bodily injury and the warranty is void. Weight Limitation Invacareʹs Top End Everyday and Sport Series wheelchairs (Terminator Titanium,  Terminator Everyday, Terminator BB, X‐Terminator BB, Paul Schulte Signature BB, T‐5  Tennis Elite, X‐Terminator titanium, X‐terminator Quad Rugby QR and Transformer All  Sport) have a weight limitation of 250 lbs (113.4 kg).  Terminator Everyday wheelchairs with the  Weight Capacity heavy duty option have a weight  Label Camber limitation of 350 lbs (158.76 kg).

  • Page 18: Section 2-Safe Handling

    MUST be replaced immediately. Anti-tippers MUST BE attached at all times. Inasmuch as the anti-tippers are an option on this wheelchair (you may order with or without the anti-tippers), Invacare strongly recommends ordering the anti-tippers as an additional safeguard for the wheelchair user.

  • Page 19: Coping With Everyday Obstacles

    SECTION 2—SAFE HANDLING Coping with Everyday Obstacles Coping with the irritation of everyday obstacles can be alleviated somewhat by learning  how to manage your wheelchair. Keep in mind your center of gravity to maintain stability  and balance. A Note to Wheelchair Assistants When assistance to the wheelchair user is required, remember to use good body  mechanics. Keep your back straight and bend your knees whenever tilting the wheelchair  or traversing curbs, or other impediments. WARNING DO NOT attempt to lift a wheelchair by lifting on any removable (detachable) parts. Lifting by means of any removable (detachable) parts of a wheelchair may result in injury to the user or damage to the wheelchair.

  • Page 20: Reaching, Leaning And Bending - Forward

    SECTION 2—SAFE HANDLING Proper positioning is essential for your safety. When reaching, leaning, bending forward,  it is important to use the front castors as a tool to maintain stability and balance.  • Lengthening the wheelbase will increase the stability and maintain standard  manoeuverability of wheelchair. • Shortening the wheelbase will decrease the stability, increase the manoeuverability  and distribute additional weight onto the rear wheels. Rear of Center of Wheelchair Gravity Lengthening the Wheelbase Shortening the Wheelbase Unoccupied Occupied Reaching, Leaning and Bending - Forward Position the front castors so that they are  extended as far forward as possible and  engage wheel locks.  WARNING DO NOT attempt to reach objects if you have to move forward in the seat or pick them up from the floor by reaching down between your knees.

  • Page 21: Tipping

    Tipping - Curbs WARNING Invacare does not recommend that sport wheelchairs be used where traversing curbs present an obstacle. Possible injury to occupant and/or assistant(s) can occur. Transfer to an everyday use wheelchair is recommended if any such obstacles may be encountered.

  • Page 22: Stairways

    Extreme caution is advised when it is necessary to move an occupied wheelchair up or down a stairway. Invacare recommends that, if possible, the user be removed from the wheelchair prior to moving. Invacare recommends using two assistants and making thorough preparations.

  • Page 23: Transferring To And From Other Seats

    SECTION 2—SAFE HANDLING 3. The second assistant, with a firm hold on a non‐detachable part of the framework, lifts  the wheelchair up and over the stair and steadies it as the first assistant places one foot  on the next stair and repeats procedure. 4. The wheelchair should not be lowered until the last stair has been negotiated and it  has been rolled away from the stairway. 5. If equipped, turn the anti‐tippers down. Refer to Footrest/Anti‐Tipper on page 61 in  this manual. WARNING DO NOT use an escalator to move a wheelchair between floors. Serious bodily injury may occur. Transferring To and From Other Seats WARNING Before attempting to transfer in or out of the wheelchair, every precaution should be taken to reduce the gap distance.

  • Page 24: Section 3-Safety Inspection

    SECTION 3—SAFETY INSPECTION SECTION 3—SAFETY INSPECTION NOTE: Every six months, take your wheelchair to a qualified technician for a thorough inspection  and servicing. Regular cleaning will reveal loose or worn parts and enhance the smooth operation  of your wheelchair. To operate properly and safely, your wheelchair must be cared for just like any  other vehicle. Routine maintenance will extend the life and efficiency of your wheelchair. Clean  upholstery with mild soap and water or spray disinfectant using a sponge. DO NOT use bleach or  wash in a washing machine. Safety Inspection Checklist WARNING In cases of inactivity longer then six months, a comprehensive initial inspection MUST be performed. Initial adjustments should be made to suit your personal body structure and preference.  Thereafter follow these maintenance procedures: Inspect Initially ❑ Ensure wheelchair rolls straight (no excessive drag/pull to one side). ❑ Ensure wheel locks DO NOT interfere with tyres when rolling. ❑ Ensure pivot points are free of wear and looseness.  ❑...

  • Page 25: Inspect/Adjust Weekly

    SECTION 3—SAFETY INSPECTION CAUTION As with any vehicle, the wheels and tyres should be checked periodically for cracks and wear, and should be replaced if damaged. ❑ Inspect wheel/fork assembly for proper tension by spinning castor; castor should  come to a gradual stop. ❑ Loosen/tighten locknut if wheel wobbles noticeably or binds to a stop.  ❑ Ensure wheel bearings are clean and free of moisture. ❑ Inspect tyres for flat spots and wear. ❑ If pneumatic tyres check for proper inflation. ❑ Ensure castors are free of debris. ❑ Check that all labels are present and legible. Replace if necessary. Inspect/Adjust Weekly ❑...

  • Page 26: Inspect/Adjust Periodically

    SECTION 3—SAFETY INSPECTION ❑ Ensure adjustable axle position camber bar is securely tightened. CAUTION As with any vehicle, the wheels and tyres should be checked periodically for cracks and wear, and should be replaced if damaged. ❑ Loosen/tighten locknut if wheel wobbles noticeably or binds to a stop.  ❑ Ensure wheel bearings are clean and free of moisture. ❑ Ensure castors are free of debris. Inspect/Adjust Periodically ❑ Ensure wheelchair rolls straight (no excessive drag/pull to one side). ❑ Ensure wheel locks are easy to engage.  ❑...

  • Page 27: Maintenance

    4. Recommended tyre pressure is listed on the sidewall of the tyre. NOTE: Refer to Tyre Pressure Conversion on page 14 for correct metric measurement. CAUTION As with any vehicle, the wheels and tyres should be checked periodically for cracks and wear, and should be replaced if damaged. 5. The wheels, castors and tyres should be checked periodically for cracks and wear, and  should be replaced when necessary. Contact a qualified technician or Invacare  customer support at the telephone numbers on the back of this manual. Part No 1122172 Everyday and Sport Series Wheelchairs...
  • Page 28 SECTION 3—SAFETY INSPECTION 6. Regularly check for loose spokes in the rear wheels. If loose, have them adjusted.  Contact a qualified technician or Invacare customer support at the telephone numbers  on the back of this manual. 7. Periodically check handrims to ensure they are secured to the rear wheels. Refer to  Handrim Replacement on page 38. 8. Periodically adjust wheel locks as tyres wear. Refer to Wheel Lock  Adjustment/Replacement on page 56. 9. Periodically check castor wheel bearings to make sure they are clean and free from  ® moisture. Use a Teflon lubricant if necessary. 10. Check upholstery for sagging, rips or tears. 11. Clean upholstery with mild soap and water. NOTE: Some countries require product returned for service be cleaned and sanitized. Please  consult your dealer prior to returning product. Everyday and Sport Series Wheelchairs Part No 1122172...

  • Page 29: Section 4-Back

    SECTION 4—BACK SECTION 4—BACK WARNING ALWAYS perform these procedures in the presence of an assistant. The position of the footrest, camber tube, back angle, the tautness of the back upholstery as well as the user's condition are directly related to the wheelchairs stability. Any change to one or any combination of the five may cause the wheelchair to decrease in stability.
  • Page 30 SECTION 4—BACK 1. Loosen, but DO NOT remove the locknuts and hex screws that secure the back angle  bracket to the seat rail and the back post. 2. Loosen the top locknut and slide the top hex screw away from the back angle bracket  to adjust the cam. 3. Adjust back post to back angle required. 4. Adjust cam to achieve desired position. NOTE: An indexing notch has been put on the cam to help determine cam position for desired back  angle adjustment. 5. Secure cam in desired position. Torque all hex screws and locknuts to 960‐1020 inch  pounds (80‐85 foot‐pounds) (9.04 ‐ 9.6 newton‐metres). NOTE: As shown in FIGURE 4.2, the adjustment cam can be rotated to several different positions  thus changing the overall back angle relative to the seat rail. 95° Back Angle to Seat Rail 90° Back Angle to Seat Rail Back Post Back Post Indexing Indexing Notch Notch TOP Hex Screw and TOP Hex...

  • Page 31: Removing/Installing Foldover Back Upholstery

    SECTION 4—BACK Removing/Installing Foldover Back Upholstery WARNING The position of the footrest, seat angle, back angle, seating system/upholstery, cas- tor size and position, rear wheel size and position, use of anti-tippers, as well as the user condition directly relate to the stability of the wheelchair. Any change to one or any combination of the ten may cause the wheelchair to decrease in stability.

  • Page 32: Adjustable Tension Back Upholstery

    SECTION 4—BACK Adjustable Tension Back Upholstery WARNING The position of the footrest, seat angle, back angle, seating system/upholstery, cas- tor size and position, rear wheel size and position, use of anti-tippers, as well as the user condition directly relate to the stability of the wheelchair. Any change to one or any combination of the ten may cause the wheelchair to decrease in stability.

  • Page 33: Back Height Adjustment (Adjustable Backs Only)

    SECTION 4—BACK 5. Stand behind the wheelchair and perform the following: A. Slide anchor loop section of adjustable tension back upholstery up onto the left  back post with the upper grommet hole facing the rear of the wheelchair. B. Slide adjuster strap section of adjustable tension back upholstery up onto the right  back post with the upper grommet hole facing the rear of the wheelchair. 6. Align the mounting hole in each back post with the desired mounting hole in each  back upright.  NOTE: Both back posts should be adjusted to the same height. 7. Install the two back height adjustment screws through the back upright mounting  holes determined in STEP 6 and the back post mounting holes. 8. Slip adjuster straps through corresponding anchor loops and adjust the back  upholstery. Secure with the fastening straps. WARNING After the adjustable tension back upholstery has been positioned to the end-users individual needs, the fastening straps MUST be securely fastened BEFORE applying the back upholstery cover.
  • Page 34 SECTION 4—BACK ORIGINAL BACK HEIGHT 11 - 15 14 - 18 16 - 20 (IN INCHES) (27.94 - 38.1 CM) (35.56 - 45.72 CM) (40.64 - 50.8 CM) Hole* Number 11 (27.94 cm) 14 (35.56 cm) 16 (40.64 cm) 12 (30.48 cm) 15 (38.1 cm) 17 (43.18 cm) 13 (33.02 cm)

  • Page 35: Section 5-Wheels

    - otherwise injury or damage may result. Removing/Installing Rear Wheels CAUTION Changing the size of the rear wheels can affect the performance of the wheelchair. Contact Invacare at the telephone numbers on the back of this manual before changing rear wheel size. NOTE: For this procedure, refer to FIGURE 5.1. 1. Perform one of the following: •...

  • Page 36: Adjusting Quick-Release Axles

    SECTION 5—WHEELS Adjusting Quick-Release Axles NOTE: For this procedure, refer to FIGURE 5.2. 1. Remove rear wheel and quick‐release axle from the wheelchair. Refer to  Removing/Installing Rear Wheels on page 35. 2. Depress detent pin in the quick‐release axle and slide axle through the wheel hub. 3. Release detent pin ensuring that the locking pins are fully released. 4. Increase or decrease end play by adjusting the locknut on the end of the quick‐release  axle. 5. Reinstall rear wheel onto the wheelchair. Refer to Removing/Installing Rear Wheels  on page 35. Adjustable Axle Position Camber Bar Locknut Locking Pins Detent Pin NOTE: End of Quick Release  Wheel Hub axle is shown for reference  only. It is not visible when  Quick-Release Axle inserted into camber bar. FIGURE 5.2 Adjusting Quick-Release Axles Replacing Quad-Release Axles NOTE: For this procedure, refer to FIGURE 5.3.

  • Page 37: Adjusting Quad-Release Handles

    SECTION 5—WHEELS 7. If detent pin does not fully release, proceed to Adjusting Quad‐Release Handles on  page 37. 8. Repeat STEPS 1‐7 for the opposite rear wheel. Adjusting Quad-Release Handles NOTE: For this procedure, refer to FIGURE 5.4. In and/or Out 1. Remove rear wheel and the  Adjusting Quad-Release quad‐release axle from the wheelchair.  Locking Pins Handle In and/or Out Refer to Removing/Installing Rear  Wheels on page 35.  2. Loosen the locking screw. Quad Release 3. Make one or both of the following  Camber Bar Handle adjustments: Locking Length Screw...

  • Page 38: Handrim Replacement

    Replacement of the tyre or tube MUST be performed by a qualified technician. CAUTION Changing the size of the rear wheels can affect the performance of the wheelchair. Contact Invacare at the numbers on the back cover before performing this proce- dure. Everyday and Sport Series Wheelchairs...

  • Page 39: Opening/Closing Camber Clamps

    SECTION 5—WHEELS NOTE: If replacing rear wheels with a different size than what was originally on the wheelchair,  the front castor height must also be changed to keep the wheelchair frame parallel to the floor. Refer  to Adjusting Front Castor Height on page 55 ONLY after contacting Invacare. Anti‐tipper height  (if applicable) must also be adjusted to maintain 1‐1/2 to 2‐inch (3.81 to 5.08 cm) clearance  between bottom of the anti‐tipper wheels and the floor. Refer to Adjusting/Replacing Anti‐Tipper  on page 65. Opening/Closing Camber Clamps WARNING QUICK RELEASE LEVERS - Make sure the quick release levers are in the closed position before using the wheelchair, otherwise personal injury or damage to the wheelchair may occur.
  • Page 40 SECTION 5—WHEELS Side View of Quick Release Lever Camber Clamp Closed Position Quick Release Open Position Lever Side View of Standard Camber Clamp Socket Screw Camber Clamp Rear View of Suspension Camber Clamp Camber Clamp Axle Tube Camber Insert Hex Screw FIGURE 5.6 Opening/Closing Camber Clamps Everyday and Sport Series Wheelchairs Part No 1122172...

  • Page 41: Adjusting Rear Wheel Camber

    SECTION 5—WHEELS Adjusting Rear Wheel Camber NOTE: For this procedure, refer to FIGURE 5.7. Camber Tube 2000 The axle tube must be replaced to change the camber. Refer to Replacing Axle Tube on  page 49. A4 Camber System NOTE: Perform this procedure to one side of  Rear View of Wheelchair the wheelchair at a time for ease of adjustment. Axle Camber Insert - 1. Open the camber clamp. Refer to  Tube Rotate 180° Opening/Closing Camber Clamps on  page 39. 2. Pull one rear wheel with camber insert  out of axle tube. Indexing Ring Camber Indexing Marks 3.

  • Page 42: Determining Toe In/Toe Out

    SECTION 5—WHEELS WARNING STANDARD AND SUSPENSION CAMBER CLAMPS - Make sure the hex screws are securely tightened before using the wheelchair, otherwise personal injury or damage to the wheelchair may occur. 8. Close the camber clamp. Refer to Opening/Closing Camber Clamps on page 39. 9. Repeat STEPS 1‐8 for opposite side of wheelchair. 10. Reinstall rear wheel to the wheelchair. Refer to Removing/Installing Rear Wheels on  page 35. 11.

  • Page 43: Adjusting Toe In/Toe Out

    SECTION 5—WHEELS Top View of Wheelchair Top View of Wheelchair Front of Wheelchair Front of Wheelchair Toe-out 12-inches (30.48 cm) Toe-in Rear of Wheelchair Smaller than Front Centerlines of Rear Wheels Larger than Front FIGURE 5.8 Determining Toe In/Toe Out - Measuring Centerlines of Rear Wheels Adjusting Toe In/Toe Out Camber Tube 2000 NOTE: For this procedure, refer to FIGURE 5.9.

  • Page 44: A4 Camber System

    SECTION 5—WHEELS A4 Camber System Course Adjustment NOTE: For this procedure, refer to FIGURE 5.10 on page 45. NOTE: This procedure is required any time the axle tube is moved from the factory set position or  is replaced. NOTE: Make the following adjustment for one camber at a time. 1. Open the camber clamps. Refer to Opening/Closing Camber Clamps on page 39. 2. Loosen the phillips screws that secure the adjustment rings to the axle tube. 3. Slowly rotate the axle tube until the rear wheels are approximately in a straight line. WARNING QUICK RELEASE LEVERS - Make sure the quick release levers are pointing towards the rear of the wheelchair and are in the closed position before using the wheelchair, otherwise personal injury or damage to the wheelchair may occur.

  • Page 45: Fine Adjustment

    SECTION 5—WHEELS Stop - In position for one Stop - Not touching camber, touching camber clamp camber clamp Adjustment Ring Adjustment Ring Camber Clamp Camber Clamp Stop - In position for one camber, touching camber clamp Adjustment Ring Stop - Not touching Adjustment Ring camber clamp FIGURE 5.10 Adjusting Toe In/Toe Out - A4 Camber System - Course Adjustment...

  • Page 46: Adjusting Wheelbase Length (Adjusting Center Of Gravity)

    SECTION 5—WHEELS NOTE: Rear wheels are removed from the  Axle Tube - Rotates Up and Down drawings for clarity, there is no need to remove  rear wheels from the wheelchair during  adjustment. NOTE: FIGURE 5.11 shows one example of  how the adjustment rings can be positioned. Stop - Not touching Stop - In position for one camber clamp camber, touching camber clamp Adjustment Ring Adjustment Ring Camber Clamp Camber Clamp Stop - In position for one camber, touching Adjustment Ring...
  • Page 47 SECTION 5—WHEELS NOTE: The camber bar is always mounted to  Non-Suspension - Top View the BOTTOM of the wheelchair frame. Hex Screw - 1. Perform one of the following: Loosen But DO NOT • Non‐Suspension ‐ Loosen, but DO  Remove Back Post NOT remove the hex screw that  secures each of the top clamps to the  Lengthening wheelchair frame. • Suspension ‐ Loosen, but DO NOT  Clamp Axle remove the two hex screws that  Tube secure each of the top clamps to the  Shortening wheelchair frame. 2. Position the camber clamps on the  Hex Screw - wheelchair frame at the desired ...

  • Page 48: Adjusting Wheelbase Width

    SECTION 5—WHEELS Adjusting Wheelbase Width NOTE: Perform this procedure on one side of the wheelchair at a time for ease of adjustment. Camber Tube 2000 NOTE: For this procedure, refer to FIGURE 5.13. NOTE: The wheelbase width can be increased/decreased by 1‐inch (2.54 cm). 1. Remove the rear wheels. Refer to Removing/Installing Rear Wheels on page 35. 2. Torque the axle nut to  Axle increase/decrease the wheelbase width. Camber Tube Insert 3. Count the number of threads showing  on the axle bolt. NOTE: The number of threads showing on the  Axle Nut axle bolt should be equal on both sides of the  Threads wheelchair. Otherwise, wheelchair performance  may be affected. 4. Repeat STEPS 2‐3 for the opposite axle  nut and axle bolt. Axle Bolt NOTE: Axle bolt removed from axle tube for  Camber Clamp clarity. It is not necessary to remove the axle ...

  • Page 49: Replacing Axle Tube

    SECTION 5—WHEELS WARNING QUICK RELEASE LEVERS - Make sure the quick release levers are pointing towards the rear of the wheelchair and are in the closed position before using the wheelchair, otherwise personal injury or damage to the wheelchair may occur. STANDARD AND SUSPENSION CAMBER CLAMPS - Make sure the hex screws are securely tightened before using the wheelchair, otherwise personal injury or damage to the wheelchair may occur.
  • Page 50 SECTION 5—WHEELS 10. A4 Camber System Only ‐ Install the adjustment rings onto the new axle tube. Make  sure the stops on the adjustment rings are facing towards the outside of the  wheelchair. NOTE: DO NOT tighten the phillips screws that secure the adjustment rings to the axle tube at  this time. 11. Slide the new axle tube through the other camber clamp until the axle tube is evenly  spaced between the camber clamps. NOTE: DO NOT close the camber clamps at this time. WARNING NEVER position the camber inserts in the axle tube with more than 3 inches (7.62 cm) (12 indexing marks showing) of the camber insert outside of the axle tube. The camber inserts will not be securely tightened in the axle tube.

  • Page 51: Adjusting The Axle Tube

    SECTION 5—WHEELS Rear of A4 Camber System Wheelchair Slot in Axle Tube Notch in Axle Tube Toe Adjustment Front of Camber Ring Wheelchair Insert Camber Set Screw Camber Tube 2000 Insert Axle Tube Rear of Camber Wheelchair Clamp Camber Indexing Ring Clamp Axle Tube...

  • Page 52: Camber Tube 2000

    SECTION 5—WHEELS Camber Tube 2000 NOTE: For this procedure, refer to FIGURE 5.16. 1. If necessary, open both camber clamps. Refer to Opening/Closing Camber Clamps on  page 39. 2. Using an ʺLʺ square, rotate the axle  tube until the flat edge of the camber  tube is at a 90° angle with the  ground/floor as shown in FIGURE 5.16. 3. Close both camber clamps. Refer to  Place “L” Square Here Refer to Opening/Closing Camber  Ground/ Clamps on page 39. Flat Edge of Floor 90° Angle Camber Tube 4. Determine the toe in/toe out of the  wheelchair. Refer to Determining Toe  In/Toe Out on page 42. FIGURE 5.16 Adjusting the Axle Tube - Camber Tube 2000 A4 Camber System...
  • Page 53 SECTION 5—WHEELS 10. Reposition the camber inserts to the highest degree of camber. Refer to Adjusting Rear  Wheel Camber on page 41. 11. Repeat STEP 3. 12. Close the left camber clamp. Refer to Opening/Closing Camber Clamps on page 39. 13. Rotate the right toe adjustment ring until the tab stops against the upper metal tab on  the camber clamp. 14. Securely tighten set screw on right toe adjustment ring. 15. Repeat STEP 7. 16. Perform one of the following: • Toe In/Toe Out Measurement is Within ±1/8‐inch (.32 cm) ‐  i. Proceed to STEP 17. • Toe In/Toe Out Measurement is Not Within ±1/8‐inch (.32 cm) ‐  i. Repeat STEP 1. ii. Loosen the set screw on the right toe adjustment ring. iii. Repeat STEP 3. iv. Repeat STEPS 12‐16 until toe in/toe out measurement is within ±1/8 (.32 cm) inch. 17. If desired, reposition camber inserts to the desired degree of camber. Refer to  Adjusting Rear Wheel Camber on page 41. Place “L” Square Here Flat Edge of Ground/Floor 90°...

  • Page 54: Replacing/Adjusting Castors

    SECTION 5—WHEELS Replacing/Adjusting Castors CAUTION Changing the size/type of and/or repositioning the front castors can affect the per- formance of the wheelchair. Contact Invacare at the telephone numbers on the back of this manual before performing this procedure. NOTE: For this procedure, refer to FIGURE 5.18 on page 55. NOTE: Non‐suspension castors cannot be adjusted as they mount in one position only. ...

  • Page 55: Adjusting Front Castor Height

    Adjusting Front Castor Height Locknut CAUTION Castor Housing Changing the height of the front/castors can affect the performance of the wheel- chair. Contact Invacare at the telephone Dust Cover numbers on the back of this manual before performing this procedure. Spacers “L” NOTE: For this procedure, refer to ...

  • Page 56: Wheel Lock Adjustment/Replacement

    SECTION 5—WHEELS Wheel Lock Adjustment/Replacement NOTE: For this procedure, refer to FIGURE 5.20. NOTE: Invacare recommends low mount wheels locks when engaging in any contact sport. NOTE: Before adjusting or replacing the High/Low mount wheel locks, ensure that the tyres are  inflated to the recommended psi on the sidewall of the tyre. 1. Loosen the locknuts and hex/allen screws that secure the High/Low mount wheel  locks to side frame. 2. Perform one of the following: • Replacing the High/Low Mount Wheel Lock: i. Remove the locknuts and hex/allen screws and remove existing wheel lock  from the wheelchair. ii. Install the new wheel lock and adjust. • Adjusting the High/Low Mount Wheel Lock: i. Measure the distance between the wheel lock shoe and the rear wheel. ii. Slide the wheel lock along the wheelchair until the measurement is between  5/32 and 5/16‐inches (.4 and .8 cm). iii. Tighten the wheel lock to the wheelchair frame. iv. Repeat this procedure for the opposite wheel lock. v. Engage the wheel locks and push against the wheelchair to determine if the  wheel locks engage the rear wheels enough to hold the occupied wheelchair. vi. Repeat STEPS i‐v until the wheel locks engage the rear wheels enough to hold  the occupied wheelchair. Rear...

  • Page 57: Section 6-Seat

    SECTION 6—SEAT SECTION 6—SEAT WARNING After ANY adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may occur. Replacing Adjustable Tension Seat Upholstery WARNING The seat upholstery and/or cushion MUST be cleaned regularly and/or replaced if incontinence is frequent.

  • Page 58: Replacing Screw-On Seat Upholstery

    SECTION 6—SEAT Fastening Flaps Seat Anchor Loop Adjuster Straps (Rear) Upholstery Wheelchair Frame (Top Bar) Top Crossbar FIGURE 6.1 Replacing Adjustable Tension Seat Upholstery Replacing Screw-On Seat Upholstery NOTE: For this procedure, refer to FIGURE 6.2 on page 58. 1. Remove the seat cushion from the wheelchair. 2. Remove the twelve mounting screws that secure the existing seat upholstery to the  seat frame. 3. Remove the existing seat upholstery. Mounting Screws Seat Upholstery Seat Frame FIGURE 6.2 Replacing Screw-On Seat Upholstery...

  • Page 59: Adjusting Transformer Seat Height

    SECTION 6—SEAT Adjusting Transformer Seat Height NOTE: For this procedure, refer to FIGURE 6.3 on page 60 Adjusting Front Seat Height 1. Note the order of the mounting screw, coved washers, spacer, half clamps and  mounting screw/threaded sleeve and their position on the wheelchair frame and  footrest tubing (Detail ʺAʺ, FIGURE 6.3). 2. Remove the mounting screw, coved washers, spacer, half clamps and mounting  screw/threaded sleeve on both sides of the wheelchair. NOTE: The footrest tubing will slide once the hardware is removed. 3. Raise/lower the front of the seat to the desired position. 4. Adjust the footrest height if desired. Refer to Adjusting the X‐terminator and  Transformer Footrests on page 64.  5. Align the footrest tubing adjustment holes with the desired wheelchair frame  adjustment holes. 6. Install the hardware removed in STEP 2 through the adjustment holes aligned in STEP 5.  7. Securely tighten all hardware. Adjusting Rear Seat Height 1. Loosen the two mounting screws on both sides of the front of the wheelchair  (Detail ʺAʺ). ...
  • Page 60 SECTION 6—SEAT DETAIL “A” - FRONT VIEW Wheelchair Frame Adjustment Holes Footrest Coved Tubing Washer Half Clamp Mounting Screw Mounted Screw/ Half Clamp Threaded Sleeve Coved Washer Adjustment Screw DETAIL “B” FIGURE 6.3 Adjusting Transformer Seat Height Everyday and Sport Series Wheelchairs Part No 1122172...

  • Page 61: Section 7-Footrest/Anti-Tipper

    SECTION 7—FOOTREST/ANTI-TIPPER SECTION 7—FOOTREST/ANTI-TIPPER WARNING After ANY adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may occur. ALWAYS perform this procedure in the presence of an assistant. The position of the footrest, camber tube, back angle, the tautness of the back upholstery as well as the user's condition are directly related to the wheelchairs stability.

  • Page 62: Installing/Adjusting Optional Clamp On Raised Footrest

    SECTION 7—FOOTREST/ANTI-TIPPER Installing/Adjusting Optional Clamp on Raised Footrest NOTE: For this procedure, refer to FIGURE 7.2. NOTE: This procedure is for Terminator Everyday (ED) wheelchairs ONLY.  Installing 1. Install the two half clamps onto either  Allen Wheelchair Frame side of the wheelchair frame  Screws approximately 2‐inches (5.08 cm) above  Half Clamp existing footrest with two provided  allen screws. Outside 2. Repeat for the opposite side of the  Raised Footrest Footrest wheelchair. Hoop 3. Slide the clamp on raised footrest into  the half clamps to the desired height. FIGURE 7.2 Installing/Adjusting Optional 4. Securely tighten the four allen screws. Clamp on Raised Footrest Adjusting 1.

  • Page 63: Adjusting Footplate Angle

    SECTION 7—FOOTREST/ANTI-TIPPER Allen Screws Footrest Tube Angle Flat Screws Height Footplate Flat Screws Depth FIGURE 7.3 Replacing/Adjusting Optional A4 Footrest Adjusting Footplate Angle 1. Loosen, but DO NOT remove the four flat screws and locknuts that secure the  footplate to the two footrest tubes. 2. Position the footplate to the necessary angle to accommodate the user. 3. Retighten the four flat screws and locknuts. NOTE: The locknuts should lie in the channel of the footplate half clamp. Adjusting Footplate Depth 1. Loosen, but DO NOT remove the four flat screws and locknuts that secure footplate  to the footrest tubes. NOTE: Observe the angle of footplate for reinstallation. 2. Move the footplate to one of two positions to accommodate the user. 3.

  • Page 64: Adjusting The X-Terminator And Transformer Footrests

    SECTION 7—FOOTREST/ANTI-TIPPER Adjusting the X-terminator and Transformer Footrests NOTE: For this procedure, refer to FIGURE 7.4 and FIGURE 7.5 on page 65. Depth 1. Remove the four allen screws from the footrest and blocks. 2. Move footrest rearward or forward to desired depth. 3. Align the holes in the footrest with the holes in the blocks on footrest tubing. 4. Install allen screws into footrest and into the blocks. 5. Securely tighten the four allen screws. Angle Allen Half Clamps Screws 1. Loosen the button screws on the blocks  on bottom of the footrest tubing. Footrest Tubing 2. Adjust the angle of the footrest. 3. Retighten the button screws securely. Footrest Allen Screws X-Terminator Height Depth Adjustment 1.

  • Page 65: Adjusting/Replacing Anti-Tipper

    Anti-tippers MUST be attached at all times. Inasmuch as the anti-tippers are an option on this wheelchair (you may order it with or without the anti-tippers), Invacare strongly recommends ordering the anti-tippers as an additional safeguard for the wheelchair user.

  • Page 66: Adjusting Anti-Tipper

    SECTION 7—FOOTREST/ANTI-TIPPER Adjusting Anti-tipper WARNING When anti-tippers are used, anti-tippers MUST be adjusted to maintain a 1-1/2 to 2-inch (3.81 to 5.08 cm) clearance between the bottom of the anti-tipper wheels and the ground/ floor. This spacing should always be checked whenever adjust- ments/changes are made to the wheelchair.

  • Page 67: Installing/Removing/Adjusting Swivel Anti-Tip

    SECTION 7—FOOTREST/ANTI-TIPPER DETAIL“A” - ANTI-TIPPER ADJUSTMENT HOLES Top Adjustment Hole Anti-Tipper Bar Release Buttons Anti-Tipper Hole Camber Clamp Anti-Tipper Socket Ground/ 1-1/2 to 2 inch Floor (53.66 cm) Clearance FIGURE 7.6 Adjusting/Replacing Anti-Tipper Installing/Removing/Adjusting Swivel Anti-Tip NOTE: For this procedure, refer to FIGURE 7.7 on page 68. NOTE: This applies to any Terminator ordered with swivel anti‐tip. Installing/Depth Adjustment 1.

  • Page 68: Adjusting Height

    SECTION 7—FOOTREST/ANTI-TIPPER Adjusting Height NOTE: For this procedure, refer to FIGURE 7.7. All Wheelchairs with Swivel Anti-tip Except Paul Schulte Signature BB and T-5 Tennis Elite Models 1. To adjust the height of the swivel anti‐tip, remove dust cover and loosen set screw on  swivel anti‐tip castor assembly (FIGURE 7.7). 2. Set anti‐tip castor wheel to desired height. Tighten set screw and reinstall dust cover. Paul Schulte Signature BB and T-5 Tennis Elite Models ONLY NOTE: For this procedure, refer to FIGURE 7.7, Detail A. 1. Remove the dust cover on the anti‐tip castor fork assembly. 2.

  • Page 69: Section 8-Suspension

    SECTION 8—SUSPENSION SECTION 8—SUSPENSION WARNING After ANY adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may occur. NOTE: The following procedures are for wheelchairs with the suspension option ONLY. Elastomers and Suspension NOTE: The performance of the wheelchair will be affected if elastomers are not the same on both  sides of the wheelchair. Replacing Rear Elastomers NOTE: For this procedure, refer to FIGURE 8.1 on page 70. 1.

  • Page 70: Replacing Front Elastomers

    SECTION 8—SUSPENSION Outside of Suspension Base Wheelchair Frame Outer Allen Screw Recess Elstaomer Pivot Pin Inner Allen Screw Axle Bracket Recess Mounting Holes Inside of Wheelchair Frame FIGURE 8.1 Replacing Rear Elastomers Replacing Front Elastomers CAUTION DO NOT use excessive force when removing/installing the threaded sleeve from/onto the fork.
  • Page 71 SECTION 8—SUSPENSION WARNING Use Loctite 242™when reinstalling the mounting screw into the threaded sleeve, otherwise the fork can become disassembled. Possible injury or damage could occur. 7. Apply Loctite 242 to the mounting screw. 8. Reinstall the mounting screw into the threaded sleeve and tighten securely. Upper Portion of Fork Mounting Screw (Use Loctite 242) Lower Portion of Fork Elstaomer Mounting Screw Threaded...

  • Page 72: Section 9-Wing/Bumper

    SECTION 9—WING/BUMPER SECTION 9—WING/BUMPER WARNING After any adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may occur. The bumper design creates a potential foot entrapment area. Ensure the occupant’s legs and feet are properly secured during use.

  • Page 73: Notes

    NOTES NOTES Part No 1122172 Everyday and Sport Series Wheelchairs...
  • Page 74 NOTES NOTES Everyday and Sport Series Wheelchairs Part No 1122172...

  • Page 75: Limited Warranty

    In the event you do not receive satisfactory warranty service, please write directly to Invacare Top End at the address on the back page. Provide dealer’s name, address, date of purchase, indicate nature of the defect and, if the product is serialized, indicate the serial number.
  • Page 76 Route de Cite-Ouest 2 identified by the symbols ™ and ®. All CH-1196 Gland, Switzerland trademarks are owned by or licensed to +44 22 354 6024 Invacare Corporation unless otherwise noted. Invacare, USA Dual Grip is a registered trademark of One Invacare Way Sun Metal Products, Inc.
