This manual MUST be given to the user of the product.
BEFORE using this product, read this manual and save for future reference.
Top End® Sports Series
Top End®T-5™ 7000 Series Tennis Chair, Pro™Tennis,
Top End®Schulte 7000 Series BB Chair, Pro™ BB
Basketball, Pro-2™ All Sport
EN Wheelchair
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Top End T-5 7000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Invacare Top End T-5 7000 Series

Summary of Contents for Invacare Top End T-5 7000 Series

  • Page 1 Top End® Sports Series Top End®T-5™ 7000 Series Tennis Chair, Pro™Tennis, Top End®Schulte 7000 Series BB Chair, Pro™ BB Basketball, Pro-2™ All Sport EN Wheelchair User Manual This manual MUST be given to the user of the product. BEFORE using this product, read this manual and save for future reference.
  • Page 2 All rights reserved. Republication, duplication or modification in whole or in part is prohibited without prior written permission from Invacare. Trademarks are identified by ™and ®. All trademarks are owned by or licensed to Invacare Corporation or its subsidiaries unless otherwise noted.

  • Page 3: Table Of Contents

    Wheelchair Operation ......34 Contents Operating Information ..... . . 34 Optional Folding Back .
  • Page 4 Installing/Replacing the Pro-2™ All Sport Adjustable Seat Upholstery ....60 Replacing Pro-2™ All Sport Screw-on Seat Upholstery ....... 60 Removing/Installing Screw-On Side Guards .

  • Page 5: General

    Max. user weight: 250 lb (113.4 kg) which, if not avoided, could result in death or serious injury. 1.3 Dealer/Technician Information The term “qualified technician” in this manual refers to an Invacare CAUTION! qualified technician. – Caution indicates a potentially hazardous situation...

  • Page 6: Safety

    WARNING! – Invacare products are specifically designed and manufactured for use in conjunction with Invacare accessories. Accessories designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products. 1171910-A~15...

  • Page 7: Transferring To And From Other Seats

    Safety 2.3 Transferring To and From Other Seats Reaching, Leaning, or Bending Forward WARNING! – Before attempting to transfer in or out of the wheelchair, every precaution should be taken to reduce the gap distance. Turn both casters parallel to the object you are transferring onto.

  • Page 8: Stability And Balance

    Top End® Sports Series This activity may be performed independently provided you have adequate mobility and upper body strength. 2.4 Stability and Balance WARNING! – The position of the footrest, center of gravity, back angle, the tautness of the back upholstery as well as the user’s condition are directly related to the wheelchairs stability.

  • Page 9: Safety Inspection Checklist

    Safety 2.5 Safety Inspection Checklist CAUTION! – As with any vehicle, the wheels and tires should be Every six months, take your wheelchair to a qualified checked periodically for cracks and wear, and should technician for a thorough inspection and servicing. Regular be replaced.
  • Page 10 Top End® Sports Series Inspect/Adjust Monthly Inspect upholstery fastening flaps to ensure they securely latch. Inspect click strap for any signs of wear. Ensure buckle latches. Verify hardware that attaches strap to frame is secure and undamaged. Replace if necessary. CAUTION! –...

  • Page 11: Overview

    Overview 3 Overview 3.1 Label Location 1171910-A~15...

  • Page 12: Typical Product Parameters

    Top End® Sports Series 3.2 Typical Product Parameters SCHULTE 7000 SERIES/T-5™ 7000 SERIES TENNIS FRAME: Rigid - 7005 Aluminum SEAT WIDTH: 14 - 21 inches (35.56 - 53.34 cm) - Outside to outside of seat frame in 1-inch (2.53 cm) increments SEAT DEPTH: 14 to 18-inches (35.56 - 45.72 cm) SEAT-TO-FLOOR (FIXED):...
  • Page 13 Overview SCHULTE 7000 SERIES/T-5™ 7000 SERIES TENNIS CHAIR REAR WHEELS*: 24–inch, 25–inch, 26–inch, 700C Sun® Double Walled Rim High Flange Hub (Standard) 24–inch, 25–inch, 26–inch, 700C Sun® Sun Equalizer (Optional) Spinergy®SLX Wheels 24–inch, 25–inch, 26–inch, 700C (Optional) REAR WHEEL TIRES: Primo 25-540 (Standard) 24–inch Kenda (Optional)
  • Page 14 Top End® Sports Series SCHULTE 7000 SERIES/T-5™ 7000 SERIES TENNIS CHAIR U240 Black - Adjustable Tension BACK UPHOLSTERY: 21 lbs (10.89 kg) Schulte 7000, 20lbs. T5 7000 WEIGHT: 30 lbs (13.6 kg) SHIPPING WEIGHT: 250 lbs (114 kg), HD optional available WEIGHT LIMITATION: 15 x 15-inch seat, rear wheels and minimal options are included in the weight.
  • Page 15 Overview TOP END PRO™ TENNIS AND TOP END PRO™ BB FRAME: Rigid - 6061T6 Aluminum SEAT WIDTH: 10 to 20 inches (30.48 - 50.8 cm) - Outside to Outside of SEAT FRAME in 1-inch (2.53 cm) increments SEAT DEPTH: 10 to 18-inches (35.56 - 45.72 cm) SEAT-TO-FLOOR Front - 19 to 21-inch (48.26 - 53.34 cm), Rear -15 to 21-inch (38.10 - 53.34 cm) ADJUSTABLE:...
  • Page 16 Top End® Sports Series TOP END PRO™ TENNIS AND TOP END PRO™ BB REAR WHEELS*: 24–inch, 25–inch, 26–inch Sun® Double Walled Rim High Flange Hub (Standard) 24–inch, 25–inch, 26–inch Sun® Sun Equalizer Wheels (Optional) 24–inch, 25–inch, 26–inch Spinergy®SLX Wheels (Optional) REAR WHEEL TIRES: Primo 25-540 (Standard) 24–inch...
  • Page 17 Overview 30 lbs (13.6 kg) SHIPPING WEIGHT: 250 lbs (114 kg) WEIGHT LIMITATION: 15 x 15-inch seat, rear wheels and minimal options are included in the weight. Refer to 3.4 Tire Pressure Conversion, page 24. All specifications are approximate. TOP END PRO-2™ ALL SPORT FRAME: Rigid —...
  • Page 18 Top End® Sports Series TOP END PRO-2™ ALL SPORT REAR WHEELS*: 25–inch Sun® Double Walled Rim High Flange Hub (Standard) REAR WHEEL TIRES: Primo 25-559 (Standard) 25–inch HANDRIMS: Aluminum Welded 6 Tab (Standard) WHEEL LOCKS: FRONT FORKS: Fits 3-inch (7.62 cm) Wheel Non-Suspension (Standard) CASTOR SIZE: 3-inch (7.62 cm) Solid (Standard) BACK UPHOLSTERY:...

  • Page 19: Component Identification

    Overview 3.3 Component Identification T-5™7000 Series Tennis 1171910-A~15...
  • Page 20 Top End® Sports Series Pro™ Tennis 1171910-A~15...
  • Page 21 Overview Schulte 7000 Series BB Basketball 1171910-A~15...
  • Page 22 Top End® Sports Series Pro™ BB 1171910-A~15...
  • Page 23 Overview Pro-2™ All Sport 1171910-A~15...

  • Page 24: Tire Pressure Conversion

    Top End® Sports Series 3.4 Tire Pressure Conversion KILOPASCALS PSI rating is printed on the side of the tire. Conversion formula: 1 psi=6.895 kPa (approx. 7 kPa). KILOPASCALS 1171910-A~15...

  • Page 25: Setup

    Setup 4 Setup 4.1 Components A A A B B B C C C D D D E E E Included in the package A: • Complete Wheel Assemblies • Introductory Bonus Set of Smooth Primo Tires • Base Frame B •...

  • Page 26: Tools

    Top End® Sports Series 4.2 Tools These tools may be needed: • Adjustable Wrench • 5mm Allen Wrench • 4mm Allen Wrench • Two 10 mm combination wrenches or socket 7/16 and 3/4 inch wrench An assistant to hold the seat frame in place while installing may also be helpful.

  • Page 27: Installing Adjustable Anti-Tip Wheel

    Setup 4.4 Installing Adjustable Anti-tip Wheel Release and loosen the quick release lever A attached to the anti-tip clamp B. Insert adjustable anti-tip wheel C into base frame D with wheel facing down. Move anti-tip to desired height above ground. The anti-tip should be about a finger’s width above the ground.

  • Page 28: Attaching The L Brackets

    Top End® Sports Series 4.5 Attaching the L Brackets There are two sets of brackets • The L Brackets for the front of the chair A • The Curved Brackets for the read of the chair B The L Brackets are installed with four bolts of the same size. The Curved Brackets are installed with two short bolts, two longer bolts, and two single bolts (bagged separately) C.
  • Page 29 Setup Attach the L Brackets A to the inside of the welded tabs C on the seat frame by: Inserting the bolt from the inside of the seat frame D. Use one flat washer, one split washer, and one nut for each bolt.

  • Page 30: Attaching The Curved Brackets To The Seat Frame

    Top End® Sports Series 4.6 Attaching the Curved Brackets to the Seat Remove the large bolts E from the bag and set them aside. Frame These are extra bolts and will not be used. Attach the curved brackets to the seat frame by: Aligning the curved bracket A to the inside of the welded tabs B on the seat frame.

  • Page 31: Attaching The Seat Frame To The Base Frame

    Setup 4.7 Attaching the Seat Frame to the Base Tighten the brackets on the seat frame so the nut is as close to the seat frame as possible. Frame Place the seat frame on top of base frame, aligning the brackets with the tabs welded in the rear and the holes drilled in the front of the frame.

  • Page 32: Attaching The Curved Brackets To The Base Frame

    Top End® Sports Series 4.8 Attaching the Curved Brackets to the Base Frame A A A Adjust the seat frame so the curved bracket is in the desired position and height. Line up the hole of a washer with the hole of the curved bracket on the outside of the base frame.

  • Page 33: Attaching The Footrest

    Setup 4.9 Attaching the Footrest Insert two bolts A through each two part clamp B. Attach the larger side of the two-part clamps to the base frame down tube C in the desired position. Attach the other side of the two-part clamp to the footrest D. Tighten the clamp using an Allen key E.

  • Page 34: Wheelchair Operation

    SEAT POSITIONING STRAP – SERIOUS INJURY CAN OCCUR IN THE 5.1 Operating Information EVENT OF A FALL FROM THE PRODUCT. – ALWAYS use your click strap (if equipped). Invacare WARNING! strongly recommends using the click strap as an WHEELCHAIR USER additional safeguard for the wheelchair user.
  • Page 35 Wheelchair Operation WARNING! WARNING! RISK OF INJURY OR DAMAGE RISK OF INJURY OR DAMAGE – Care, consideration and practice MUST be taken and – The user is responsible for normal upkeep and observed in the following safety points. Otherwise, maintaining the wheelchair in proper operating injury or damage may occur.

  • Page 36: Optional Folding Back

    Top End® Sports Series 5.2 Optional Folding Back Rear of Front of Wheelchair Wheelchair WARNING! RISK OF INJURY OR DAMAGE – ALWAYS perform these procedures in the presence of an assistant. The position of the footrest, center of gravity, back angle, the tautness of the back upholstery as well as the user’s condition are directly related to the stability of the wheelchair.
  • Page 37 Wheelchair Operation Adjust cam E to achieve desired position. An indexing notch F has been put on the cam D to help determine cam position for desired back angle adjustment. Secure cam in desired position. Torque all allen screws and locknuts to 960-1020 inch pounds (80-85 foot-pounds) (9.04 - 9.6 newton-metres).
  • Page 38 Top End® Sports Series 95° Back Angle to Seat Rail 90° Back Angle to Seat Rail 75° Back Angle to Seat Rail 85° Back Angle to Seat Rail 80° Back Angle to Seat Rail 1171910-A~15...

  • Page 39: Replacing Adjustable Tension Back Upholstery

    Wheelchair Operation 5.4 Replacing Adjustable Tension Back Replacing Adjustable Tension Back Upholstery Upholstery Slide the existing back upholstery up and off the back posts A. WARNING! Both back posts A should be adjusted to the same RISK OF INJURY OR DAMAGE height.

  • Page 40: Adjusting Back Height/Back Upholstery

    Top End® Sports Series 5.5 Adjusting Back Height/Back Upholstery Before unlatching the fastening flaps, observe the tautness of the back upholstery for installation. Unlatch the two fastening flaps that secure the top of the back upholstery to the back posts B and remove from the back posts. WARNING! RISK OF INJURY OR DAMAGE –...
  • Page 41 Wheelchair Operation Back Height (inches) 9-11 inches 10-14 inches 12-16 inches 14 - 18 inches (CM) (22.86 - 27.94 cm) (25.40 - 35.56 cm) (30.48 - 40.64 cm) (35.56 - 45.72 cm) Hole* Number 9 (22.86 cm) 10 (25.40 cm) 12 (30.48 cm) 14 (35.56 cm) 10 (25.40 cm)

  • Page 42: Removing Play From Rear Wheels

    Top End® Sports Series 5.6 Removing Play from Rear Wheels 5.8 Adjusting Quick-Release Axles Remove rear wheel and quick-release axle A from the WARNING! wheelchair. RISK OF INJURY OR DAMAGE Depress detent pin D in the quick-release axle A and slide axle –...

  • Page 43: Determining Toe In/Toe Out

    Wheelchair Operation 5.9 Determining Toe In/Toe Out Determine difference between two measurements. If difference between the two measurements is greater than 1/2-inch (1.27 Inflate all pneumatic tires to recommended tire pressures (listed cm) (0 + 1/4-inch (.63 cm) for maximum rollability), one of two on the sidewall of the tire).

  • Page 44: Adjusting Center Of Gravity

    Top End® Sports Series 5.10 Adjusting Center of Gravity Perform one of the following: Top End Pro Tennis/Top End Pro BB Models • For COG mounting positions 1-5 proceed to STEP 6 • To obtain COG mounting positions 6 and 7 perform the If necessary, remove the seat upholstery.
  • Page 45 Wheelchair Operation Detail “A” Detail “B” Detail “C” Detail “D” 1171910-A~15...

  • Page 46: Adjusting Wheelbase Width

    Top End® Sports Series 5.11 Adjusting Wheelbase Width T-5™7000 Series Tennis and Schulte 7000 Series BB Basketball Models Perform this procedure on one side of the wheelchair at a time for ease of adjustment. Adjusting Center of Gravity Option If necessary, remove the seat upholstery. Fixed Axle Tube Remove the four mounting screws A, coved spacers B, washer The wheelbase width can be increased/decreased by 1–inch...

  • Page 47: Fork

    CAUTION! – If the stem bolt is loose, threads on the bolt may be damaged. – If this occurs, contact Invacare. The front fork should rotate freely without side-to-side movement. If any side-to-side movement occurs, tighten bolts immediately. Pro™BB/Tennis Front Fork and Anti-tip Fork Replacement Place the empty wheelchair upside down so the bottom of the front fork A is easily accessible.

  • Page 48: Adjusting Seat Height For Top End Pro Tennis, Top

    Top End® Sports Series 5.13 Adjusting Seat Height for Top End Pro Schulte 7000/T-5™ 7000 Front Fork and Anti-Tip Fork Stem Assembly Replacement Tennis, Top End Pro BB, and Top End Pro-2™ All Sport The Front Fork and Anti-Tip Fork Stem Assembly parts may be purchased separately.
  • Page 49 Wheelchair Operation DETAIL “A” — REAR SEAT ADJUSTMENT DETAIL “B” — FRONT SEAT ADJUSTMENT 1171910-A~15...

  • Page 50: Removing/Installing The Seat Rail Extensions

    Top End® Sports Series 5.14 Removing/Installing the Seat Rail Extensions Only applies to Pro Tennis Facing the rear of the wheelchair, align the locking pin A with the hole on the wheelchair frame B. Insert the seat rail extension C into the wheelchair frame D so the locking pin A is in the hole on the wheelchair frame B.

  • Page 51: Replacing/Adjusting Tubular Footrest

    Wheelchair Operation 5.15 Replacing/Adjusting Tubular Footrest Tighten the allen screws A that secure the footrest to the wheelchair frame. WARNING! RISK OF INJURY OR DAMAGE WARNING! – After any adjustments, repair or service and before RISK OF INJURY OR DAMAGE –...

  • Page 52: Replacing/Adjusting Pro-2™ All Sport Tubular Footrest

    Top End® Sports Series 5.16 Replacing/Adjusting Pro-2™ All Sport Adjusting Tubular Footrest Loose the two screws A in the clamp B on the wheelchair frame C. Adjust the frame to the proper height by moving clamps vertically along the frame. Securely tighten the two screws in the clamp.

  • Page 53: Adjusting The Platform Footrest System

    Wheelchair Operation Align the holes in the platform footrest E with the holes in the Depth and Angle footrest clamp F. Secure the platform footrest C to the footrest clamp F with the two mounting screws A. Tighten securely. Angle Loosen the two mounting screws A in the platform footrest C.

  • Page 54: Removing/Installing The Footrest Click Strap

    Top End® Sports Series 5.19 Removing/Installing the Footrest Click 5.20 Adjusting Height of Swivel Anti-tip Caster strap Loosen mounting screw A and locknut B in clamp. Adjust the height of the anti-tip caster fork assembly D to the Remove the two mounting screws and locknuts A from the desired height by moving the bullet C up or down.

  • Page 55: Adjusting The Height Of The Telescoping Anti-Tip

    Wheelchair Operation 5.21 Adjusting the Height of the Telescoping Anti-tip This option is only available for the T-5™ 7000 series Wheelchair and the Pro™2 All Sport Wheelchair. Loosen mounting screw A and locknut B in the side of the clamp. Loosen the mounting screw A in the top of the clamp.

  • Page 56: Service

    6.1 Removing/Installing Rear Wheels CAUTION! – Changing the size of the rear wheels can affect the performance of the wheelchair. Contact Invacare at the telephone numbers on the back of this manual before changing rear wheel size. Perform one of the following: •...

  • Page 57: Handrim Replacement

    Service 6.2 Handrim Replacement Remove the rear wheel from the wheelchair. WARNING! RISK OF INJURY OR DAMAGE – After any adjustments, repair or service and before use, make sure all attaching hardware is tightened securely. Otherwise injury or damage may occur. –...

  • Page 58: Repairing/Replacing Rear Wheel Tire/Tube

    CAUTION! Repeat STEPS 1–3 for the opposite caster if necessary. – Changing the size of the rear wheels can affect the performance of the wheelchair. Contact Invacare at the numbers on the back cover before performing this procedure. If replacing rear wheels with a different size than what was...

  • Page 59: Replacing Adjustable Tension Seat Upholstery

    Service 6.5 Replacing Adjustable Tension Seat 10. Securely latch the four remaining adjuster straps A together. 11. Return wheelchair to upright position. Upholstery 12. Reinstall the seat cushion and back upholstery. WARNING! RISK OF INJURY OR DAMAGE – The seat upholstery and/or cushion MUST be cleaned regularly and/or replaced if incontinence is frequent.

  • Page 60: Installing/Replacing The Pro-2™ All Sport Adjustable Seat Upholstery

    Top End® Sports Series 6.6 Installing/Replacing the Pro-2™ All Sport 6.7 Replacing Pro-2™ All Sport Screw-on Seat Adjustable Seat Upholstery Upholstery Remove the seat cushion and back upholstery. Remove the seat cushion from the wheelchair. Position new seat upholstery A onto the wheelchair frame Remove the twelve mounting screws A that secure the existing ensuring the adjusting straps B hang over the right and left sides seat upholstery B to the seat frame C.

  • Page 61: Removing/Installing Screw-On Side Guards

    Service 6.8 Removing/Installing Screw-On Side Guards Align hole in sideguard with hole in back frame E of wheelchair. Place screw D through hole in sideguard and seat frame. Tighten Standard only on the Pro-2™ All Sport Wheelchair. securely. Removing Loosen locknuts on the two screws A through the seat frame B of wheelchair.

  • Page 62: Troubleshooting

    Top End® Sports Series 7 Troubleshooting 7.1 Troubleshooting WHEEL CHAIR CHAIR SLUGGISH CASTOR SQUEAKS LOOSENESS SOLUTIONS LOSES SPINS TOO VEERS TURN OR FLUTTERS IN CHAIR QUICKLY RIGHT CONTACT PERFORMANCE RATTLES OR LEFT WITH FLOOR Check tires for correct and equal pressure.
  • Page 63 Troubleshooting WHEEL CHAIR CHAIR SLUGGISH CASTOR SQUEAKS LOOSENESS SOLUTIONS LOSES SPINS TOO VEERS TURN OR FLUTTERS IN CHAIR QUICKLY RIGHT CONTACT PERFORMANCE RATTLES OR LEFT WITH FLOOR Check toe in/toe out. Tighten back upholstery. Change COG (if equipped). Change foot position.

  • Page 64: Maintenance

    – DO NOT overtighten hardware attaching to the Contact a qualified technician or Invacare customer support at frame. This could cause damage to the frame tubing. the telephone numbers on the back of this manual.

  • Page 65: Options

    Options 9 Options 9.1 Using the Alignment Gauge Inflate the tires to recommended tire pressures (listed on the sidewall of the tire). Place the wheelchair and alignment gauge on a flat surface. Position the alignment gauge near the rear of the rear tires. Loosen the alignment screw on each side.

  • Page 66: Installing The Clamp-On Sideguard

    Top End® Sports Series 9.2 Installing the Clamp-on Sideguard 9.3 Installing/Adjusting the Fold-in Sideguards Installing the Fold-in Sideguards Attach two clamps H to the wheelchair frame D and one clamp H to the back post E. Place the clamp A around the wheelchair frame B. Align the holes in the sideguard G with the holes on the clamps Insert the bolt through the clamp A and tighten to attach the clamp A to the wheelchair frame B.
  • Page 67 Options Fold-in sideguard should be able to be moved vertically (Detail “A”) and horizontally (Detail “B”). DETAIL “A” DETAIL “B” Adjusting the Fold-In Sideguards Height Lift sideguard to a level position (Detail “A”). Remove bolt from sideguard clamp D and sideguard C. Adjust sideguard C to desired height.

  • Page 68: Click Strap For Pro™ Tennis And Pro™ Bb

    Top End® Sports Series 9.4 Click strap for Pro™ Tennis and Pro™ BB 9.5 Click strap for Schulte 7000 BB Series Basketball Remove bolt from latch kit closest to front of chair. Insert bolt through hole in click strap, latch kit, and chair. Tighten securely.

  • Page 69: Additional Options

    Options 9.6 Additional Options D Ring Front A A A and Rear B B B Frame Protectors Strap encircles chair. End of strap and D Ring should be in front of chair. Seat Cushion Foam pieces covered in nylon wrapping the front and rear frames and fastened with hook and loop fasteners.

  • Page 70: Warranty

    DAMAGED BY CIRCUMSTANCES BEYOND INVACARE'S (3) years from the date of purchase from Invacare or a dealer, with a CONTROL, AND SUCH EVALUATION WILL BE SOLELY copy of the seller’s invoice required for coverage under this warranty.
  • Page 71 Warranty FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES WHATSOEVER. THIS WARRANTY SHALL BE EXTENDED TO COMPLY WITH STATE/PROVINCIAL LAWS AND REQUIREMENTS. 1171910-A~15...

  • Page 72: European, Australian, And New Zealand Limited Warranty And Customer Service Information

    Canada United Kingdom: 570 Matheson Blvd. E. Unit 8 Mississauga, Ontario L4Z 4G4 Invacare Limited, Pencoed Technology Park, Pencoed, Tel: (1) 800 668 5324, Fax: (1) 800 668 5478 Bridgend CF35 5HZ infocanada@invacare.com, www.invacare.ca Switchboard Tel: (44) (0)1656 776200, Fax: (44) (0)1656 776201...
  • Page 73 Warranty Ireland: Invacare Ireland Ltd, Unit 5 Seatown Business Campus, Seatown Road, Swords, County Dublin - Ireland Tel: (353) 1 810 7084, Fax: (353) 1 810 7085 ireland@invacare.com, www.invacare.ie 1171910-A~15...

  • Page 74: Usability Survey

    Are there too many warnings/cautions? The survey is also available online: http://www.invacare.com/TechnicalDocumentSurvey Are there warnings/cautions that you feel do not apply to this product? Please indicate your primary involvement with the product (choose one):...
  • Page 75 Thank You! Thank you for completing this survey. If you have any questions or we may be of assistance to you, please feel free to contact us. Send your survey to Invacare Technical Writing Department: TechnicalWriting@invacare.com or Invacare Corporation: One Invacare Way, Elyria, Ohio 44035 FAX: 440–329–6975 1171910-A~15...
