SOLTEK SL-85DRS User Manual page 63

Audio Device Allows you to enable /disable Audio Device on board.
USB Function Allows you to enable /disable USB Function on
USB KB/Mouse/FDD
Legacy Support
OnBoard FDC Allows you to enable /disable Floppy Disk Drive on
OnBoard Serial PortA/
PortB
Serial Port2 Mode Allows you to set serial Port 2 Mode.
OnBoard Parallel Port Allows you to configure parallel port on board.
Parallel Port Mode
Parallel Port IRQ/DMA If Parallel Port is set 378h, this option allows you to
OnBoard Game Port Allows you to configure Onboard Game port
The choices: Enabled; Disabled
board.
The choices: Enabled; Disabled
If USB Function is Enabled, this option appears to
Allow you to enable /disable these USB functions.
The choices: Enabled; Disabled
board.
The choices: Auto; Enabled; Disabled
Allows you to set Serial Port on board.
Select a logical COM port name and matching
address for the first and second serial ports.
Select an address and corresponding interrupt
for the first and second serial ports.
The choices: Auto; Disable; 3F8h/COM1;
2F8h/COM2; 3F8h/COM3; 2F8h/COM4
The choices: Normal; IrDA; ASKIR
The choices: Auto; Disabled; 378h; 278h; 3BCh
If Parallel Port is not disabled, this option allows
you to configure parallel port mode.
The choices: SPP; EPP; ECP; EPP+ECP
configure parallel port IRQ/DMA.
The choices: 5/7 for IRQ; 0/1/3 for DMA
address.
The choices: Disabled; 201h; 209h
63
Chapter 4 BIOS Setup
