8.3.1.2
Bus Contention
Bus contention arises when multiple nodes attempt to access and transmit message frames across
the J1850 bus simultaneously. This creates a conflict on the bus. The recognition of conflicting
symbols or bits on the bus is referred to as contention detection. For example, if a node observes
a difference between a symbol it transmits to the J1850 bus and the symbol that it detects on the
bus, that node has detected contention to the transmission of its message frame. Only one message
frame from one node vying for the bus wins arbitration on each symbol or bit of its frame. This
winning message frame does not experience or detect contention. The message frames that were
not awarded arbitration will experience contention.
8.3.1.3
Bit Arbitration
A bit arbitration scheme is used to resolve such conflicts as bus contention. The J1850 protocol
uses the carrier sense multiple access (CSMA) bit arbitration scheme. Bit arbitration is the pro-
cess of settling conflicts that occur when multiple nodes attempt to transmit one bit or symbol at
a time across a single bus. A symbol is simply a timing-level formatted bit. By definition, a node
that detects contention has lost arbitration and will discontinue transmitting any further symbols
remaining in its message frame. Remaining nodes vying for the bus will continue to send their
symbols until the next instance of contention is detected or arbitration is awarded. This process
continues until a complete message frame from one node has been transmitted. For details on this
arbitration scheme, refer to the "Bit Arbitration Example" on page 8-7.
8.3.1.4
Error Detection
The J1850 controller's error detection logic monitors the bus for four error conditions, and sets
the J1850BE interrupt pending bit in the J_STAT register if an error occurs. The following list
describes each error type:
•
CRC error — the calculated CRC checksum received on incoming messages has a value
other than C4H (the expected value for all received message frames).
•
bus symbol timing error — the symbol stream on the J1850 bus contains an invalid symbol.
An invalid symbol is any signal that is between 8 µs and 34 µs in duration.
•
incomplete byte error — an EOD/EOF symbol occurred,but was not on a byte boundary;
the number of bits recieved was not a multiple of eight.
•
no echo — the message is transmitted; however, the transmission's echo back through the
feedback loop to the receiver has not been detected within the allowable 60 µs window.
8.3.2
Symbol Synchronization and Timing Circuitry
The symbol synchronization and timing (SST) circuitry consists of a clock prescaler, digital filter,
delay compensation circuitry, and synchronization and symbol encoding/decoding circuitry. The
SST supports Huntzicker encoding of symbols, which entails 10.4 Kb/s variable pulse-width
(VPW) operation for valid edge detection on message receptions.
J1850 COMMUNICATIONS CONTROLLER
8-5
