Assembly and Operating Instructions for Outback®
NEW Apollo 4 Burner Gas BBQ
Drawings are not to scale.
Specifications subject to change
without prior notice.
•
For outdoor use only. Not for commercial use.
•
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
•
Warning: accessible parts may be very hot. Keep young children and pets away.
•
Do not move the appliance during use.
•
Turn off the gas supply at the gas bottle after use.
•
Any modification of the appliance, misuse, or failure to follow the instructions may
be dangerous and will invalidate your warranty. This does not affect your statutory
WARNING
rights.
•
Retain these instructions for future reference.
•
Leak test annually, and whenever the gas bottle is removed or replaced. Check that
the hose connections are tight and leak test each time you reconnect the gas bottle.
•
For Flare-up control please refer to the 'OPERATION' section of this manual.
FOR YOUR SAFETY
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
MF4493
FOR YOUR SAFETY
1.
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2.
A gas bottle not connected for use must not be
stored in the vicinity of this or any other
appliance.
0359

Advertisement

Table of Contents
loading

Related Manuals for Outback NEW Apollo 4

Summary of Contents for Outback NEW Apollo 4

  • Page 1 Assembly and Operating Instructions for Outback® NEW Apollo 4 Burner Gas BBQ MF4493 Drawings are not to scale. Specifications subject to change 0359 without prior notice. • For outdoor use only. Not for commercial use. • Read instructions before using the appliance. Failure to follow instructions could result in death, serious bodily injury, and/or property loss.

  • Page 2: Parts List

    Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’. Outback® CODE PART NEW Apollo 4 Burner Gas BBQ Hood (Pre-Assembled to Body) Hood Handle HOOD Heat Indicator...

  • Page 3: Parts Diagram

    Parts Diagram Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
  • Page 4 Hardware Reference Diagram Specifications subject to change without prior notice.
  • Page 5 Assembly IMPORTANT! TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver, • adjustable spanner or metric spanner set. Remove any internal component or packaging from the barbecue body. • Whilst every care is taken in the manufacture of this product, care must be taken during assembly in •...
  • Page 6 Attach the Upper Support (C11) to the left/right cabinet panel using M6x15 Bolts (D3x4pcs). Bottom View Attach the Storage Unit (C17) onto the Bottom Panel (C16) using M6x15 Bolts (D3x4pcs) as shown.
  • Page 7 Carefully turn the cabinet upside-down. Unscrew the Locknuts (C22) from both ends of the Axle (C21). Slide the axle through the corresponding holes in the left cabinet panel . Slide the Wheels (C19) over each end of the axle. Secure the wheels into place with the locknuts. Place the Wheel Hubcaps (C20) onto the outside of the wheels.
  • Page 8 Carefully place the Barbecue Body (B1) onto the cabinet assembly and fix using M6x15 Bolts (D3x4pcs) as shown. Remove the retaining bolts from one Door Handle (C12), and then attach the door handle onto the Left Door (C13) using the retaining bolts as shown.
  • Page 9 Remove the retaining bolts from one Door Handle (C12), and then attach the door handle onto the Right Door (C14) using the retaining bolts as shown. Fit the doors to the cabinet by depressing the spring pins and placing into the cabinet.
  • Page 10 Attach Side Shelf Panel , Tool Hook (C4 , C5) onto Side Shelf (C3) using M6x15 Bolts (D3x2pcs) and M6 Nut (D4x2pcs) as shown. step1 step2 step3 step4 Attach the side shelf assembly to the barbecue body using ST4.0x10 Screw (D2x1pcs) and M6x15 Bolts (D3x4pcs) as shown.
  • Page 11 Attach Side Burner Shelf Panel (C2) onto Side Burner Shelf (C1) using M6x15 Bolts (D3x2pcs) and M6 Nut (D4x2pcs) as shown. step1 step2 step4 step3 Attach the side burner shelf assembly to the barbecue body using ST4.0x10 Screw (D2x1pcs) and M6x15 Bolts (D3x4pcs) as shown.
  • Page 12 Attach the side burner valve onto side burner shelf using M4x10 Bolts (D5x2pcs) as shown. Press the Side Burner Knob (C7) onto side burner valve stem. Feed the venturi tube of the Side Burner (C8) through the hole in bottom of the side burner shelf, and fix it onto side burner shelf using a M4x10 Bolt (D5x1pcs) as shown.
  • Page 13 Unscrew the pre-assembled nut of the Ignition Button (B11). Insert the Ignition Button (B11) into the hole at the side burner shelf and secure with the pre- assembled nut. Connect the electrode wire to the ignitor. WARNING: BEFORE OPERATION, ENSURE SIDE BURNER WIRES ARE CONNECTED TO IGNITOR.
  • Page 14 Insert the Drip Tray (B10) by sliding it underneath the barbecue body. Lay the Flame Tamer (B6) carefully into the body ensuring it lies level within the body. Lay the Grill With Hole (B8) and Round Grill (B7) , Cooking Grill (B9) into place.
  • Page 15 Attach the Warming Rack (A4) to the Barbecue Body (B1) as shown. Attach the Beer Bottle Opener (B12) to the Right Cabinet Panel using M6x15 Bolt (D3x1pcs) , as shown.

  • Page 16: Leak Testing

    1. Maximum diameter or breadth is 320mm. 2. Maximum height (regulator included) is 700mm. ASSEMBLY IS NOW COMPLETE. PROCEED TO THE NEXT PAGE FOR INSTRUCTIONS ON OPERATION AND MAINTENANCE ALL JOINTS AND CONNECTIONS MUST NOW BE LEAK TESTED BEFORE USING THE BARBECUE.

  • Page 17: Gas, Regulator And Hose

    leak test. This is the only safe and sure way Important Information to detect any gas leaking from joints and connections of the barbecue after assembly. Please read these instructions carefully before assembly and use of your barbecue. Leak test annually, and whenever the gas bottle is removed or replaced.

  • Page 18: Installation

    Installation not covered by warranty. Preparation Before Cooking Selecting a Location To prevent foods from sticking to the cooking This barbecue is for outdoor use only and surface, please use a long handled brush to should be placed in a well-ventilated area, and apply a light coat of cooking or vegetable oil on a safe and even surface.
  • Page 19 baking food, such as joints of meat or whole or regulator. • Insert lit match through the right match- chickens, etc. More even cooking of food will actually be achieved by using the barbecue with lighting hole on the right side of the the hood down.

  • Page 20: Care And Maintenance

    extinguished by applying baking soda or salt Care and Maintenance directly onto the flame tamers. Always protect your hands when handling anything near the Regularly clean your barbecue between uses cooking surface of the barbecue and take care and especially after extended periods of to protect yourself from the flames.
  • Page 21 Stainless Steel (debris, insects) in either the burner portholes or the primary air inlet of the burners. Use a pipe Stainless Steel is a type of steel containing chromium, which offers high resistance to cleaner to clear obstructions. corrosion and heat by forming a protective layer of Chromium Oxide.

  • Page 22: Technical Specifications

    0.84mm Burner 359BR665 Propane: 37 mbar Gas Consumption: Outback® NEW Apollo 4 Burner Gas BBQ: 943g/hr Side Burner: 214g/hr Countries of Use: BE, CH, CY, CZ, ES, FR, GB, GR, IE, IT, LT, LU, LV, PT, 3+ (28-30/37) SK, SI...

  • Page 23: Troubleshooting

    Troubleshooting Problem Possible Cause Solution Burner will not light using LP gas bottle is empty Replace with full bottle the ignition system Faulty regulator Have regulator checked or replaced Obstructions in burner Clean burner Obstructions in gas jets or gas hose Clean jets and gas hose Electrode wire is loose is connected on Reconnect wire...
  • Page 24 Other parts are warranted for a period of one (1) year from the date of purchase. ♦ OUTBACK® will, within above periods, supply replacements for defective parts free of charge provided that: The product has not been used for trade, professional or hire purposes.
