Assembly and Operating Instructions for Outback®
Meteor Select Stainless Steel 4 and
Meteor Select Stainless steel 6 Burner Gas BBQ
MS-4464
Drawings are not to scale.
Specifications subject to change
without prior notice.
•
For outdoor use only. Not for commercial use.
•
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
•
Warning: accessible parts may be very hot. Keep young children and pets away.
•
Do not move the appliance during use.
•
Turn off the gas supply at the gas bottle after use.
•
Any modification of the appliance, misuse, or failure to follow the instructions may
be dangerous and will invalidate your warranty. This does not affect your statutory
WARNING
rights.
•
Retain these instructions for future reference.
•
Leak test annually, and whenever the gas bottle is removed or replaced. Check that
the hose connections are tight and leak test each time you reconnect the gas bottle.
•
For Flare-up control please refer to the 'OPERATION' section of this manual.
FOR YOUR SAFETY
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
MS-5664
FOR YOUR SAFETY
1.
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2.
A gas bottle not connected for use must not be
stored in the vicinity of this or any other
appliance.
0359

Advertisement

loading
Need help?

Need help?

Do you have a question about the MS-4464 and is the answer not in the manual?

Questions and answers

Related Manuals for Outback MS-4464

Summary of Contents for Outback MS-4464

  • Page 1 Assembly and Operating Instructions for Outback® Meteor Select Stainless Steel 4 and Meteor Select Stainless steel 6 Burner Gas BBQ MS-4464 MS-5664 Drawings are not to scale. Specifications subject to change 0359 without prior notice. • For outdoor use only. Not for commercial use.
  • Page 2 Parts List Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’. Outback® Outback® CODE PART Meteor Select Stainless Steel Meteor Select Stainless Steel 4 Burner Gas BBQ...
  • Page 3 Parts Diagram Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
  • Page 4 Hardware Reference Diagram Specifications subject to change without prior notice.
  • Page 5 Assembly IMPORTANT! • TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver, adjustable spanner or metric spanner set. • Remove any internal component or packaging from the barbecue body. • Whilst every care is taken in the manufacture of this product, care must be taken during assembly in case sharp edges are present.
  • Page 6 Attach the Wheel Skirt (C27, C28, C29) to the bottom panel using M4x10 Bolts (D8x7pcs) and M4 Nuts (D3x7pcs) as shown, Then fix the left / right wheel skirts onto the front wheel skirt using ST4.0x10 Screw (D4x2pcs) as shown. Unscrew the retaining bolts and retaining nuts from the Balance Weight (C30).
  • Page 7 Front Side Rear Side Carefully turn the assembled cabinet right side up. Attach Drip Tray Left Bracket (B10) to the right legs using ST4.0x10 Screws (D4x2pcs) as shown. Repeat above process for Drip Tray Right Bracket (B11). Attach the Upper Support (C21) to the front legs using M6x15 Bolts (D2x4pcs).
  • Page 8 Attach the Door Handle (C22) onto the Left Door (C23) using M6x15 Bolts (D2x2pcs). Repeat above process for Right Door (C24). Fit the door to the cabinet by depressing the spring pins and placing into the cabinet. Attach the Basket (C25) onto the right door as shown.
  • Page 9 Attach Body Support A (C14) onto the left rear leg and right front leg using M4x10 Bolts (D8x4pcs) , and attach Body Support B (C15) onto the right rear leg and left front leg using M4x10 Bolts (D8x4pcs) as shown. Carefully place the Barbecue Body (B1) onto the cabinet structure and fix using M6x40 Bolts (D1x8pcs) as shown.
  • Page 10 Attach Side Shelf Panel (C4) onto Side Shelf (C3) using M6x15 Bolts (D2x2pcs) and M6 Nut (D6x2pcs) as shown. Attach the side shelf assembly to the barbecue body using ST4.0x10 Screw (D4x2pcs) and M6x15 Bolts (D2x4pcs) as shown.
  • Page 11 Attach Side Burner Shelf Panel (C2) onto Side Burner Shelf (C1) using M6x15 Bolts (D2x2pcs) and M6 Nut (D6x2pcs) as shown. Attach the side burner shelf assembly to the barbecue body using ST4.0x10 Screw (D4x2pcs) and M6x15 Bolts (D2x4pcs) as shown.
  • Page 12 Attach the side burner valve and Knob Bezel (C10) onto side burner shelf using M4x10 Bolts (D8x2pcs) as shown. Press the Side Burner Knob (C11) onto side burner valve stem. Attach the Side Burner Firebox (C8) into the side burner shelf using M4x10 Bolts (D8x4pcs) as shown.
  • Page 13 Feed the tube of the Sear Burner (C12) through the guide hole in the side burner firebox, and fix it using M5x15 Bolt (D7x2pcs) as shown. Make sure that the end of tube is set over the gas outlet of side burner valve. Attach Side Burner Electrode (C9) into the side burner firebox using a ST4.0x10 Screws F# (D5) as shown.
  • Page 14 Attach Side Burner Lid (C6) onto the side burner shelf using Side Burner Lid Axle (C7) as shown. Place the Side Burner Grid (C5) onto the side burner shelf. NOTE: Make sure the base of cooking utensil to put on the side burner is larger than 150mm and smaller than 220mm.
  • Page 15 Insert the Side Burner Drip Tray (C13) by sliding Insert the Drip Tray (B12) by sliding it it underneath the side burner frame as shown. underneath the barbecue body. Place the Drip Pan (B13) in position as shown. Remove the plastic wrap from the Lava Rock (B6) and then distribute the Lava Rock evenly in the Basket (B7).

  • Page 16: Warming Rack

    Attach the Warming Rack (A3) to barbecue body as shown. ASSEMBLY IS NOW COMPLETE. PROCEED TO THE NEXT PAGE FOR INSTRUCTIONS ON OPERATION AND MAINTENANCE ALL JOINTS AND CONNECTIONS MUST NOW BE LEAK TESTED BEFORE USING THE BARBECUE. Leak test annually, and whenever the gas bottle is removed or replaced. Leak Testing Always perform a leak test in a well-ventilated area.

  • Page 17: Burner 4

    Important Information Before you use your barbecue, perform a leak test. This is the only safe and sure way Please read these instructions carefully to detect any gas leaking from joints and before assembly and use of your barbecue. connections of the barbecue after assembly. Leak test annually, and whenever the gas Retain these...

  • Page 18: Knob

    WARRANTY. Please consult your local gas Full coverage will cause excessive build-up dealer for the most suitable gas bottles and of heat and damage the barbecue. This is regulators. not covered by warranty. Preparation Before Cooking Installation To prevent foods from sticking to the cooking surface, please use a long handled brush to Selecting a Location apply a light coat of cooking or vegetable oil...

  • Page 19: Lava Rock

    • Ensure all knobs are in the off position. the option to form an ‘oven’ for roasting or baking food, such as joints of meat or whole Open the gas control valve on the gas bottle chickens, etc. More even cooking of food will or regulator.

  • Page 20: Drip Tray

    When flare-ups do occur, they can usually be Care and Maintenance extinguished by applying baking soda or salt directly onto the lava rock. Always protect your Regularly clean your barbecue between uses hands when handling anything near the cooking and especially after extended periods of surface of the barbecue and take care to storage.
  • Page 21 uses or in storage, clean with a soft brass wire soapy water and a cloth, or nylon-bristled brush brush. Be careful not to damage the cooking only. Do not use abrasives. Remove cooking surface, re-oil and cure. surfaces and burners before full cleaning. Do not immerse the gas controls or manifold in Burner water.

  • Page 22: Technical Specifications

    Burner or 37 mbar Propane 359BR665 Gas Consumption: Outback® Meteor Select Stainless Steel 4 Burner Gas BBQ: 943g/hr Outback® Meteor Select Stainless Steel 6 Burner Gas BBQ: 1258g/hr Side Burner: 328g/hr Countries of Use: BE, CH, CY, CZ, ES, FR, GB, GR, IE, IT, LT, LU, LV, PT,...

  • Page 23: Troubleshooting

    Troubleshooting Problem Possible Cause Solution Burner will not light using LP gas bottle is empty Replace with full bottle the ignition system Faulty regulator Have regulator checked or replaced Obstructions in burner Clean burner Obstructions in gas jets or gas hose Clean jets and gas hose Electrode or ignition button wire is loose Reconnect wire...
  • Page 24 (10) years from the date of purchase. Stainless steel and cast iron burners are warranted for a period of two (2) years from the date of purchase. OUTBACK will, within this period, supply replacements for defective parts free of charge provided that: ♦...

This manual is also suitable for:

Ms-5664
