Assembly and Operating Instructions for Outback®
Meteor Stainless steel 6 Burner Gas BBQ
MS4464
Drawings are not to scale.
Specifications subject to change
without prior notice.
•
For outdoor use only. Not for commercial use.
•
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
•
Warning: accessible parts may be very hot. Keep young children and pets away.
•
Do not move the appliance during use.
•
Turn off the gas supply at the gas bottle after use.
•
Any modification of the appliance, misuse, or failure to follow the instructions may
be dangerous and will invalidate your warranty. This does not affect your statutory
WARNING
rights.
•
Retain these instructions for future reference.
•
Leak test annually, and whenever the gas bottle is removed or replaced. Check that
the hose connections are tight and leak test each time you reconnect the gas bottle.
•
For Flare-up control please refer to the 'OPERATION' section of this manual.
FOR YOUR SAFETY
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
Meteor Stainless Steel 4 and
1.
2.
MS5664
FOR YOUR SAFETY
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
A gas bottle not connected for use must not be
stored in the vicinity of this or any other
appliance.
0359

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS4464 and is the answer not in the manual?

Questions and answers

Related Manuals for Outback MS4464

Summary of Contents for Outback MS4464

  • Page 1 Assembly and Operating Instructions for Outback® Meteor Stainless Steel 4 and Meteor Stainless steel 6 Burner Gas BBQ MS4464 MS5664 Drawings are not to scale. Specifications subject to change 0359 without prior notice. • For outdoor use only. Not for commercial use.

  • Page 2: Parts List

    Parts List Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’. Outback® Outback® CODE PART Meteor Stainless Steel Meteor Stainless Steel 4 Burner Gas BBQ...

  • Page 3: Parts Diagram

    Parts Diagram Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
  • Page 4 Hardware Reference Diagram Specifications subject to change without prior notice.
  • Page 5 Assembly IMPORTANT! TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver, • adjustable spanner or metric spanner set. Remove any internal component or packaging from the barbecue body. • Whilst every care is taken in the manufacture of this product, care must be taken during assembly in •...
  • Page 6 Attach the Wheel Skirt (C24, C25, C26) to the bottom panel using M4x10 Bolts (D8x7pcs) and M4 Nuts (D3x7pcs) as shown, Then fix the left / right wheel skirts onto the front wheel skirt using ST4.0x10 Screw (D4x2pcs) as shown. Unscrew the retaining bolts and retaining nuts from the Balance Weight (C27).
  • Page 7 Front Side Rear Side Carefully turn the assembled cabinet right side up. Attach Drip Tray Left Bracket (B10) to the right legs using ST4.0x10 Screws (D4x2pcs) as shown. Repeat above process for Drip Tray Right Bracket (B11). Attach the Upper Support (C18) to the front legs using M6x15 Bolts (D2x4pcs).
  • Page 8 Attach the Door Handle (C19) onto the Left Door (C20) using M6x15 Bolts (D2x2pcs). Repeat above process for Right Door (C21). Fit the doors to the cabinet by depressing the spring pins and placing into the cabinet. Attach the Basket (C22) onto the right door as shown.
  • Page 9 Attach Body Support A (C14) onto the left rear leg and right front leg using M4x10 Bolts (D8x4pcs) , and attach Body Support B (C15) onto the right rear leg and left front leg using M4x10 Bolts (D8x4pcs) as shown. Carefully place the Barbecue Body (B1) onto the body supports and fix using M6x40 Bolts (D1x8pcs) as shown.
  • Page 10 Attach Side Shelf Panel (C4) onto Side Shelf (C3) using M6x15 Bolts (D2x2pcs) and M6 Nut (D6x2pcs) as shown. Attach the side shelf assembly to the barbecue body using ST4.0x10 Screw (D4x2pcs) and M6x15 Bolts (D2x4pcs) as shown.
  • Page 11 Connect the Hose and Regulator Assembly (B5) to the barbecue. Ensure the mating faces of the connection are clean and not damaged. Do not use any sealing tape, paste, or liquid on the connection. The nut must be tightened with the use of a spanner. Do not use force which may damage the assembly.
  • Page 12 Attach the side burner shelf assembly to the barbecue body using ST4.0x10 Screw (D4x2pcs) and M6x15 Bolts (D2x4pcs) as shown. Attach the side burner valve and Knob Bezel (C10) onto side burner shelf using M4x10 Bolts (D8x2pcs) as shown. Press the Side Burner Knob (C11) onto side burner valve stem.
  • Page 13 Unscrew the pre-assembled nut of the Ignition Button (B14). Insert the Ignition Button (B14) into the hole at the side burner shelf panel and secure with the pre-assembled nut. Connect the electrode wire to the Ignition Button (B14).
  • Page 14 Attach the Side Burner Firebox (C8) into the side burner shelf using M4x10 Bolts (D8x4pcs) as shown. Feed the tube of the Sear Burner (C12) through the guide hole in the side burner firebox, and fix it using M5x15 Bolt (D7x2pcs) as shown. Make sure that the end of tube is set over the gas outlet of side burner valve.
  • Page 15 Main burner wire Side burner wire Attach Side Burner Electrode (C9) into the side burner firebox using a ST4.0x10 Screws F# (D5) as shown. Connect the electrode wire to the Ignition Button (B14). WARNING: BEFORE OPERATION, ENSURE BOTH MAIN BURNER AND SIDE BURNER WIRES ARE CONNECTED TO PUSH BUTTON IGNITOR.
  • Page 16 Place the Side Burner Grid (C5) onto the side burner shelf. NOTE: Make sure the base of cooking utensil to put on the side burner is larger than 150mm and smaller than 220mm. Insert the Side Burner Drip Tray (C13) by sliding Insert the Drip Tray (B12) by sliding it it underneath the side burner frame as shown.

  • Page 17: Warming Rack

    Remove the plastic wrap from the Lava Rock (B6) and then distribute the lava rock evenly in the Basket (B7). Lay the lava rock carefully into the body ensuring it lies level within the body. Lay the cooking grill (B8) and griddle (B9) into place. NOTE: Ensure that the lava rock lies directly underneath the grill.

  • Page 18: Leak Testing

    1. Maximum diameter or breadth is 320mm. 2. Maximum height (regulator included) is 700mm. ASSEMBLY IS NOW COMPLETE. PROCEED TO THE NEXT PAGE FOR INSTRUCTIONS ON OPERATION AND MAINTENANCE ALL JOINTS AND CONNECTIONS MUST NOW BE LEAK TESTED BEFORE USING THE BARBECUE.

  • Page 19: Gas, Regulator And Hose

    Important Information Before you use your barbecue, perform a leak test. This is the only safe and sure way Please read these instructions carefully to detect any gas leaking from joints and before assembly and use of your barbecue. connections of the barbecue after assembly. Leak test annually, and whenever the gas Retain these...

  • Page 20: Installation

    INCORRECT OR FAULTY REGULATOR IS understand IMPORTANT DANGEROUS AND WILL INVALIDATE ANY INFORMATION section of this manual. WARRANTY. Please consult your local gas Your barbecue is not designed to be used dealer for the most suitable gas bottles and with more than 50% of the cooking area as a regulators.

  • Page 21: Lava Rock

    Manual Ignition Instructions Alternatively, it can be used for heating pans or • Open the barbecue and side burner hood keeping food warm. or lid before lighting. Never light your Roasting Hood Cooking barbecue or side burner with the hood or lid Barbecues equipped with a roasting hood give closed.

  • Page 22: Care And Maintenance

    sparingly and try to avoid very cheap cuts of turn all the control valves fully clockwise to the meat or meat products as these tend to have a “Off” position, then switch off the gas supply at high fat and water content. Also, the burners the bottle.
  • Page 23 It is quite normal for surface rust to be present is not necessary to remove all the grease from on the cooking surface. If rust appears between the body. If you need to clean fully, use hot uses or in storage, clean with a soft brass wire soapy water and a cloth, or nylon-bristled brush brush.

  • Page 24: Technical Specifications

    Burner 359BR665 or 37 mbar Propane Gas Consumption: Outback® Meteor Stainless Steel 4 Burner Gas BBQ: 943g/hr Outback® Meteor Stainless Steel 6 Burner Gas BBQ: 1258g/hr Side Burner: 328g/hr Countries of Use: BE, CH, CY, CZ, ES, FR, GB, GR, IE, IT, LT, LU, LV, PT,...

  • Page 25: Troubleshooting

    Troubleshooting Problem Possible Cause Solution Burner will not light using LP gas bottle is empty Replace with full bottle the ignition system Faulty regulator Have regulator checked or replaced Obstructions in burner Clean burner Obstructions in gas jets or gas hose Clean jets and gas hose Electrode or ignition button wire is loose Reconnect wire...
  • Page 26 OUTBACK® WARRANTY OUTBACK® barbecues are warranted to the original purchaser against defects in materials and workmanship. OUTBACK® will supply replacements for defective parts free of charge provided that: The product has not been used for trade, professional or hire purposes.
