Outback Modern Classic Trooper Assembly And Operating Instructions Manual

Gas barbecues
Hide thumbs Also See for Modern Classic Trooper:
Table of Contents

Advertisement

Quick Links

Assembly and Operating Instructions for Outback®
Modern Classic Trooper and Outback® Modern Classic Hunter Gas Barbecues
Photographs are not to scale.
Specifications subject to change
without prior notice.
•
•
•
•
•
•
•
WARNING
•
FOR YOUR SAFETY
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
Gas Barbecues
For outdoor use only.
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
Warning: accessible parts may be very hot. Keep young children away.
Do not move the appliance during use.
Turn off the gas supply at the gas bottle after use.
Any modification of the appliance, misuse, or failure to follow the instructions may be
dangerous and will invalidate your warranty. This does not affect your statutory rights.
Retain these instructions for future reference.
Leak test your barbecue annually. Check the hose connections are tight and leak test
each time you reconnect the gas bottle.
FOR YOUR SAFETY
1.
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2.
A gas bottle not connected for use shall not be
stored in the vicinity of this or any other
appliance.
0359

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Modern Classic Trooper and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Outback Modern Classic Trooper

Summary of Contents for Outback Modern Classic Trooper

  • Page 1 Gas Barbecues Assembly and Operating Instructions for Outback® Modern Classic Trooper and Outback® Modern Classic Hunter Gas Barbecues Photographs are not to scale. Specifications subject to change 0359 without prior notice. • For outdoor use only. • Read instructions before using the appliance. Failure to follow instructions could result in death, serious bodily injury, and/or property loss.

  • Page 2: Parts List

    A. Parts List Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram’. Outback® Modern Outback® Modern CODE PART Classic Trooper Classic Hunter Hood (Pre-Assembled to Body)

  • Page 3: Parts Diagrams

    B. Parts Diagrams Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see hardware pack page.
  • Page 4 C. Hardware Reference Diagram Specifications subject to change without prior notice. D1,D2,D3 D5,D6...
  • Page 5 D. Assembly TOOLS NEEDED ASSEMBLY: Medium size flat blade or Phillips/crosspoint screwdriver, adjustable spanner or metric spanner set The assembly of this barbecue requires 2 people Whilst every care is taken in the manufacture of this product, care must be taken during assembly in case sharp edges are present.
  • Page 6 Turn the trolley over so that it stands on its side shelves. Slide the axle (C9) through the corresponding holes in the short legs (C2,C3). Place a washer (D7) on each end of the axle. Slide the wheels (C10) over each end of the axle. Secure the wheels into place with the locknuts (D8).
  • Page 7 Lay the assembled trolley on its side. Lay the body (B5) on its back and slide into position between the trolley legs. Warning: Care must be taken to ensure hood does not fall open unexpectedly. When positioning the body of the barbecue, ensure the control panel is on the same side as the legs with Velcro fastenings.
  • Page 8 Carefully stand the barbecue upright. Remove the plastic wrap from the flame tamer (B4) and lay them carefully into the body ensuring it lies level within the body. Lay the cooking grill(B1, B2) and griddle (B3) into place. 2 burner model configuration: Left — Large Cooking Grill, Right — Small Cooking Grill, 3 burner model configuration: Left —...
  • Page 9 Insert the Drip Tray (B9) by sliding it underneath the barbecue body. (Rear view of the barbecue trolley.) Attach the warming rack (A5) to the hood as Attach the screen (C6) to the front left/right legs shown. as shown.
  • Page 10 Connect the hose and regulator (B12) to the BBQ. Ensure the mating faces of the connection are clean and not damaged. Do not use any sealing tape, paste or liquid on the joint. The nut must be tightened with a spanner. Do not use force which may damage the assembly.
  • Page 11 Do not move the barbecue while alight. Model Butane Minimum Propane Minimum This barbecue must not be left unattended Bottle Size Bottle Size when lit. Outback® 15kg Parts of this barbecue become very hot – Trooper care must be taken when children, elderly Outback® 15kg** 10kg people, and animals are present.

  • Page 12: Installation

    connections regulator connections. G. Installation NEVER USE AN OPEN FLAME to test for leaks at anytime. If bubbles form over any of G1. Selecting a Location the joints, there is a leak. Turn off the gas This barbecue is for outdoor use only and supply and retighten all joints.
  • Page 13 procedure, turn all the knobs to the off smaller items, such as seafood, which could position. Close the gas valve on the gas fall through the spaces of a grill. They are bottle. Wait five minutes. Reattempt all of also suitable for cooking items that require the above steps.

  • Page 14: Care And Maintenance

    Outback® stockist. then turning up at a later stage in the cooking process. The barbecue should also not be Even when your barbecue is covered for its overloaded.
  • Page 15 I2. Burner Maintenance Provided that they are operating correctly, in normal usage, burning off the residue after cooking will keep the burners clean. The burners should be removed and cleaned annually, or whenever heavy build up is found, to ensure that there are no signs of blockage (fat, debris or insects for example), in either the burner portholes or the burner primary air inlet.

  • Page 16: Technical Specifications

    Gas / Burners stiffening, cracking, de-lamination of outer Approval Input Size Pressure covering, chemical degradation i.e. Outback® softening of outer coating by contact with Modern 0359 7.92kW Butane/28 Classic 359AS128 oil; -30mbar Trooper • Hose service failure such as – blistering, 1.05...

  • Page 17: Troubleshooting

    K. Troubleshooting Problem Possible Cause Solution Burners will not light using the igni- LP gas cylinder is empty Replace with full cylinder tion system Faulty regulator Have regulator checked or replace Obstructions in burners Clean burners Obstructions in gas jets or gas hose Clean jets and gas hose Electrode wire is loose or disconnected on elec- Reconnect wire...
  • Page 18 (10) years from the date of pur- chase. Stainless steel burners are warranted for a period of two (2) years from the date of pur- chase. OUTBACK UK will, within this period, supply replacements for defective parts free of charge provided that: ♦...
