Initial Settings menu
• You can see the effect of your changes in
the room graphic on the right of the
screen.
• Except for the subwoofer, you can set
speaker size to Large or Small. If the main
speaker cone in the speaker is 12cm or
more, set to Large, otherwise set to Small
(or Off if you don't have that speaker).
• If you set the front L and R speakers to
Small, the center and surround speakers
are automatically set to Small and the
subwoofer to On.
• The subwoofer can only be set to On or
Off.
Press  (cursor left) to go back to the
4
speaker list if you want to modify another
speaker, or press ENTER to exit the
Speaker Installation screen.
• For LPCM DVD-Audio only, if the C, LS, or
RS speakers is set to Off, the audio is
automatically downmixed to stereo.

Speaker Distance

• Default setting: all speakers 3 m
You only need to make this setting if you
connected this player to your amplifier using
the 5.1 channel analog outputs.
These settings do not affect any digital audio
output.
To get the best surround sound from your
system, you should set up the speaker
distances from your listening position.
Initial Settings
Digital Audio Out Audio Output Mode
Video Output Speaker Installation
Language Speaker Distance
Display Channel Level
Options
Speakers
Use the / (cursor up/down) to
1
select a speaker.
• The L and R speakers are paired; you can't
set them differently.
Initial Settings
Digital Audio Out
Video Output
L 3.0 m
Language
C 3.0 m
Display
R 3.0 m
Options
RS 3.0 m
Speakers
LS 3.0 m
Press  (cursor right) to change the
2
speaker distance for the highlighted
speaker.
Use the / (cursor up/down) to
3
change the distance.
• When you change the distance settings of
the front left (L) or front right (R) speakers,
all the other speaker distances change
relative to it.
• Front left/right (L/R) speaker distances
can be set from 30 cm to 9 m in 30 cm.
increments.
• The center speaker (C) can be set from
–1.5 m to 0 m relative to the front left/right
speakers.
• You can't set the subwoofer (SW)
distance.
09
2 Channel
Fix
67
En
