09 Initial Settings menu

Speakers

Audio Output Mode

• Set in Setup Navigator (Default: 2
Channel)
Initial Settings
Digital Audio Out
Video Output
Language
Display
Options
Speakers
If you connected this player to your amplifier
using the 5.1 channel analog outputs (front,
surround, center and subwoofer outs), set
this to 5.1 Channel; if you connected only the
stereo outs, set to 2 Channel.
• Even if you set Audio Output Mode to
5.1 Channel, you'll only get sound from
all speakers when playing a 5.1 channel
multi-channel disc.
• When set to 5.1 Channel, only the front
left/right channels are output from the
AUDIO OUT (2ch) jacks. Change to 2
Channel if you want to listen to
downmixed stereo audio (for example,
because you are listening through the
TV's built-in speakers).
• If you set to 2 Channel, Dolby Digital, DTS
and MPEG audio is mixed down to two
channels so you still hear all the audio
recorded on the disc. With DTS encoded
audio, you can choose how the signal is
downmixed to PCM audio. See DTS
DownMix above to change the downmix
setting.
66
En
Audio Output Mode
2 Channel

Speaker Installation

5.1 Channel
Speaker Distance
Channel Level
• Some DVD-Audio discs don't allow down-
mixing of audio. These discs always
output multi-channel audio regardless of
the setting made here.
Speaker Installation
• Set in Setup Navigator (default: L/R: Large
| C: Large | LS/RS: Large| SW: On )
You only need to make this setting if you
connected this player to your amplifier using
the 5.1 channel analog outputs.
This setting does not affect digital audio
output.
Initial Settings
Digital Audio Out Audio Output Mode
Video Output Speaker Installation
Language Speaker Distance
Display Channel Level
Options
Speakers
Use the Speaker Installation screen to tell the
player what kinds of speakers you have
connected.
Use the / (cursor up/down)
1
buttons to select a speaker.
• The L and R, and RS and LS speakers are
paired; you can't set them differently.
Initial Settings
Digital Audio Out
Video Output
L Large
Language
C Large
R Large
Display
RS Large
Options
LS Large
Speakers
SW
Press  (cursor right) to modify the
2
selected speaker.
Use the / (cursor up/down)
3
buttons to change the current setting.
2 Channel
Fix
On
