Audio Settings menu
4 Variable setting only: Set the channel
levels for each speaker.
Audio Settings
Channel Level L
Channel Level C
Channel Level R
Channel Level RS
Channel Level LS
Channel Level SW
• Use the / buttons (cursor up/down) to
select a speaker.
• Use the / buttons (cursor left/right)
to adjust the channel level for that
speaker.
Channel levels can be set from –6 dB to +6
dB in 1.0 dB increments.
5 Press ENTER to make the settings and
exit the audio settings screen.
• You can't adjust the channel level for any
speakers that are set to Off in the
Speaker Installation menu screen
(page 66).
• The Fix setting is equivalent to setting all
the channel levels to +6 dB. Therefore, the
Variable setting will usually sound
quieter than the Fix setting.

Speaker Distance

• Default setting: all speakers 3 m
To get the best surround sound from your
system, you should set up the speaker
distances from your listening position.
2/3 page
0.0 dB
0.0 dB
0.0 dB
0.0 dB
0.0 dB
0.0 dB
1 Press SETUP and select 'Audio
Settings' from the on-screen display.
press  (cursor down) until you reach
2
the Speaker Distance setting screen.
Audio Settings
Speaker Distance L
Speaker Distance C
Speaker Distance R
Speaker Distance RS
Speaker Distance LS
• Use the / buttons (cursor up/down) to
select a speaker.
• Use the / buttons (cursor left/right)
to adjust the distance from your listening
position to that speaker.
Front left/right (L/R) speaker distances can be
set from 30 cm to 9 m in 30 cm. increments.
The center speaker (C) can be set from –1.5 m
to 0 m relative to the front left/right speakers.
You can't set the subwoofer (SW) distance.
Surround left/right (LS/RS) speakers can be
set from –4.5 m to 0 m relative to the front left/
right speakers.
When you adjust the front left (L) or front right
(R) speaker, all the other speaker distances
are adjusted relative to that speaker.
3 Press ENTER to make the settings and
exit the audio settings screen.
• When playing DVD-Video and DVD-Audio
material with a sampling rate of 88 kHz or
higher, the speaker distance settings of
the center (C) can be adjusted up to a
maximum of –0.9 m, and the surround
speakers (LS/RS) up to a maximum of
–2.1 m.
3/3 page
3.0 m
3.0 m
3.0 m
3.0 m
3.0 m
07
51
En
