User Manual
Ascom d62 DECT Handset
IMPORTANT: Do not remove the handset while the text "Saving settings. Do not remove
6, 7 When the text "Please insert new phone in charger" is displayed, replace the old
handset with the new handset. The text "Restoring settings" is displayed.
IMPORTANT: Do not remove the handset while the text "Restoring settings" is
8 When the text "Phone successfully replaced. Please remove phone to restart."
appears inthe display, remove the handset from the charger. The handset is
automatically restarted.
LED Indications during Easy Replacement
The following table shows the LED indications that are used for the d62 and the charger
during the easy replacement procedure.
LED indication
Orange, flashing (1 000 ms on, 1 000
ms off)
Orange, flashing (100 ms on, 800 ms
off)
Red, flashing (100 ms on, 800 ms off) Error indication during Easy Replacement. Put
Red, flashing (900 ms on, 100 ms off) Error during Easy Replacement. Service needed
See also 12 Troubleshooting

14.3 Attach the Hinge-type Clip

Attach the hinge-type belt clip as described in the illustration below.
Figure 14. Screw the hinge-type clip into position.
2009-12-08/ Ver. C
phone from charger" is displayed. It may take several minutes.
displayed.
on page 65.
Description
File transfer during Easy Replacement.
"Change phone" indication during Easy
Replacement.
back old handset in charger.
for both handsets.
TD 92477GB
72
