INTRODUCTION
Features
All Models Feature:
• 1/3" Sony Super HAD™ II CCD
• Excellent low light performance using
Polaris Vision 2 technology.
• 0.15 Lux / F1.2 (Color)
0.001 Lux w/Sense-Up at x256
• 600 TV lines(Color) of resolution
• 3D Digital Noise Reduction (3D-DNR)
• OSD menu control
• Privacy Masking / Motion Detection
• VIDEO OUT(BNC)
• Operates in 12VDC or 24VAC
• Test Monitor Output
• Camera Mounting: Surface / Flush mounting
DPD23D
• Indoor Dome Model
• 3.6mm Fixed Lens

SPECIFICATIONS

General
Power source
Power consumption
Image sensor
Total pixels
Scanning system
Scanning frequency
Sync.system
Resolution
Min.Illumination
Video output
S/N Ratio
Operating Temperature
Power input
Video output
Lens mount
Lens
Operating humidity
DPD24D
• Indoor Dome Model
• 2.8-10.5mm Varifocal Day/Night Lens F1.4 DC Iris
DPV24D
• Vandal Resistant Dome Model
• 2.8-10.5mm Varifocal Day/Night Lens F1.4 DC Iris
DPV24TLX
• Vandal Resistant Dome Model
• 2.8-10.5mm Varifocal Day/Night Lens F1.4 DC Iris
• Smart IR technology
(Indoor Model only)
• ICR filter to give clear night vision
• ArcticPro technology with built-in heater
• 0 Lux with IR LED
DPD23D DPD24D
DC 12V / AC 24V +10%
2.5 Watts
3" Sony Super HAD™ II CCD
1/
15.734KHz(H), 59.95Hz(V)
Internal / Line Lock
0.15Lux / 0.001Lux
Sense Up at x256
1.0 Vp-p (75 ohm, composite)
more than 50dB (AGC OFF)
-10°C - +50°C
2-Pin terminal block (Detachable)
BNC Connector (2nd video RCA)
3.6mm Fixed 2.8 - 10.5mm F1.4 Varifocal DC Auto iris
0-90% (non-condensing)
-1-
DPV24D
811 (H) x 508 (V)
2:1 interlace
600 TV Lines
Fixed mount
DPV24TLX
10 Watts
(Heater On)
0 Lux IR LED On
-40°C - +50°C
