MEASUREMENTS
55.5 mm
2.19 in
40 mm
1.57 in
Vandal Dome Dimensions
112 mm
4.4 in
130 mm
Indoor Dome Dimensions
27 mm
1.1 in
Recess Mount Fitting dimensions
97.0 mm
3.82 in
112 mm
4.4 in
3/4'' -14
NPS thread
5.1"
130 mm
5.1"
39 mm
1.5 in
Ø 0.1"
3.5 mm
3.9"
100.0 mm
Base hole positions
137°
Underside Base hole positions
115 mm
4.5 in
Recess cutout and tting clearance.
-2-
3.4"
87 mm
100°
123°
7 mm
.28 in
