Appendix #1 - Camera Specifications

Appendix #1 - Camera Specifications

Hardware

Image Sensor
Monitoring
Connectors
Lens
Image Compression
CCD Adjustment
Resolutions
Video Adjustment
Image Compression
30
1/3" Sony Super HAD CCD
Horizontal Resolution: 520 TV Lines
0.15 LUX (F1.2)
Watchdog Chipset; monitors system voltage
tolerance and abnormal program execution
1 x x RJ-45 Connector for Ethernet (with Built-in Power
Over Ethernet IEEE 802.3af).
1 x Mini-DIN for RS-485/RS-232/GPIO/Video Out.
• RS-485: For external Pan/Tilt (PT) device
• RS-232: For Console connection
• GPIO: For one fully opto-isolated alarm input and
one relay output
• Video Out: For connecting to a CCTV monitor,
DVR, etc.
1 x Internal Microphone
1 x 12V DC Jack
1 x DC-Iris Power Connector
2 x LEDs to indicate network and power/system status.
• Standard package: Accepts CS mount type lenses
• Supports Direct drive lenses: Built-in VR for DC
level adjustment.
• MPEG-4 Simple Profile (SP); JPEG, MJPEG
• White Balance (WB/AWB): Auto
• gain Control (GC/AGC): On/Off
• Electronic Shutter (ES/AES): On/Off
• Full D1 (4CIF): NTSC = 720x480
• CIF: NTSC = 352x240
• QCIF: NTSC = 176x112
• Brightness, Contrast, Hue, Saturation, Frame
Rate, Bit Rate (Constant Bit Rate (CBR), Variable
Bit Rate (VBER) w/quality levels), Frame
Sequence (I-Frame, I-Frame/P-Frame), Group of
Pictures (GOP) size (Advanced Features).
16K~4M bits/sec (CBR/VBR configurable)
