INSTALLATION. INDOOR DOME
1
ow to lift
r
ease
b
nd pre-
screws
2
ng
tion.
b
on box
he base
ings)
c
s
from the
ed using
3
4
a
d
a) Remove camera cover by squeezing the back and front
b) Insert the included video test cable into the RCA jack
c)
Note: Lens adjustment levers are by default in the locked
a) Re-attach the camera cover, using the thumb screw as a guide, until it snaps into
place.
b) Reattach dome cover.
1a) Press down on the tab marked with an arrow to lift
up the dome cover slightly
1b) While pressing on tab, twist the dome cover counter-
clockwise to release dome cover
1c) Remove the camera base by unscrewing the base
locking screws (indicated by a padlock markings)
and turn camera module approx. 5 degrees counter-
clockwise to detach camera base from the camera
module.
a) Cut semi flush mounting hole into surface using
provided flush mounting template.
Note: Always cut according to the inside of the cutout
template
b) Insert dome into cutout. Make sure that the
mounting arms are not extended.
c)
Turn screwdriver clockwise to unlock all of the 3
mounting arms.
d) Continue turning clockwise to move mounting arms
down until they make contact with inner mounting
surface.
Note: Once mounting arms have made contact with
the inner mounting surface, do not apply too
much pressure to avoid damaging surface.
of the cover as indicated by the "PRESS" indicators at
the same time and lifting it up and away from the lens.
and connect to a test monitor to set up camera. (see
page 10)
Adjust camera viewing angle and secure into place by
tightening thumb screw using a flat head screwdriver.
Adjust lens and OSD as required.
position. Turn counter clockwise to unlock. Tighten
levers to secure lens setting.
-9-
(Semi-Flush Fitting)
