STEP 2: Attaching Back Pad and Seat Bottom to Bench Frame
14
10
Parts
• Bench Frame Assembly from Step 1
• Back Pad (#4)
• Seat Bottom (#5)
Hardware
• 5/16 x 2 1/2 inch Bolts (#10)
• 5/16 Washers (#14)
Tools
• 3/16 Allen Wrench
2-1 Align the Back Pad to the Bench Frame Assembly and secure with the hardware shown.
2-2 Tighten hardware.
2-3 Align the Seat Bottom to the Bench Frame Assembly and secure with the hardware shown.
2-4 Tighten hardware.
6
4
Qty
10
10
5
