Bowflex Xtreme
2 SE Home Gym
®
Assembly Manual

Advertisement

Table of Contents
loading

Related Manuals for Bowflex Bowflex Xtreme 2 SE

Summary of Contents for Bowflex Bowflex Xtreme 2 SE

  • Page 1 ® ® Bowflex Xtreme 2 SE Home Gym ® Assembly Manual...

  • Page 2: Table Of Contents

    . Before assembling your Bowflex Xtreme® 2 SE home gym please read the Assembly Manual and follow the Important Safety Precautions . For information on how to use your Bowflex Xtreme® 2 SE home gym, refer to the Bowflex Xtreme® 2 SE Owner’s Manual .

  • Page 3: Important Safety Instructions

    3. When attaching two pieces, gently lift and look through the bolt holes to help guide the bolt through the holes. 4 . As a general rule, and for all bolts and nuts on your Bowflex Xtreme 2 SE home gym, turn bolts or nuts toward the ®...

  • Page 4: Parts

    Parts ImporTAnT: LeAve ALL CABLes CoILed And wrApped unTIL your BowfLex xTreme 2 se Home Gym Is fuLLy AssemBLed. ® Note: Cables are not shown for clarity . Bowflex Xtreme 2 SE Assembly Manual ®...
  • Page 5 • 7/16" Combination Wrench • 9/16" Combination Wrench 7/32” • Adjustable Wrench 5/16” • Socket Wrench Set • Phillips Screw Driver • Flat Blade Screw Driver • Rubber Mallet • Utility Knife • Scissors Bowflex Xtreme 2 SE Assembly Manual ®...

  • Page 6: Hardware

    Button Head Screw 3/8” X 2 3/4” Button Head Screw 3/8” X 5” Hex Head Bolt 3/8” X 3 1/4” Button Head Screw 3/8” X 3/4” Cable End Stop Ball Button Head Screw 1/2” X 5 1/4” Snaphook Bowflex Xtreme 2 SE Assembly Manual ®...

  • Page 7: Assembly Guide

    Tool: 7/32” Hex Wrench Align the Lower Lat Tower Assembly over the Base Frame . Secure Lower Lat Tower Assembly using screws and washers as shown . finger tighten screws at this time. Bowflex Xtreme 2 SE Assembly Manual ®...
  • Page 8 Base Frame connector as shown . Slide the top of the Seat Support Rail onto the Lower Lat Tower Assembly connector as shown . Secure using screws and washers as shown . finger tighten screws at this time. Bowflex Xtreme 2 SE Assembly Manual ®...

  • Page 9: Install Squat Pulley Frame

    Lock the pulley in position near the Seat Support Rail . Install the hardware to attach the Squat Platform to the Left Squat Pulley Frame. Repeat Steps 4-3 through 4-5 for the Right Squat Pulley Frame. Bowflex Xtreme 2 SE Assembly Manual ®...

  • Page 10: Install Pulley Arms/Slider Pulleys

    • 2 Slider Pulleys w/ Decal (14) • Main Assembly Tools: 3/16 Hex Wrench Install a Slider Pulley onto each Pulley Arm as shown . Choose any of the four holes to secure . Bowflex Xtreme 2 SE Assembly Manual ®...
  • Page 11 . A rubber mallet may be needed to secure the end caps . note: The Leg Extension may be adjusted during workout to best suit your height and personal preferences . Bowflex Xtreme 2 SE Assembly Manual ®...
  • Page 12 Align the screw holes on the Seat Back Pad with the screw holes on the Seat Support Rail . 10-2 Install the Seat Back Pad to the Seat Support Rail using screws and washers as shown . Bowflex Xtreme 2 SE Assembly Manual ®...
  • Page 13 Seat Backbone hooks to secure the seat assembly on the Seat Support Rail as shown in Figure 11b . note: Reverse procedure to remove seat . Detail 11a Detail 11b - Back View Bowflex Xtreme 2 SE Assembly Manual ®...
  • Page 14 • 4 Washers 3/8" (B) • 2 Nylock Nuts 3/8 (O) Tool: 7/32" Hex Wrench 13-1 Attach the Ab Crunch Crossbar to the Ab Crunch Bracket as shown. Tighten all hardware. from this step . Bowflex Xtreme 2 SE Assembly Manual ®...

  • Page 15: Install Upper Lat Tower Assembly

    Place one washer over the end of each screw . Attach the Lat Pulley Housing to the Lat Tower by installing the screws loosely into the aligned holes as shown in Figure 14b . do not tighten hardware at this time. Bowflex Xtreme 2 SE Assembly Manual ®...

  • Page 16: Cable/Pulley Routing Overview

    15 Cable and Pulley Routing – Overview The figure below shows all Pulleys on the Bowflex Xtreme 2 SE home gym. Subsequent images show how to connect and route each of the Cables through the Pulleys. (The Ab Crunch Station is not shown for clarity.) Connecting the Cables is much easier with a second persn assisting you .

  • Page 17: Cable & Pulley Routing

    Figure 16 and holding the cable tightly where indicated . 16-3 Repeat for the Left Pulley Cable (on the Left Frame Rail), without loosening your grip on the Right Pulley Cable. Bowflex Xtreme 2 SE Assembly Manual ®...
  • Page 18 Tighten all hardware. note: You will probably need to push the Power Rod unit out of the way for this step. The Power Rod unit is ® ® not pictured for the sake of clarity. Bowflex Xtreme 2 SE Assembly Manual ®...
  • Page 19 Pulleys . See Figure 18b . note: The Cable End Stop Ball Core should fit over the Ferrue when installed correctly . Rotate the Core to align it with the groove in the Ball . Bowflex Xtreme 2 SE Assembly Manual ®...

  • Page 20: Cable End Stop Ball With Core

    Once the Cable End Stop Balls are attached, hook each Rod Hook onto the Lat Pulley Housing as shown in Figure 18d . Figure 18d - Rod Hooks Storage on Lat Pulley Housing Bowflex Xtreme 2 SE Assembly Manual ®...

  • Page 21: Connect Right Squat Cable

    Continue to guide the Cable down through the Inner Right Frame Rail Pulley (9), up through the Right Pulley Arm Pulley (10), as shown in Figure 19 . Finally, insert the Cable End through the Cable End Stop Ball and attach the Cable Core, as completed during Step 18 . Bowflex Xtreme 2 SE Assembly Manual ®...
  • Page 22 Assembly Guide step 19b Cable and Pulley Routing – Connect Left Squat Cable through the Floating and Main Assembly Pulleys Repeat the same procedure completed during Step 19 for the Left Squat Cable. Bowflex Xtreme 2 SE Assembly Manual ®...

  • Page 23: Final Inspection

    Warning Labels and Serial Number section of the Owner’s Manual . Failure to visually check and test assembly before use can cause damage to the equipment. It can also cause serious injury to users and bystanders . Bowflex Xtreme 2 SE Assembly Manual ®...
  • Page 24 Nautilus Bowflex Schwinn Fitness Universal ® ® ® ® 8001515.010913.B...
