CEILING RECESS KIT (SOLD SEPARATELY)
1. Prepare ceiling cut out & ceiling box.
Ceiling box minimum internal dimensions must
be as showin table.
Heater must be installed with heater surface at
least 2400mm above the floor level.
Supporting structure
for fireproof insulation
Ceiling surface
2. From below, bring ceiling frame up and into
ceiling cut out.
3. Fasten ceiling frame to ceiling box through
mounting holes with fasteners (not supplied).
4. Prepare heater for installation
Attach mounting brackets to both ends
of heater with supplied fasteners
2 layers of minimum 16mm (5/8")
fireproof insulation must be installed
on all surfaces of ceiling box
MODEL
2000W & 4000W
3000W & 6000W
Fireproof
insulation
www.bromicheating.com
A
DIMENSION "A"
1170mm (46")
1463mm (57.5")
368mm
(14.5")
