- Page 1 ® XTENDEX Series ST-C6HD(-A)-300 ST-C6HD-(A)IR-300 300 FOOT HDMI, STEREO AUDIO AND IR EXTENDER Installation and Operation Manual MAN111 Rev Date 11/21/2012...
- Page 2 Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202. CHANGES The material in this guide is for information only and is subject to change without notice. Network Technologies Inc reserves the right to make changes in the product design without reservation and without notification to its users.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction..................................1 Materials ..................................2 Connectors And LEDs..............................3 Limitations ..................................4 Preparation for Installation .............................. 4 Installation ..................................5 Installing The Local Unit .............................. 5 Installing The Remote Unit ............................6 Connect the CATx Cables ............................7 Plug-in and Boot Up.............................. -
Page 4: Introduction
(i.e. ST-C6HD-CLA-L-300M) CEC support for remote display is standard. Optional dual HDMI support- includes two local units in one case- add a “2” to the model number (i.e. ST-C6HD-LA-2L-300M) Model Single HDMI Dual HDMI CEC Support Local Access Support Support ST-C6HD-LA-L-300M ST-C6HD-CLA-L-300M ST-C6HD-LA-2L-300M ST-C6HD-CLA-2L-300M... -
Page 5: Materials
1 to pin 1, etc. (see page 14 for proper EIA/TIA 568 B wiring method) Note: Use only CAT7 solid STP cable if the extender is a rackmount module (i.e. ST-C6HD-LA-L-300M). HDMI male-male cable to connect a HDMI source or display (Order NTI # HD-xx-MM where xx=3, 6, 9,14,20,30, 50,75,100 and 150 foot cable). -
Page 6: Connectors And Leds
NTI XTENDEX 300 Foot HDMI and IR Extender CONNECTORS AND LEDS LABEL CONNECTOR DESCRIPTION 24VDC- 1.0A 1.0mm Power Jack connection jack for the AC adapter (only the Local or the Remote Unit needs to be powered, not both) CATx RJ45 connector for connecting the CAT5e/6/6a/7 cable between the Local and Remote units Yellow LED... -
Page 7: Limitations
NTI XTENDEX 300 Foot HDMI and IR Extender LIMITATIONS • The use of CAT5e unshielded or all shielded CATx cabling will reduce the maximum distance and resolution. PREPARATION FOR INSTALLATION • Locations should be chosen for the monitor that also has space to connect the Remote unit within the distance provided by the cables. -
Page 8: Installation
NTI XTENDEX 300 Foot HDMI and IR Extender INSTALLATION Installing The Local Unit Connect an HD-xx-MM or DVI-HD-xx-MM cable (page 2) between the video source and the "HDMI In" connector on the Local Unit (Figure 1). If stereo audio support is present, a stereo audio source can be connected (Figure 2). Figure 1- Connect the XTENDEX Local Unit to the source Figure 2- Connect the XTENDEX Local Unit to stereo audio source... -
Page 9: Installing The Remote Unit
NTI XTENDEX 300 Foot HDMI and IR Extender Installing The Remote Unit Position the Remote Unit such that the CATx cable and the monitor cables can each reach the Remote Unit without putting strain on the cables. 2. Connect a HD-xx-MM (or DVI-HD-xx-MM cable depending upon what connector your display will accept) to the female HDMI video connector labeled "HDMI Out"... -
Page 10: Connect The Catx Cables
NTI XTENDEX 300 Foot HDMI and IR Extender Connect the CATx Cables Connect the CATx cable between the “CATx” ports on the Local and Remote Unit. (See Figure 5.) When properly inserted the cable ends should snap into place. WARNING: Never connect the XTENDEX to an Ethernet card, Ethernet router, hub or switch or other Ethernet RJ45 connector of an Ethernet device. -
Page 11: Rackmount Modules (Optional)
NTI XTENDEX 300 Foot HDMI and IR Extender Rackmount Modules (optional) If ST-C6-300M Series XTENDEX rackmount Local Unit modules are being installed, then an ST-C6RCK-24 Rackmount Extender Module Tray must be used (sold separately) to mount the modules to a RACK. The ST-C6RCK-24 provides a convenient mounting method for up to 12 Local XTENDEX modules. -
Page 12: Connect The Hdmi Video/Audio Source
NTI XTENDEX 300 Foot HDMI and IR Extender Figure 9- Secure each power supply to the tray Connect the HDMI Video/Audio Source Connect a cable between the Local Unit and the HDMI video source. Figure 10 shows the proper connections for the ST- C6HD-LA-2L-300M using a HD-xx-MM cable (xx= 3, 6, 9,14,20,30, 50,75,100 and 150 foot length). -
Page 13: Connect Local Display(S)
NTI XTENDEX 300 Foot HDMI and IR Extender Connect Local Display(s) If desired, connect a local display to the local unit at “HDMI-1 OUT”. If your extender module has dual HDMI support, up to two local displays can be connected. Figure 11- Connect Local Display Connect the CAT7 cable Connect the CAT7 cable to a “CATx-1”... -
Page 14: Plug-In And Boot Up
NTI XTENDEX 300 Foot HDMI and IR Extender Plug-in and Boot Up Plug the power cord(s) from the video and audio source(s) into power outlet(s). Connect the AC adapter power connectors to the 24VDC port on either the Remote or Local Unit. (AC adapter shown in Figure 13) Plug the AC adapter into a power outlet. -
Page 15: Infrared Control
NTI XTENDEX 300 Foot HDMI and IR Extender INFRARED CONTROL Model ST-C6HD-IR-300 (and each rackmount module) includes ports for connecting an infrared emitter and receiver (included) to work in conjunction with the IR remote control used to operate the video/audio source. Connect the receiver to the “IR IN”... -
Page 16: Technical Specifications
NTI XTENDEX 300 Foot HDMI and IR Extender TECHNICAL SPECIFICATIONS Video Video Compatibility PC Resolution up to 1920x1200 @60Hz / HDTV resolution up to 1080p Video Connectors HDMI Type A Female Input Video Signal TMDS Video Color Format Standard (24bit); Deep color (30,36bit);RGB, 4:2:2, 4:4:4 HDMI Version HDMI 1.3a DVI Support... -
Page 17: Interconnection Cable Wiring Method
Figure 15- View looking into RJ45 female TROUBLESHOOTING Each and every piece of every product produced by Network Technologies Inc is 100% tested to exacting specifications. We make every effort to insure trouble-free installation and operation of our products. If problems are experienced while installing this product, please look over the troubleshooting chart below to see if perhaps we can answer any questions that arise. -
Page 18: Warranty Information
NTI XTENDEX 300 Foot HDMI and IR Extender WARRANTY INFORMATION The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact Network Technologies Inc at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070 or visit our website at http://www.networktechinc.com/return-policy.html for information regarding repairs and/or returns.
