- Page 1 ® XTENDEX Series ST-C6DVI(A)-300 ST-C6DVI(A)-IR-300 300 FOOT DVI VIDEO, AUDIO AND IR EXTENDER Installation and Operation Manual MAN135 Rev Date 8/22/2011...
- Page 2 Note: CATx connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series products should not be run underground, outdoors or between buildings.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction..................................1 Materials ..................................2 Connectors and LEDs ..............................3 Limitations ..................................4 Preparation for Installation .............................. 4 Installation ..................................5 Installing The Remote Unit ............................5 Installing The Local Unit .............................. 5 Connect the CATx Cables ............................6 Plug-in and Boot Up.............................. -
Page 4: Introduction
NTI XTENDEX 300 Foot DVI Video, Audio and IR Extender INTRODUCTION The XTENDEX Series ST-C6DVI-300 CAT6 DVI and IR Extender (XTENDEX) is designed to enable the video and audio output from one digital video and stereo audio source to be viewed and heard by a remote user. Each video extender consists of a local unit that connects to an DVI video source and optional IR emitter, and a remote unit that connects to an DVI display and optional IR receiver as much as 300 feet away via Category 5e,6, 6a or 7 twisted-pair cable. -
Page 5: Materials
SA-xx-MM 3.5mm male-to-male stereo plug to connect a self-powered audio source (where xx=3, 6, 9 foot cable) Always use the shortest possible cable for best performance. Contact your nearest NTI distributor or NTI directly for all of your KVM needs at 800-RGB-TECH (800-742-8324) in US & Canada or 330-562-7070 (Worldwide) or at our website at http://www.networktechinc.com... -
Page 6: Connectors And Leds
NTI XTENDEX 300 Foot DVI Video, Audio and IR Extender CONNECTORS AND LEDS LABEL CONNECTOR DESCRIPTION 24VDC- 1.0A 1.0mm Power Jack connection jack for the AC adapter (only the Local or the Remote Unit needs to be powered, not both) IR Out 3.5mm Stereo Jack... -
Page 7: Limitations
Locations should be chosen for the monitor that also has space to connect the Remote unit within the distance provided by the cables. If extension cables are needed, contact NTI for the cables required. • The CATx cables must be run to the locations where the Remote and Local units will be connected. Be careful to route the cables away from any sources of magnetic fields or electrical interference that might reduce the quality of the video signal (i.e. -
Page 8: Installation
NTI XTENDEX 300 Foot DVI Video, Audio and IR Extender INSTALLATION Installing The Remote Unit 1. Position the Remote Unit such that the CATx cable and the monitor cables can each reach the Remote Unit without putting strain on the cables. -
Page 9: Connect The Catx Cables
NTI XTENDEX 300 Foot DVI Video, Audio and IR Extender Connect the CATx Cables Connect the CATx cable between the “CATx” ports on the Local and Remote Unit. (See Figure 3.) When properly inserted the cable ends should snap into place. -
Page 10: Infrared Control
NTI XTENDEX 300 Foot DVI Video, Audio and IR Extender INFRARED CONTROL Model ST-C6DVI(A)-IR-300 includes ports for connecting an infrared emitter and receiver (included) to work in conjunction with the IR remote control used to operate the video/audio source. Connect the receiver to the “IR IN” port on the Remote Unit and the emitter to the “IR OUT”... -
Page 11: Technical Specifications
NTI XTENDEX 300 Foot DVI Video, Audio and IR Extender TECHNICAL SPECIFICATIONS Video Video Compatibility PC Resolution up to 1920x1200 @60Hz / HDTV resolution up to 1080p Video Connectors DVI Female Input Video Signal TMDS Video Color Format Standard (24bit) DVI Support DVI 1.0... -
Page 12: Interconnection Cable Wiring Method
NTI XTENDEX 300 Foot DVI Video, Audio and IR Extender INTERCONNECTION CABLE WIRING METHOD The CATx connection cables between the Remote and Local are terminated with RJ45 connectors and must be wired according to the EIA/TIA 568 B industry standard. Wiring is per the table and drawing below. -
Page 13: Warranty Information
NTI XTENDEX 300 Foot DVI Video, Audio and IR Extender WARRANTY INFORMATION The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact Network Technologies Inc at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070 or visit our website at http://www.networktechinc.com/return-policy.html...
