NTI XTENDEX ST-C6DVIA-IR-R-300 Installation And Operation Manual

300 foot dvi video and ir extender

Advertisement

Quick Links

®
XTENDEX
Series
ST-C6DVI-IR-300
300 FOOT DVI VIDEO AND IR EXTENDER
Installation and Operation Manual
MAN135 Rev Date 9/25/2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XTENDEX ST-C6DVIA-IR-R-300 and is the answer not in the manual?

Questions and answers

Summary of Contents for NTI XTENDEX ST-C6DVIA-IR-R-300

  • Page 1 ® XTENDEX Series ST-C6DVI-IR-300 300 FOOT DVI VIDEO AND IR EXTENDER Installation and Operation Manual MAN135 Rev Date 9/25/2018...
  • Page 2 Note: CATx connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series products should not be run underground, outdoors or between buildings.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction..................................1 Materials ..................................1 Connectors and LEDs ..............................2 Limitations ..................................3 Preparation for Installation .............................. 3 Installation ..................................4 Installing The Remote Unit ............................4 Installing The Local Unit .............................. 4 Connect the CATx Cables ............................5 Plug-in and Boot Up..............................
  • Page 4: Introduction

    Always use the shortest possible cable for best performance. Contact your nearest NTI distributor or NTI directly for all of your KVM needs at 800-RGB-TECH (800-742-8324) in US & Canada or 330-562-7070 (Worldwide) or at our website at http://www.networktechinc.com...
  • Page 5: Connectors And Leds

    NTI XTENDEX 300 Foot DVI Video and IR Extender CONNECTORS AND LEDS LABEL CONNECTOR DESCRIPTION 24VDC- 1.0A 1.0mm Power Jack connection jack for the AC adapter (only the Local or the Remote Unit needs to be powered, not both) IR Out 3.5mm Stereo Jack...
  • Page 6: Limitations

    WARNING: The CATx connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series products must be wired straight through (pin 1 to pin 1, pin 2 to pin 2, etc.) The use of a CROSSOVER CABLE will...
  • Page 7: Installation

    NTI XTENDEX 300 Foot DVI Video and IR Extender INSTALLATION Installing The Remote Unit 1. Position the Remote Unit such that the CATx cable and the monitor cables can each reach the Remote Unit without putting strain on the cables.
  • Page 8: Connect The Catx Cables

    NTI XTENDEX 300 Foot DVI Video and IR Extender Connect the CATx Cables Connect the CATx cable between the “CATx” ports on the Local and Remote Unit. (See Figure 3.) When properly inserted the cable ends should snap into place.
  • Page 9: Infrared Control

    NTI XTENDEX 300 Foot DVI Video and IR Extender INFRARED CONTROL The ST-C6DVI-IR-300 includes ports for connecting an infrared emitter and receiver (included) to work in conjunction with the IR remote control used to operate the video source. Connect the receiver to the “IR IN” port on the Remote Unit and the emitter to the “IR OUT”...
  • Page 10: Technical Specifications

    NTI XTENDEX 300 Foot DVI Video and IR Extender TECHNICAL SPECIFICATIONS Video Video Compatibility PC Resolution up to 1920x1200 @60Hz / HDTV resolution up to 1080p Video Connectors DVI Female Input Video Signal TMDS Video Color Format Standard (24bit) DVI Support DVI 1.0...
  • Page 11: Interconnection Cable Wiring Method

    NTI XTENDEX 300 Foot DVI Video and IR Extender INTERCONNECTION CABLE WIRING METHOD The CATx connection cables between the Remote and Local are terminated with RJ45 connectors and must be wired according to the EIA/TIA 568 B industry standard. Wiring is per the table and drawing below.
  • Page 12: Warranty Information

    NTI XTENDEX 300 Foot DVI Video and IR Extender WARRANTY INFORMATION The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact Network Technologies Inc at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070 or visit our website at http://www.networktechinc.com/return-policy.html...
