Page 1: User Guide
User Guide YOYOCam G3 GSM Remote Surveillance Camera V0.2, January 2013... -
Page 2: Important Information
When inserting or removing the SIM card, do not touch the gold connectors. Use only the approved YOYOMotion G3 AC power adaptor (Do not use a G2 power adaptor). The AC Power adaptor is for indoor use only and must not be used in damp conditions. -
Page 3: Gsm Calls And Gsm Messages
Do not allow the battery contacts to touch any metal object. The battery should not be exposed to temperatures above 60°C. Use only the supplied battery or accessory/service replacement battery from YOYOMotion. Dispose of any old battery in accordance with the disposal guidelines below. ... -
Page 4: About This Guide
Improvements and changes to this text necessitated by typographical errors, inaccuracies of current information or improvements to products, may be made by YOYOMotion AB at any time and without notice. Product specifications are subject to change without prior notice. -
Page 5: Table Of Contents
Built-in Stand ..............................13 Mounting Bracket ............................13 STEP 3. Set Up YOYOCam G3....................15 STEP 4 – Refine YOYOCam G3 Settings ..................16 Optimize image settings ..........................16 Configure the sensors which detect an alarm condition ................16 Configure how YOYOCam signals alarms ...................... 16 Change the Password............................ - Page 6 Alarm Settings ........................31 Warning Bleep from YOYOCam........................31 SMS Message..............................31 MMS Message .............................. 31 Email Message .............................. 32 Voice Call............................... 33 Precedence ..............................33 To check Alarm settings ..........................33 Image settings ........................34 YOYOCam G3 User Guide v0.2 Page 6...
- Page 7 Arming and Disarming YOYOCam .................... 46 Emergency Button ........................46 Emergency Numbers............................. 47 Voice Dialling Mode (Default option) ......................48 SMS/MMS Mode ............................50 Remote Control Battery ......................50 Guest Commands ......................51 Request one image ............................51 YOYOCam G3 User Guide v0.2 Page 7...
- Page 8 Detecting & Communicating Alarms......................58 Images................................59 Built-in Temperature Sensor ......................... 59 Wireless Sensors & Remote Control ......................59 Advanced Settings & Check Settings......................59 GUEST ............................ 60 Specifications ......................... 61 Configuration Limits........................ 61 YOYOCam G3 User Guide v0.2 Page 8...
-
Page 9: Yoyocam Features
Receive images at pre-set intervals according to a Simple configuration via SMS commands; schedule request images by SMS Remote control arms and disarms YOYOCam and Link up to 15 wireless detectors, for example has programmable Emergency button window, door, smoke YOYOCam G3 User Guide v0.2 Page 9... -
Page 10: Get To Know Your Yoyocam
Get to know your YOYOCam YOYOCam unit Status Indicator YOYOCam G3 User Guide v0.2 Page 10... -
Page 11: Remote Control
Master and each added Emergency number. See Emergency Button for further information. NOTE: The remote controls are powered by an internal battery. Please refer to your retailer or YOYOMotion if the Remote Control stops working. YOYOCam G3 User Guide v0.2 Page 11... -
Page 12: Getting Started
Getting started STEP 1. Prepare YOYOCam G3 1. An antenna is included and ready-mounted at delivery. To remove it, gently unscrew the nut by hand. To attach it again or use a different antenna, align the plug with the antenna connector and screw it on gently by hand until it is finger tight. -
Page 13: Step 2. Mount Yoyocam G3
Replace the Locate the battery cover in place and slide it up until it stops. Snap the cover closed by pressing the right or left side (not the middle) of the lower edge as shown. STEP 2. Mount YOYOCam G3 Built-in Stand Un-clip the stand and rotate backwards. - Page 14 Make test shots (e.g. using command #03#) to check image quality. Adjust angle and/or position of YOYOCam until images are optimal. Check that the infrared body detection and/or camera movement detection is working. YOYOCam G3 User Guide v0.2 Page 14...
-
Page 15: Step 3. Set Up Yoyocam G3
STEP 3. Set Up YOYOCam G3 1. Plug the power adaptor in to an AC outlet. 2. Slide the power switch to the ON position to turn on YOYOCam 3. After approximately 40 seconds, YOYOCam bleeps to indicate that the GSM network has been found. -
Page 16: Step 4 - Refine Yoyocam G3 Settings
STEP 4 – Refine YOYOCam G3 Settings Here are some of the settings that you may like to change in order to configure YOYOCam to your needs. Optimize image settings By default, YOYOCam takes five images at an interval of 0.5 seconds between each shot. The image size is 320 x 240 pixels. -
Page 17: Change The Password
NOTE: The number shall be entered in international format with + and country code. For more information, see Master, Users & Guests. Add Remote Controls You can also configure how YOYOCam responds when the Emergency Button is pressed. See Using the Remote Control for more information. YOYOCam G3 User Guide v0.2 Page 17... -
Page 18: Interacting With Yoyocam
Note: Commands always begin and end with the # character, and a # separates each required parameter. Note: In some cases all parameters must be supplied; in others like the one above, as many parameters as required can be supplied. YOYOCam G3 User Guide v0.2 Page 18... -
Page 19: Telephone Numbers
YOYOCam warns you by SMS when external power is connected and disconnected: External power applied: External power – resumed External power removed: External power lost. Running on battery. For more information see SMS Notification when power supply changes. YOYOCam G3 User Guide v0.2 Page 19... -
Page 20: Arm And Disarm Yoyocam
YOYOCam will arm itself after 20 seconds. The Status indicator shows when armed. To disarm YOYOCam using the Remote Control: 1. Press the button on the Remote Control. 2. YOYOCam bleeps 3. Status Indicator shows YOYOCam G3 User Guide v0.2 Page 20... -
Page 21: Arming And Disarming Yoyocam By Schedule (Day And Time)
Thursday Friday Saturday Sunday Monday to Friday To enable/disable Arm/Disarm by schedule: Turn On: #128#1# Response: Scheduled arming and disarming - activated Turn Off: #128#0# (Default) Response: Scheduled arming and disarming – deactivated YOYOCam G3 User Guide v0.2 Page 21... -
Page 22: Dial In And Listen To Audio
To request a single image to be sent to your mobile by MMS: Command: #03# Response: MMS message containing the image Note: The image size is the size set by the Image Size setting (default 320 x 240) See Image settings YOYOCam G3 User Guide v0.2 Page 22... -
Page 23: Request A Sequence Of Images
The interval between the images is determined by the Image Interval setting (default 0.5 seconds). The images are sent by MMS if a mobile number is provided, or E-mail (using the mobile operator’s MMS service to send to the E-mail address) if an E-mail address is provided. YOYOCam G3 User Guide v0.2 Page 23... -
Page 24: Request Yoyocam To Automatically Send Images According To A Schedule
Note: The image size is the size set by the Image Size setting (default 320 x 240). Day(s) of the week Sunday Monday Tuesday Wednesday Thursday Friday Saturday Every day Monday to Friday To enable/disable periodic image sending: Turn On: #115#1# (Send to mobile number using MMS, default) YOYOCam G3 User Guide v0.2 Page 24... - Page 25 Response: Periodic sending of images – enabled Turn On: #115#2# (send to configured e-mail accounts using MMS) Turn Off: #115#0# (Default) Response: Periodic sending of images - disabled YOYOCam G3 User Guide v0.2 Page 25...
-
Page 26: Yoyocam Settings
To change Master number: Command: #14#NewMasterNumber# Example: #14#+46702222222# Response: New MASTER phone number is +46702222222 Note: response is sent to the old master number. No response is sent to the new Master number. YOYOCam G3 User Guide v0.2 Page 26... -
Page 27: User
To find out which User numbers are set: Command: #07# Response: MMS message including YOYOCam status and User number(s) To delete a user: Command: #113#UserNumber# Example: #113#+46703333333# Response: +46703333333 USER phone number has been deleted YOYOCam G3 User Guide v0.2 Page 27... -
Page 28: Guest Users & Password
Emergency Button Notifications By default, the Master is contacted when the Emergency Button on the Remote Control is pressed. To configure this feature and add other contacts, see Emergency Button. YOYOCam G3 User Guide v0.2 Page 28... -
Page 29: Sensor Settings
Note: By default the IR LEDs will be constantly lit when the Camera Motion Detection is activated and the surrounding light is poor. YOYOCam G3 User Guide v0.2 Page 29... -
Page 30: Motion Detection Parameters
The default is one detection per minute (#141#1#1#) Built-in Temperature Sensor YOYOCam G3 includes a built-in temperature sensor. You can set a temperature range and get a warning by SMS if the observed temperature goes outside that range. Turn On:... -
Page 31: Alarm Settings
Turn On: #12#1# (Default) Response: MMS notification upon Alarm - enabled Turn Off: #12#0# Response: MMS notification upon Alarm – disabled See Image settings for more information about the image format. YOYOCam G3 User Guide v0.2 Page 31... -
Page 32: Email Message
To update, send the command again and the new Email address over-writes the old one. Command: #108#EmailAddress# Example: #108#night.warden@yoyomotion.com# Response: Current alarm notification Email address is: night.warden@yoyomotion.com To delete all E-mail addresses: Command: #109# Response: E-mail address - deleted NOTE: Master user only. -
Page 33: Voice Call
Where multiple alarm options are enabled, the precedence is SMS first, (MMS or Email) next, Voice Call (last) To check Alarm settings Command: #07# Response: An MMS containing the status of these settings YOYOCam G3 User Guide v0.2 Page 33... -
Page 34: Image Settings
YOYOCam defaults to 5 images at size 2 (320 x 240 pixels). The images are taken at the interval selected via the Image Interval command. Default interval is 0.5 seconds. Command: #33#Quantity# Example: #33#2# Response: Number of Alarm images has been set to 2 YOYOCam G3 User Guide v0.2 Page 34... -
Page 35: Image Interval
Command: #34#BrightnessLevel# Example: #34#3# Response: Brightness has been set to 3 Note: Check your image brightness setting in each different condition (e.g. daylight, night) to make sure that the image is captured ok. YOYOCam G3 User Guide v0.2 Page 35... -
Page 36: Image Contrast
YOYOCam names the sensors Sensor1, Sensor2, Sensor3… 3. YOYOCam emits a bleep tone and the indicator flashes alternate red and green. 4. YOYOCam sends a notification SMS: YOYOCam is ready to connect a sensor. Please activate the sensor now. YOYOCam G3 User Guide v0.2 Page 36... -
Page 37: Checking Wireless Sensors
Sensor deleted successfully FrontDoor To delete several wireless sensors in one command: Command: #112#SensorDescription1#SensorDescription2#SensorDescription3# … Example: #112#FrontDoor#BackDoor#SmokeAlarm# Response: Sensor deleted successfully FrontDoor BackDoor SmokeAlarm To Delete all sensors: Command: #112# Response: Sensor deleted successfully YOYOCam G3 User Guide v0.2 Page 37... -
Page 38: Advanced Settings
Text of the original SMS message Note: The forwarded SMS will be charged to the account or prepay balance of the SIM in YOYOCam, according to the mobile operator’s service plan for that SIM. YOYOCam G3 User Guide v0.2 Page 38... -
Page 39: Sms Notification When Power Supply Changes
To set number of alarms before auto-disarm: Command: #139#Times# Example: #139#3# Response: Disarm the YOYOCam after 3 alarms Note: Times must be at least 1. Note: After the given number of alarms, YOYOCam auto-disarms and sends an SMS: YOYOCam G3 User Guide v0.2 Page 39... -
Page 40: Language
(Default) Response: Disarm the YOYOCam after several alarms - disabled Language English: #127#1# Response: Language set to English As SIM Card: #127#0# (Swedish for a Swedish SIM, otherwise English) Response: Svenska - installt YOYOCam G3 User Guide v0.2 Page 40... -
Page 41: Check Settings & Status
Periodic sending of images - disabled Day: Monday-Friday Time: 0000-0800 Image capture interval:60 1700-2358 Image capture interval:60 Periodic arming and disarming - enabled Parameters are: Day: daily Time: 0800-1700 Warning signal - enabled Infrared sensor - enabled YOYOCam G3 User Guide v0.2 Page 41... -
Page 42: Get Help With Commands
If your SIM is issued by some ‘Mobile Virtual Network Operators’ (MVNO) then you may need to enter the correct settings. NOTE: Automatic MMS configuration is disabled once a manual setting command has been sent. YOYOCam G3 User Guide v0.2 Page 42... -
Page 43: Checking Mms Configuration
TDC Song SE #145#TDCSE# TDCSE MMS settings configured Telmore DK #145#TELMORE# TELMORE MMS settings configured Universal #145#UNIVERSAL# UNIVERSAL MMS settings configured Ventelo NO #145#VENTELONO# VENTELNO MMS settings configured Ventelo SE #145#VENTELOSE# VENTELOSE MMS settings configured YOYOCam G3 User Guide v0.2 Page 43... -
Page 44: Manual Mms Configuration
To clear out any manual settings and return to automatic MMS configuration: Command: #54# Response: MMS Settings removed. New MMS parameter is auto-changed to: MMSC: http://mmsc.t-mobile.co.uk:8002 IP: 149.254.201.135 WAP Port: 9201 HTTP Port: 8080 APN: general.t-mobile.uk YOYOCam G3 User Guide v0.2 Page 44... - Page 45 APN User: user APN Password: one2one YOYOCam G3 User Guide v0.2 Page 45...
-
Page 46: Using The Remote Control
YOYOCam calls the Master number. When the Master answers, the audio from YOYOCam can be heard. If the Master does not answer, YOYOCam will call twice more (total three attempts) before giving up. YOYOCam G3 User Guide v0.2 Page 46... -
Page 47: Emergency Numbers
To delete an Emergency number: Command: #107#EmergencyNumber# Example: #107#+46703333333# Response: +46703333333 Emergency phone number deleted To delete several Emergency numbers in a single command: Command: #107#EmergencyNumber1#EmergencyNumber2#EmergencyNumber3# Example: #107#+46704444444#+46705555555#+46706666666# Response: +46704444444 +46705555555 +46706666666 Emergency phone number - deleted YOYOCam G3 User Guide v0.2 Page 47... -
Page 48: Voice Dialling Mode (Default Option)
The call is allowed to ring for approximately 40 seconds before YOYOCam hangs up and rings the next number in the sequence.The LED indicator displays (ongoing voice call). For example, YOYOCam is configured with Master, EmergencyNumber1 and EmergencyNumber2. YOYOCam G3 User Guide v0.2 Page 48... - Page 49 Mobile phone networks normally allow the called party to end the call and are therefore emergency calls to mobile phones should be able to end the call and immediately make a new call. Note: YOYOCam cannot send MMS images while a voice call is in progress. YOYOCam G3 User Guide v0.2 Page 49...
-
Page 50: Sms/Mms Mode
Response: SMS and MMS notification upon emergency alarm – enabled Remote Control Battery The remote controls are powered by an internal battery. Please refer to your retailer or YOYOMotion if the Remote Control stops working. YOYOCam G3 User Guide v0.2... -
Page 51: Guest Commands
Note: The format of the image is controlled by the Master. Note: Quantity can be 1-8 for image sizes 160 x 120 and 320 x 240. Quantity must be 1-2 for image size 640 x 480. YOYOCam G3 User Guide v0.2 Page 51... -
Page 52: Factory Reset
4. After approx. 10 seconds, YOYOCam bleeps twice and the indicator LED goes green and then flashes red 5. You may now release the Reset key. To perform Factory Reset by SMS (Master only) Command: #08#Password# Response: YOYOCam has been reset to default settings YOYOCam G3 User Guide v0.2 Page 52... -
Page 53: Troubleshooting
International format or vice versa. YOYOCam treats national and international format of the same number as two different numbers. Possible Solution: Set up User number in national or international format and re-test. Set twice in both formats. YOYOCam G3 User Guide v0.2 Page 53... - Page 54 Problem: The SIM-card does not have MMS service activated at delivery. Possible solution: Easily done by sending an activation-SMS from a regular mobile phone with the SIM-card inserted. Consult the homepage or contact your mobile operator. YOYOCam G3 User Guide v0.2 Page 54...
- Page 55 Problem: The SIM-card is from a “Mobile Virtual Network Operator”. Possible solution: See STEP3 Set Up YOYOCam G3 to set up listed MVNOs. Send #145# to your YOYOCam’s mobile number and get the list of MVNO codes. Problem: The SIM-card is from a foreign mobile operator Get current MMS settings with #55# Set up MMS manually.
-
Page 56: Command Summary
#204#0# or #204#1# Disable (0) forwarding received SMS to Master (default). Enable (1) forwarding SMSs from non-registered user numbers to Master #208#position# Place Master number at position (1 to 10) in emergency number calling list YOYOCam G3 User Guide v0.2 Page 56... -
Page 57: Mms Settings
Get this list or virtual operators with Quick-Command setup. #124#MMScenter# Set MMS Centre #125#parameters# Set MMS Access Point and parameters #125#GatewayIP#WAPGatewayPort#HTTPGatewayPort#APN#APNus ername#APNpassword# #55# Check MMS parameters #54# Delete current MMS parameters; YOYOCam reverts to auto- configuration mode. YOYOCam G3 User Guide v0.2 Page 57... -
Page 58: Master & User
Set camera motion sensitivity from 1 (least sensitive) to 5 (most sensitive). Default 4. #142#0# Sets number of pictures taken at motion detection to be the same as the number taken at IR body detection. YOYOCam G3 User Guide v0.2 Page 58... -
Page 59: Images
Use this setting with #22#1# movement detection. #31#2# Infrared LED light is always off. #07# Check the settings and status #09# or #09#1# Get the command list (#09# for SMS, #09#1# for MMS response) YOYOCam G3 User Guide v0.2 Page 59... -
Page 60: Guest
Take a number (Quantity 1-8) of images and send to a phone or E- mail address (To is the mobile number or E-Mail address; note 1) Note 1: Maximum Quantity is limited to 2 when image size is set to 3. YOYOCam G3 User Guide v0.2 Page 60... -
Page 61: Specifications
Max number of Users Max number of Email accounts 1 for Master and 10 for Users Max number of Emergency numbers 9 (including the Master-number) © Copyright, 2013 Yoyomotion AB. All rights reserved. YOYOCam G3 User Guide v0.2 Page 61...
