Summary of Contents for YOYOMOTION YOYOCam G2
-
Page 1: User Guide
User Guide YOYOCam G2 GSM Remote Surveillance Camera... -
Page 2: Important Information
All GSM based functions, such as calls and SMS messaging, are dependent on network performance and availability. While YOYOCam G2 is on a voice call (Alarm call, Emergency call, dial-in to listen call), it is unable to send SMS or MMS messages. ... -
Page 3: Gsm Calls And Gsm Messages
Improvements and changes to this text necessitated by typographical errors, inaccuracies of current information or improvements to products, may be made by YOYOMotion AB at any time and without notice. Product specifications are subject to change without prior notice. - Page 4 YOYOCam G2 Features Insert a SIM card, perform a few simple configuration steps and YOYOCam is ready to guard your property. Infrared body detector and camera-based Infrared LEDs enable the camera to capture movement detection images in the dark Alarm by SMS (text), MMS and Email (including...
- Page 5 Get to know your YOYOCam YOYOCam unit Status Indicator...
-
Page 6: Remote Control
Remote Control When the Emergency button is pressed, YOYOCam calls the Master and any added Emergency numbers up to three times in sequence until the call is answered, at which point the audio from YOYOCam is heard. SMS/MMS mode can be used as an alternative. When the Emergency button is pressed YOYOCam acknowledges with a bleep, and sends an SMS alert followed by an MMS with an image to the Master and each added Emergency number. -
Page 7: Getting Started
Getting started STEP 1. Prepare YOYOCam G2 1. Slide the battery compartment cover downwards. 2. Lift the battery cover away from the device. 3. Hold the SIM card in line with the slot (gold contacts on the underside) and slide it in to position. - Page 8 STEP 2. Mount YOYOCam G2 A mounting bracket is included with YOYOCam Threaded tip Round lock nut Locking screw Fixing hole To mount YOYOCam: 1. Mount the bracket on the wall, ceiling or other surface as required. 2. Attach YOYOCam to the threaded tip of the bracket.
- Page 9 STEP 3. Set Up YOYOCam 1. Connect the cable from the power adaptor to the power inlet socket on the back panel, as shown. 2. Plug the power adaptor in to a wall outlet or socket strip. 3. Slide the power switch to the UP position to turn on YOYOCam 4.
-
Page 10: Optimize Image Settings
Default Sensor and Alarm Behaviour When armed, YOYOCam will raise the alarm when a sensor is triggered. By default, the built-in infrared body sensor is enabled and camera movement detection is disabled. See Sensor Settings for more information. When a sensor triggers the alarm, YOYOCam sends an SMS to the Master followed by an MMS with images. -
Page 11: Add Remote Controls
Configure how YOYOCam signals alarms By default, YOYOCam sends SMS and MMS to the Master when an alarm is triggered. You can also send alarms by E-mail and voice calling. Additionally, YOYOCam can be set to bleep when the alarm is triggered. -
Page 12: Interacting With Yoyocam
Interacting with YOYOCam General Command Format Commands and Parameters Master and Users interact with YOYOCam by sending SMS messages that contain specially formatted textual commands. YOYOCam typically responds with confirmation text by SMS. Where the command is a request for images, these are sent by MMS or E-mail. Generic format of a simple command: Command: #CommandCode#... -
Page 13: Switch Yoyocam On And Off
For example: International format: +46702222222 National format: 0702222222 Note: Do not include spaces or any other character in phone numbers. YOYOCam treats a number in International format as different from one in National format. For example, if you send #06#+46702222222# and #06#+46702222222#, YOYOCam will not recognise that they are both actually the same user, and will configure two users, one with the number in each format. - Page 14 Arming and Disarming YOYOCam by SMS To arm YOYOCam by SMS: Command: #01# Response: YOYOCam is armed Status Indicator: To disarm YOYOCam by SMS Command: #02# Response: YOYOCam is disarmed Status Indicator: Arming and Disarming YOYOCam using the Remote Control Note: The Remote Control must first be paired with YOYOCam.
- Page 15 a different schedule for each day, for example workdays and weekends To set the armed periods Command: #129#Day#ArmTime1#DisarmTime1#ArmTime2#DisarmTime2 #ArmTime3#DisarmTime3# Example: #129#0000#0800#1700#2359# (armed outside working hours 0800-1700) Response: Parameter is 0000#0800#1700#2359# Note: Time is expressed as HHMM, for example 0000 is midnight, 1200 is mid-day, 1730 is 17:50 (5:30pm), 2359 is 23:59 (11:59PM).
- Page 16 set to automatically send images according to a timetable. Request one image To request a single image to be sent to your mobile by MMS: Command: #03# Response: MMS message containing the image Note: The image size is the size set by the Image Size setting (default 320 x 240) See Image settings for more information about the image format.
- Page 17 address) Master and users can request images to be sent to any mobile phone by providing the mobile phone number, or to any E-mail address. You can request YOYOCam to take up to 8 images in a sequence. The interval between the images is determined by the Image Interval setting (default 0.5 seconds). The images are sent by MMS if a mobile number is provided, or E-mail (using the mobile operator’s MMS service to send to the E-mail address) if an E-mail address is provided.
-
Page 18: Yoyocam Settings
Every day Monday Tuesday Wednesday Thursday Friday Saturday Sunday Monday to Friday To enable/disable periodic image sending: Turn On: #115#1# Response: Periodic sending of images - enabled Turn Off: #115#0# (Default) Response: Periodic sending of images - disabled YOYOCam Settings Master, Users &... - Page 19 Error Responses MASTER phone number YOYOCam already has a Master number configured. already exists Note: YOYOCam gives this response if you send #00# from the configured Master phone. From the Master’s or a User’s mobile phone, you can send the #07# Check Status &...
- Page 20 Error Responses as above To find out which User numbers are set: Command: #07# Response: MMS message including YOYOCam status and User number(s) To delete a user: Command: #113#UserNumber# Example: #113#+46703333333# Response: +46703333333 USER phone number has been deleted To delete several Users in a single command: Command: #113# UserNumber1#UserNumber2#UserNumber3#UserNumber4# ….
-
Page 21: Sensor Settings
Sensor Settings You can set up which sensors trigger the alarm when YOYOCam is armed. Infrared Body Detector The infrared body detector works by detecting the heat emitted from a body moving in front of it. Turn On: #118#1# (Default) Response: Infrared sensor - enabled Turn Off:... -
Page 22: Mms Message
Warning Bleep from YOYOCam. YOYOCam bleeps for approximately 5 seconds when the alarm is triggered. Turn On: #130#1# Response: Warning signal - enabled Turn Off: #130#0# (Default) Response: Warning signal - disabled SMS Message YOYOCam sends the Master an SMS when the alarm is triggered, for example: Alarm from IR sensor received. -
Page 23: Image Settings
Master and Each user can add their Email address by sending this command from their mobile phone: Command: #108#EmailAddress# Example: #108#night.warden@yoyomotion.com# Response: Current alarm notification Email address is: night.warden@yoyomotion.com To delete all E-mail addresses: Command: #109# Response: E-mail address - deleted Voice Call YOYOCam calls the Master and each added User number in turn until someone answers, at which point that person can hear the audio from YOYOCam. -
Page 24: Image Quantity
Image Size This setting defines the size of images taken by the built-in camera. Command: #32#Size# Example: #32#3# Response: Image size has been reset to 3 You can chose from three image sizes. Default is Size 2: Size Width x Height Image Image size Application... -
Page 25: Image Interval
Image Interval This is the time delay between camera snapshots sent in an MMS. The default is 0.5 seconds. Command: #103#ImageInterval# Example: #103#10# Response: Image capture interval has been set to 10 Image Interval may take values 3 to 10: ImageInterval Value in seconds Value in Milliseconds... - Page 26 alarm by SMS only or SMS followed by MMS, according to the way the sensor is configured. Adding Wireless Sensors To add a Wireless Sensor 1. Make sure the wireless sensor is powered on. 2. Send the command to add the sensor to YOYOCam Command: #05#SensorDescription# (SMS notification upon alarm) Command: #05#*SensorDescription#...
-
Page 27: Advanced Settings
To delete several wireless sensors in one command: Command: #112#SensorDescription1#SensorDescription2#SensorDescription3# … Example: #112#FrontDoor#BackDoor#SmokeAlarm# Response: Sensor deleted successfully FrontDoor BackDoor SmokeAlarm To Delete all sensors: Command: #112# Response: Sensor deleted successfully Advanced Settings Status Indicator on/off You can disable the status indicator if you want YOYOCam to have no visual status indication. Turn On: #143#1# (Default) - Page 28 To set number of alarms before auto-disarm: Command: #139#Times# Example: #139#3# Response: Disarm the YOYOCam after 3 alarms Note: Times must be at least 1. Note: After the given number of alarms, YOYOCam auto-disarms and sends an SMS: YOYOCam has auto-disarmed Note: The counter is reset each time YOYOCam is manually disarmed or armed.
- Page 29 Alarm image quantity: 5 Image size: 320*240 Image direction: 0 Image contrast: 4 Image interval: 5 Image brightness: 4 Image compression: 1 Sensitivity of motion detection: 4 Periodic sending of images - disabled Day: Monday-Friday Time: 0000-0800 Image capture interval:60 1700-2358 Image capture interval:60 Periodic arming and disarming - enabled...
-
Page 30: Mobile Network Settings
Command: #09# Response: #00# Set as Master #01# Arm YOYOCam #02# Disarm YOYOCam #03#Password#Quantity# Request images #04#OldPassword#NewPassword# Change 4-digit password #05#SensorDescription# Load sensor #06#number# Add USER phone number #07# Report Status #08#Password# Reset to default settings #22#0# Disable motion detection #22#1# Enable motion detection Mobile Network settings YOYOCam uses MMS (Multimedia Messaging Service) to send images and Email messages. -
Page 31: Manual Mms Configuration
Quick Settings for Scandinavian MVNOs YOYOCam has quick settings for the major Scandinavian MVNOs – simply send the MVNO name to YOYOCam. To enter MMS settings for Scandinavian MVNOs: Command: #145#Name# Example: #145#ACN# Response: ACN MMS settings configured Error Response: YOYOCam returns a list of valid names. Network Operator Command to send Response... -
Page 32: Reset Mms Configuration
Example: #124#http://mmsc.t-mobile.co.uk:8002# Response: MMS configuration successful. http://mmsc.t-mobile.co.uk:8002 To configure MMS Internet Access Point Settings manually: Command: #125#GatewayIP#WAPGatewayPort#HTTPGatewayPort#APN#APNusername# APNpassword# Example: #125#149.254.201.135#8080#8002#general.t-mobile.uk#user#tm# Response: Set MMS parameter successfully: 149.254.201.135#8080#8002#general.t- mobile.uk#user#tm Reset MMS Configuration To clear out any manual settings and return to automatic MMS configuration: Command: #54# Response:... -
Page 33: Using The Remote Control
Using the Remote Control Pairing your YOYOCam with a Remote Control Before use, each Remote must be paired with your YOYOCam. Up to five remotes can be paired; two are supplied. To pair a Remote Control with YOYOCam: 1. Press the SET button. YOYOCam bleeps and LED flashes orange indicating pairing mode. -
Page 34: Emergency Numbers
the Emergency alarm. Emergency Numbers The Master can add up to 9 Emergency Numbers. To add an Emergency number. Use this command to add numbers one by one. Use international (recommended) or national format. Command: #106#EmergencyNumber# Example: #106#+46703333333# Response: +46703333333 Emergency phone number added To add several Emergency numbers in a single command (maximum 9): Command: #106#EmergencyNumber1#EmergencyNumber2#EmergencyNumber3# …... - Page 35 Response: MMS message including YOYOCam status and Emergency number(s) Error Responses Emergency phone number already EmergencyNumber has already been set up. exists Note that YOYOCam treats the national and international format of the same number as different and will not issue this error is both formats are sent.
- Page 36 5. Hang up the call at the landline. 6. Wait 10 seconds. 7. Pick up the Landline: If you hear dialling tone and can make another call, your line is not blocked. If you still hear YOYOCam, the incoming call is blocking your landline. This is a property of your telephone network.
-
Page 37: Remote Control Battery
Remote Control Battery The remote control uses one CR2032 type 3 Volt battery. When the battery runs low, YOYOCam bleeps and a warning SMS is sent to the Master. -
Page 38: Guest Commands
Guest Commands This page describes the commands that are available to Guests. The Master does not need to add Guest users to YOYOCam. Instead the Master gives the Guest the Password, and the Password has to be included in the commands that the Guest sends to YOYOCam. Request one image To request a single image to be sent to your mobile by MMS: Command:... -
Page 39: Factory Reset
Factory Reset If the Master phone is lost or you want to set up YOYOCam again from the beginning, you can use Factory Reset to set all settings and parameters back to the factory default. Following Factory Reset you will need to re-pair the remote controls and any remote sensors, re-enter any mobile network (MMS) settings and reconfigure all users etc. -
Page 40: Troubleshooting
Troubleshooting Problem: YOYOCam cannot register a Master Possible Causes: YOYOCare has already a registered Master Possible Solution: Master Reset your YOYOCare and then register again Problem: Master is not recognized Possible Cause: The master number was presented to YOYOCam in national format when set up and now the number is being presented in International format, or vice versa. - Page 41 included with the SMS command. For example, in command #33#Quantity#, #33#1# will fail because Quantity must be between 2 and 8.
-
Page 42: Command Summary
Command Summary These tables summarise the most useful YOYOCam commands: MASTER There is one Master user who has complete control over YOYOCam. Master-only commands: Text to send What it does #00# (after factory reset) sender becomes Master #14#NewMasterNumber# Change from present Master number to NewMasterNumber #04#OldPassword#NewPassword# Change the Guest password (default is 1234) #06#UserNumber#... - Page 43 GUEST Guest users are people who do not normally need access, but might be asked to check the protected area because they are nearby, for example. Guest users do not need to be pre-defined to YOYOCam, but do require the PIN. Guest commands: Text to send What it does #03#Password#...
-
Page 44: Specifications
Receiving distance sensors Up to 15m Power adapter Input: 110V~240V Output: DC 5.5V/2A Built-in battery Lithium 800mAh Battery back-up Up to 12 hours Low battery alarm by SMS Size 75x125x43 mm Weight 186 grams © Copyright, 2010 Yoyomotion AB. All rights reserved.
