Specifications

Typical for 25 °C unless otherwise specified.
Specifications in italic text are guaranteed by design.

Digital input/output

Digital type
Configuration
Number of channels
Output high
Output low
Input high
Input low
Power-up / reset state
Miscellaneous

Power consumption

+5V

Environmental

Operating temperature range
Storage temperature range
Humidity

Main connector and pin out

Connector type
Compatible cables
Compatible accessory products
with the C50FF-x
Table 1. DIO specifications
8255 mode 0 emulation
Output: 74S244
Input: 74LS373
4 banks of 8, 4 banks of 4, programmable by bank as input or output
48 I/O
2.4 volts min @ -15 mA
0.5 volts max @ 64 mA
2.0 volts min, 7 volts absolute max
0.8 volts max, -0.5 volts absolute min
Input mode (high impedance)
Locations provided for installation of pull-up or pull-down resistors.
Table 2. Power consumption specifications
700 mA typical, 1200 mA max
Table 3. Environmental specifications
0 to 50 °C
-40 to +100 °C
0 to 90% non-condensing
Table 4. Connector specifications
50-pin shrouded male header (P1)
C50FF-x
CIO-TERM100
CIO-SPADE50
CIO-MINI50
SSR-RACK24, SSR-RACK48
CIO-ERB24, CIO-ERB48
17
Chapter 5
