CIO-DIO48H User's Guide
Disregard the numbers printed on the switch
When setting the base address, refer to the numbers printed in white on the printed circuit board.
Hex Range Function
000-00F 8237 DMA #1
020-021 8259 PIC #1
040-043 8253 TIMER
060-063 8255 PPI (XT)
060-064 8742 CONTROLLER (AT)
070-071 CMOS RAM & NMI MASK (AT)
080-08F DMA PAGE REGISTERS
0A0-0A1 8259 PIC #2 (AT)
0A0-0AF NMI MASK (XT)
0C0-0DF 8237 #2 (AT)
0F0-0FF 80287 NUMERIC CO-P (AT)
1F0-1FF HARD DISK (AT)
200-20F GAME CONTROL
210-21F EXPANSION UNIT (XT)
238-23B BUS MOUSE
23C-23F ALT BUS MOUSE
270-27F PARALLEL PRINTER
2B0-2BF EGA
You can set the base address switch to any address in the range of 000-3F8. If you are not using IBM
prototyping cards or another board which occupies these addresses, 300-31Fh are also free to use.
Addresses not specifically listed, such as 390-39Fh, are not reserved and may be available. Check your
computer for other boards which may use I/O addresses.

Installing the CIO-DIO48H

After you configure the base address, you can install the CIO-DIO48H into your computer. Follow the steps
below.
Install the MCC DAQ software before you install your board
The driver needed to run your board is installed with the MCC DAQ software. Therefore, you need to install
the MCC DAQ software before you install your board. Refer to the Quick Start Guide for instructions on
installing the software.
1. Turn your computer off, open it up, and insert your board into an available ISA slot.
2. Close your computer and turn it on.
3. To test your installation and configure your board, run the InstaCal utility you installed in the previous
section. Refer to the Quick Start Guide that came with your board
Software-Quick-Start.pdf
PC I/O Address Summary
for information on how to initially set up and load InstaCal.
10
Hex Range Function
2C0-2CF EGA
2D0-2DF EGA
2E0-2E7 GPIB (AT)
2E8-2EF SERIAL PORT
2F8-2FF SERIAL PORT
300-30F PROTOTYPE CARD
310-31F PROTOTYPE CARD
320-32F HARD DISK (XT)
378-37F PARALLEL PRINTER
380-38F SDLC
3A0-3AF SDLC
3B0-3BB MDA
3BC-3BF PARALLEL PRINTER
3C0-3CF EGA
3D0-3DF CGA
3E8-3EF SERIAL PORT
3F0-3F7 FLOPPY DISK
3F8-3FF SERIAL PORT
www.mccdaq.com/PDFmanuals/DAQ-
Installing the CIO-DIO48H
