CIO-DIO48H User's Guide
Pin Signal name
50 GND
48 FIRSTPORTC Bit 0
46 FIRSTPORTC Bit 2
44 FIRSTPORTC Bit 4
42 FIRSTPORTC Bit 6
40 FIRSTPORTB Bit 0
38 FIRSTPORTB Bit 2
36 FIRSTPORTB Bit 4
34 FIRSTPORTB Bit 6
32 FIRSTPORTA Bit 0
30 FIRSTPORTA Bit 2
28 FIRSTPORTA Bit 4
26 FIRSTPORTA Bit 6
24 SECONDPORTC Bit 0
22 SECONDPORTC Bit 2
20 SECONDPORTC Bit 4
18 SECONDPORTC Bit 6
16 SECONDPORTB Bit 0
14 SECONDPORTB Bit 2
12 SECONDPORTB Bit 4
10 SECONDPORTB Bit 6
8 SECONDPORTA Bit 0
6 SECONDPORTA Bit 2
4 SECONDPORTA Bit 4
2 SECONDPORTA Bit 6
Table 5. Main connector pin out
Pin
49
47
45
43
41
39
37
35
33
31
29
27
25
23
21
19
17
15
13
11
9
7
5
3
1
18
Signal name
+5V
FIRSTPORTC Bit 1
FIRSTPORTC Bit 3
FIRSTPORTC Bit 5
FIRSTPORTC Bit 7
FIRSTPORTB Bit 1
FIRSTPORTB Bit 3
FIRSTPORTB Bit 5
FIRSTPORTB Bit 7
FIRSTPORTA Bit 1
FIRSTPORTA Bit 3
FIRSTPORTA Bit 5
FIRSTPORTA Bit 7
SECONDPORTC Bit 1
SECONDPORTC Bit 3
SECONDPORTC Bit 5
SECONDPORTC Bit 7
SECONDPORTB Bit 1
SECONDPORTB Bit 3
SECONDPORTB Bit 5
SECONDPORTB Bit 7
SECONDPORTA Bit 1
SECONDPORTA Bit 3
SECONDPORTA Bit 5
SECONDPORTA Bit 7
Specifications
